cigen-UBX1A

UBX1A extendedoffer 系列

Nichicon Corporation

Nichicon Corporation

Leaded aluminum electrolytic capacitors for diverse electronic applications

系列图片（12 张）

文档与媒体

e-bx.pdf

e-mi_tape.pdf

e-bx-25845.pdf

常见问答

内容由 AI 生成，仅供参考

加载中...

03

UBX1A extendedoffer - 型号列表

共 11 个型号

制造商零件编号	库存	价格	产品类别	产品	工厂包装数量	RoHS	容差	电容	额定电压	漏电流	高频纹波电流	直径	包装方式	引脚间距	封装形式	尺寸/外形	端接样式	系列	工作温度	供电电压	电阻公差	高度	导线线规	连接器间距	外壳尺寸-插入件（转换至）	功能	技术	工作范围	损耗角正切（DF）	额定寿命
2 UBX1A331MPL Aluminum Electrolytic Capacitors - Leaded 10volts 330uF 150c 10x16 5LS CAP ALUM 330UF 10V 20% RADIAL Nichicon 330μF ±20% 10V dc Through Hole Aluminium Electrolytic Capacitor Capacitor Nichicon BX 系列 330μF 10 V 直流铝电解电容器 , ±20%容差 Nichicon	15	¥3.968	Aluminum Electrolytic Capacitors - Leaded	High Temp Electrolytic Capacitors	200	RoHS Compliant	20 %	330 uF	10 V	99 uA	300 mA	10 mm	Bulk	5 mm	16 mm	10 mm Dia. x 16 mm L	Radial	BX	- 55 C to + 150 C	10 V 直流	+20%	16mm	0.6mm	5mm	径向	Y	电解	1000h	-	-
2 UBX1A102MHL Aluminum Electrolytic Capacitors - Leaded 10volts 1000uF 150c 12.5x25 5LS CAP ALUM 1000UF 10V 20% RADIAL Nichicon 1000μF ±20% 10V dc Through Hole Aluminium Electrolytic Capacitor Capacitor Nichicon BX 系列 1000μF 10 V 直流铝电解电容器 , ±20%容差 Nichicon	765	¥10.062	Aluminum Electrolytic Capacitors - Leaded	High Temp Electrolytic Capacitors	100	RoHS Compliant	20 %	1000 uF	10 V	300 uA	600 mA	12.5 mm	Bulk	5 mm	25 mm	12.5 mm Dia. x 25 mm L	Radial	BX	- 55 C to + 150 C	10 V 直流	+20%	25mm	0.6mm	5mm	径向	Y	电解	1000h	-	-
3 UBX1A222MHL Aluminum Electrolytic Capacitors - Leaded 10volts 2200uF 150c 16x31.5 7.5LS CAP ALUM 2200UF 10V 20% RADIAL Nichicon 2200μF ±20% 10V dc Through Hole Aluminium Electrolytic Capacitor Capacitor Nichicon BX 系列 2200μF 10 V 直流铝电解电容器 , ±20%容差 Nichicon	50	¥9.06	Aluminum Electrolytic Capacitors - Leaded	High Temp Electrolytic Capacitors	50	RoHS Compliant	20 %	2200 uF	10 V	660 uA	1000 mA	16 mm	Bulk	7.5 mm	31.5 mm	16 mm Dia. x 31.5 mm L	Radial	BX	- 55 C to + 150 C	10 V 直流	+20%	31.5mm	0.8mm	7.5mm	径向	Y	电解	2000h	-	-
3 UBX1A332MHL Aluminum Electrolytic Capacitors - Leaded 10volts 3300uF 150c 18x35.5 7.5LS CAP ALUM 3300UF 10V 20% RADIAL Nichicon 3300μF ±20% 10V dc Through Hole Aluminium Electrolytic Capacitor Capacitor Nichicon BX 系列 3300μF 10 V 直流铝电解电容器 , ±20%容差 Nichicon	24	¥11.04	Aluminum Electrolytic Capacitors - Leaded	High Temp Electrolytic Capacitors	50	RoHS Compliant	20 %	3300 uF	10 V	990 uA	1200 mA	18 mm	Bulk	7.5 mm	35.5 mm	18 mm Dia. x 35.5 mm L	Radial	BX	- 55 C to + 150 C	10 V 直流	+20%	35.5mm	0.8mm	7.5mm	径向	Y	电解	2000h	-	-
3 UBX1A472MHL Aluminum Electrolytic Capacitors - Leaded 10volts 4700uF 150c 18x40 7.5LS CAP ALUM 4700UF 10V 20% RADIAL Nichicon 4700μF ±20% 10V dc Through Hole Aluminium Electrolytic Capacitor Capacitor Nichicon	91	¥11.90	Aluminum Electrolytic Capacitors - Leaded	High Temp Electrolytic Capacitors	50	RoHS Compliant	20 %	4700 uF	10 V	1410 uA	1300 mA	18 mm	Bulk	7.5 mm	40 mm	18 mm Dia. x 40 mm L	Radial	BX	- 55 C to + 150 C	-	-	-	-	-	-	-	-	-	-	-
2 UBX1A471MPL Aluminum Electrolytic Capacitors - Leaded 10volts 470uF 150c 10x20 5LS CAP ALUM 470UF 10V 20% RADIAL Nichicon 470μF ±20% 10V dc Through Hole Aluminium Electrolytic Capacitor Capacitor Nichicon BX 系列 470μF 10 V 直流铝电解电容器 , ±20%容差 Nichicon	650	¥4.136	Aluminum Electrolytic Capacitors - Leaded	High Temp Electrolytic Capacitors	200	RoHS Compliant	20 %	470 uF	10 V	4 uA	400 mA	10 mm	Bulk	5 mm	20 mm	10 mm Dia. x 20 mm L	Radial	BX	- 55 C to + 150 C	10 V 直流	+20%	20mm	0.6mm	5mm	径向	Y	电解	1000h	0.2	1000 hr
2 UBX1A331MPD1TD CAP ALUM 330UF 10V 20% RADIAL Capacitor Nichicon	488	¥4.97	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
2 UBX1A471MPL1TD CAP ALUM 470UF 10V 20% RADIAL Nichicon	454	¥5.59	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
2 UBX1A102MHL1TO CAP ALUM 1000UF 10V 20% RADIAL Capacitor Nichicon	472	¥8.14	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
UBX1A471MPD1TD Capacitor Nichicon	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
UBX1A331MPL1TD CAP ALUM 330UF 20% 10V RADIAL Nichicon	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
