| 规格书 |
 1785B,1786B,1787B,1788 Manual 1785B,1786B,1787B,1788 Datasheet |
| Rohs | Contains lead / RoHS non-compliant |
| 标准包装 | 1 |
| 型 | Bench (AC to DC) |
| - 电源电压 | 110VAC, 220VAC |
| Voltage - 输出功率 | 0 ~ 32VDC |
| Current - 输出功率 | 0 ~ 6A |
| Display 型 | VFD |
| 数字/字母数 | 10 |
| 输出数 | 1 |
| 大小/尺寸 | 15.000 L x 10.000 W x 4.160 H (381.00mm x 254.00mm x 105.66mm) |
| 特点 | Programmable, RS232 Port |
| 功率（瓦特） | - |
| 精度-电压表,电流表 | 0.05% + 120mV |
| 电压调节 - 线 | 0.01% + 3mV |
| 电压调节 - 负载 | 0.02% + 5mV |
| 现行规例 - 线 | 0.1% + 2mA |
| - 负载电流调节 | 0.1% + 2mA |
| 波纹 | 3mV p-p, 1mV rms |
| 重量 | 15 lbs (6.8kg) |
| 尺寸/尺寸 | 15.000" L x 10.000" W x 4.160" H (381.00mm x 254.00mm x 105.66mm) |
| 输出数 | 1 |
| 显示器类型 | VFD |
| 流 - 线路 | 0.1% + 2mA |
| 产品特点 | Programmable, RS232 Port |
| 重量 | 15 lbs (6.8kg) |
| 字符数 | 10 |
| 电压 - 输出 | 0 ~ 32VDC |
| 稳压 - 负载 | 0.02% + 5mV |
| 电流 - 输出 | 0 ~ 6A |
| 电压 - 电源 | 110VAC, 220VAC |
| 标准包装 | 1 |
| 纹波 | 3mV p-p, 1mV rms |
| 电流调节 - 负载 | 0.1% + 2mA |
| 稳压 - 线路 | 0.01% + 3mV |
| 类型 | Bench (AC to DC) |
| 其他名称 | BK1788 |
| 精确度 - 伏特表; | 0.05% + 120mV |
| 输出电压通道1 | 0 VDC to 32 VDC |
| 产品种类 | Bench Top Power Supplies |
| AC电源电压 | For B&K Precision products requiring AC input, please consult the accompanying User Manual before plugging the unit into mains power. Most products are configured for US mains/110VAC input but have a selectable input for 220VAC input. In some cases this may require a fuse change. |
| 电缆类型 | Detachable Power Cord Included |
| 单位重量 | 17.600 lbs |
| 输入电压 | 110 VAC to 220 VAC |
| RoHS | RoHS Compliant By Exemption |
| 零件号别名 | EXD |
| 输出电流通道1 | 6 A |
| 系列 | 1700 |
| 产品类型 | Dc Power Supply |
| 宽度 | 4.16in |
| 外形尺寸 | 10 x 4.16 x 15in |
| Brand Name | BK Precision |
| 电源类型 | Digital |
| Output Current Rating | 0 to 6A |
| 包括 | User Manual, Software Installation Disk, Test Report, Power Line Cord, IT-E131 RS232 to TTL Serial Converter Cable |
| Input Voltage Rating | 110/220V ac |
| 长度 | 10in |
| 功耗 | 350VA |
| 额定输出电压 | 0 to 32V dc |
| 最低工作温度 | +32°F |
| Protection Features | Limit Voltage Protection, Over Current Protection, Temperature Protection |
| 安装类型 | Surface Mount |
| 身高 | 15in |
| 最高工作温度 | +104°F |
| associated | IT-E151 |
