Hammond Manufacturing
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 面积（长x宽） | 19.2" (124cm) |
| 产品特点 | Card Guides |
| 重量 | 0.66 lb (299.37g) |
| 颜色 | Black, Natural |
| 标准包装 | 1 |
| 材质 | Metal, Aluminum |
| 身高 | 2.087" (53.01mm) |
| 尺寸/尺寸 | 4.724" L x 4.055" W (119.99mm x 103.00mm) |
| 集装箱类型 | Box |
| 设计 | End Panel(s) |
| 厚度 | 0.060" (1.52mm) |
| 装运信息 | Shipped from Digi-Key |
| 阀体材质 | Extruded Aluminium, Plastic |
| 颜色 | Clear |
| 外部尺寸 | 120 x 103 x 53mm |
| 外部高度 | 53 mm |
| 外部长度 | 120 mm |
| 外宽 | 103 mm |
| 击倒数 | 0 |
| RoHS指令 | Compliant |
| 外宽 | 4.06 in |
| 外部高度 | 2.09 in |
| 产品 | Electronics Enclosures |
| 产品种类 | Enclosures, Boxes, & Cases |
| 类型 | Bench Top |
| RoHS | RoHS Compliant |
| 外部深度 | 4.72 in |
| 外壳类型 | :Instrument |
| 外壳材质 | :Aluminium |
| 主体颜色 | :Transparent |
| External Height - Imperial | :2.09" |
| External Height - Metric | :53mm |
| External Width - Imperial | :4.06" |
| External Width - Metric | :103mm |
| External Depth - Imperial | :4.72" |
| External Depth - Metric | :120mm |
| IP等级 | :- |
| NEMA号 | :- |
| SVHC | :No SVHC (20-Jun-2013) |
| Weight (kg) | 0.28 |
| Tariff No. | 76169990 |
| Brand/Series | 1455Series |
| 配置 | Desktop |
| 外形尺寸 | 4.720x4.060x2.090In. |
| 表面处理 | ClearAnodized |
| Material,Body | ExtrudedAluminum |
| Material,Panel | Plastic |
| Thickness,Panel | 0.06in. |
| Panel colour | grey |
| Dimension Z | 53mm |
| Dimension Y | 120mm |
| Dimension X | 103mm |
| Multiplicity | 1 |
| Gross weight | 0.26 kg |
| Body colour | grey |
| spg | 10 |
| Enclosure series | 1455 |
| 机箱类型 | with panel |
| Panel material | aluminium |
| Collective package [pcs] | 10 |
| Enclosure material | aluminium |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
