TRACOPOWER
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 深度 | 10.2mm |
| 效率 | 81% |
| 输入电压 | 36 → 75V dc |
| 隔离电压 | 1500V dc |
| 长度 | 32mm |
| 线路调整 | ±0.5% |
| 负载调整率 | ±2% |
| 最高温度 | +85°C |
| 最低气温 | -40°C |
| 安装类型 | Through Hole |
| 平均无故障时间 | 1000000h |
| 输出数 | 2 |
| 输出电流 | ±125mA |
| 输出电压 | ±12V dc |
| 包装 | DIL 24 |
| 额定功率 | 3W |
| 纹波和噪声 | 60mV Pk-Pk |
| 重量 | 12g |
| 宽度 | 20mm |
| DC / DC Converter Type | :Isolated POL |
| DC / DC Converter Output Type | :Fixed |
| Input Voltage DC Min | :36V |
| Input Voltage DC Max | :75V |
| No. of Outputs | :2 |
| Output Voltage Nom. | :12V, -12V |
| Output Current Max | :125mA, 125mA |
| Output Power Max | :3W |
| DC / DC Converter Mounting | :Through Hole |
| 身高 | :10.2mm |
| Approvals / Standards | :- |
| Approval Bodies | :CSA, EN, IEC, UL |
| 外部深度 | :20.0mm |
| External Length / Height | :10.2mm |
| 外宽 | :32.0mm |
| 可燃性等级 | :UL94V-0 |
| Input Voltage Max | :75VDC |
| Input Voltage Min | :36VDC |
| Operating Temperature Max | :75°C |
| Operating Temperature Min | :-25°C |
| Output Current - Output 2 | :125mA |
| Output Ripple Voltage pk-pk | :60mV |
| Output Voltage + | :12VDC |
| Output Voltage - | :-12VDC |
| 电源电压 | :48V |
| Weight (kg) | 0.01679 |
| Tariff No. | 85044090 |
