B&K Precision
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 尺寸/尺寸 | 9.800" L x 2.800" W x 6.000" H (248.92mm x 71.12mm x 152.40mm) |
| 输出数 | 1 |
| 显示器类型 | LCD |
| 流 - 线路 | ±20mA |
| 产品特点 | USB Charge Port |
| 重量 | 4.4 lbs (2kg) |
| 字符数 | 3 (2) |
| 电压 - 输出 | 1 ~ 36VDC |
| 稳压 - 负载 | ±50mV |
| 电流 - 输出 | 0 ~ 3A |
| 功率（瓦特） | 108W |
| 电压 - 电源 | 100 ~ 120VAC |
| 标准包装 | 1 |
| 纹波 | ±5mV rms |
| 电流调节 - 负载 | ±20mA |
| 稳压 - 线路 | ±20mV |
| 类型 | Bench (AC to DC) |
| 其他名称 | BK1550 |
| 精确度 - 伏特表; | 1% + 5 digits |
| 输出电压通道1 | 1 VDC to 36 VDC |
| 产品种类 | Bench Top Power Supplies |
| 电缆类型 | North American Power Cord Included |
| 单位重量 | 4.600 lbs |
| 输入电压 | 100 VAC to 120 VAC |
| RoHS | RoHS Compliant By Exemption |
| 零件号别名 | EXD |
| 输出电流通道1 | 3 A |
| Current,Output | 3A |
| NumberofOutputs | 1 |
| Power,Output | 108W |
| Voltage,Output | 36VDC |
| 产品类型 | Dc Power Supply |
| 宽度 | 6in |
| 外形尺寸 | 2.8 x 6 x 9.8in |
| Brand Name | BK Precision |
| Maximum Line Regulation | ±20 mV|±20 mA |
| 电源类型 | Digital |
| Output Current Rating | 0 to 3A |
| 包括 | User Manual, Power Cord |
| 纹波及噪音 | Ripple:±5|Noise:±50mVrms |
| Input Voltage Rating | 100 to 120V ac |
| 长度 | 2.8in |
| 功耗 | 108W |
| 额定输出电压 | 1 to 36V dc |
| Protection Features | Short Circuit Protection, Overload Protection, Over Temperature Protection, Over Voltage Protection |
| 安装类型 | Surface Mount |
| 身高 | 9.8in |
| Maximum Load Regulation | ±50 mV|±20 mA |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
