所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 面积（长x宽） | 25.5" (165cm) |
| 产品特点 | Card Guides |
| 重量 | 0.5 lb (226.8g) |
| 颜色 | Black, Natural |
| 标准包装 | 1 |
| 材质 | Metal, Aluminum |
| 身高 | 1.201" (30.51mm) |
| 尺寸/尺寸 | 6.299" L x 4.055" W (159.99mm x 103.00mm) |
| 集装箱类型 | Box |
| 设计 | End Panel(s) |
| 厚度 | 0.060" (1.52mm) |
| 其他名称 | HM897 |
| 装运信息 | Shipped from Digi-Key |
| 阀体材质 | Aluminium |
| 外部尺寸 | 160 x 106.13 x 33.63mm |
| 外部高度 | 33.63 mm |
| 外部长度 | 160 mm |
| 外宽 | 106.13 mm |
| RoHS指令 | Compliant |
| 外宽 | 4.06 in |
| 外部高度 | 1.2 in |
| 产品 | Electronics Enclosures |
| 产品种类 | Enclosures, Boxes, & Cases |
| 类型 | Bench Top |
| RoHS | RoHS Compliant |
| 外部深度 | 6.3 in |
| 外壳类型 | :Instrument |
| 外壳材质 | :Aluminium |
| 主体颜色 | :Transparent |
| External Height - Imperial | :1.2" |
| External Height - Metric | :30.5mm |
| External Width - Imperial | :4.06" |
| External Width - Metric | :103mm |
| External Depth - Imperial | :6.3" |
| External Depth - Metric | :160mm |
| IP等级 | :- |
| NEMA号 | :- |
| SVHC | :No SVHC (20-Jun-2013) |
| Weight (kg) | 0.24 |
| Tariff No. | 76169990 |
| Brand/Series | 1455Series |
| 配置 | Desktop |
| 外形尺寸 | 6.300x4.060x1.200In. |
| 表面处理 | ClearAnodized |
| Material,Body | ExtrudedAluminum |
| Material,Panel | Plastic |
| Thickness,Panel | 0.06in. |
| Panel colour | black |
| Dimension Z | 30.5mm |
| Dimension Y | 160mm |
| Dimension X | 103mm |
| Body colour | grey |
| Enclosure series | 1455 |
| Panel material | ABS |
| Enclosure material | aluminium |
