cigen-TL1014

TL1014 tactile switche 系列

E-Switch, Inc.

Compact tactile switches for surface-mount electronic applications

系列图片（8 张）

文档与媒体

PDF 文档

PDF 文档

TL1014AF180QG.pdf

PDF 文档

PDF 文档

PDF 文档

TL1014%20SERIES.pdf

PDF 文档

PDF 文档

常见问答

内容由 AI 生成，仅供参考

加载中...

03

TL1014 tactile switche - 型号列表

共 10 个型号

制造商零件编号	库存	价格	产品类别	其他名称	标准包装数量	RoHS	电路	开关功能	触点额定值 @ 电压	外形尺寸(长x宽)	包装方式	致动器类型	安装类型	开关行程	操作力	执行器材料	端接样式	执行器方向	照明类型	机械寿命	工作温度	标准包装规格	海关税号	额定电压	最大额定电流	最大触点电流	供电电压 (Vcc/Vdd)	重量	安装样式	开关驱动电平	典型触点布局	系列	产品特性	工厂包装数量	连接器类型 - 电压输入	接触镀层	类型	卡标准	触点形式	行程范围	按钮样式/尺寸	按钮/帽颜色
5 TL1014BF180QG SWITCH TACTILE SPST-NO 0.05A 12V Tactile Switches 4.7mm x 3.5mm SMT Gull Wing Side Act Switch Tactile N.O. SPST Rectangular Button Gull Wing 0.05A 12VDC 100000Cycle 1.77N SMD T/R SWITCH, TACTILE, SPST, 0.05A, SMD Tact Switches E-Switch	91	¥3.12	Tactile Switches	EG4343TR	3,000	Lead free / RoHS Compliant	SPST-NO	Off-Mom	0.05A @ 12VDC	4.70mm x 3.50mm	Tape & Reel (TR)	Rectangular Button	Surface Mount, Right Angle	0.30mm	180gf	Polyamide (PA46), Nylon 4/6	Gull Wing	Side Actuated	Non-Illuminated	100,000 Cycles	-20°C ~ 70°C	-	85365019	12 V	50 mA	:50mA	:12V	0.002	SMD/SMT	:Side	:SPST-NO	TL1014	Board Guide	3000	:Solder	Silver	-	-	-	-	-	-
4 TL1014AF180QG SWITCH TACTILE SPST-NO 0.05A 12V Tact Switches E-Switch	0		-	EG4342TR	3,000	Lead free / RoHS Compliant	SPST-NO	Off-Mom	0.05A @ 12VDC	4.70mm x 3.50mm	Tape & Reel (TR)	Rectangular Button	Surface Mount, Right Angle	0.30mm	180gf	Polyamide (PA46), Nylon 4/6	Gull Wing	Side Actuated	Non-Illuminated	100,000 Cycles	-20°C ~ 70°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Switches	Tactile Switch	-	-	-	-
2 TL1014AF160QG SWITCH TACTILE SPST-NO 0.05A 12V Tactile Switches 4.7mm x 3.5mm SMT Gull Wing Side Act SWITCH, TACTILE, SPST, 50mA, SMD E-Switch	9061	¥2.43	-	EG5043TR	3,300	Lead free / RoHS Compliant	SPST-NO	Off-Mom	0.05A @ 12VDC	4.70mm x 3.50mm	Tape & Reel (TR)	Rectangular Button	Surface Mount, Right Angle	0.30mm	160gf	Polyamide (PA46), Nylon 4/6	Gull Wing	Side Actuated	Non-Illuminated	100,000 Cycles	-20°C ~ 70°C	3,300	85365005	12 V	50 mA	:50mA	:12V	0.002	SMD/SMT	:Side	:SPST-NO	TL1014	-	-	-	-	-	-	SPST	0.25 mm	:Side	:Black
2 TL1014BF160QG SWITCH TACTILE SPST-NO 0.05A 12V E-Switch	9046	¥2.43	-	EG5042TR	3,300	Lead free / RoHS Compliant	SPST-NO	Off-Mom	0.05A @ 12VDC	4.70mm x 3.50mm	Tape & Reel (TR)	Rectangular Button	Surface Mount, Right Angle	0.30mm	160gf	Polyamide (PA46), Nylon 4/6	Gull Wing	Side Actuated	Non-Illuminated	100,000 Cycles	-20°C ~ 70°C	-	-	-	-	-	-	-	-	-	-	-	Board Guide	-	-	-	-	-	-	-	-	-
TL1014AF220QG None Tactile Switches 50mA 12VDC SPST E-Switch	3280	¥1.97	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	3,300	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TL1014BF220QG None E-Switch	10	¥2.24	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	3,300	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TL1014AF160QG(M) P410000 E-SWITCH	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TL1014AF220QG(M) P410001 E-SWITCH	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TL1014BF160QG(M) P410002 E-SWITCH	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TL1014BF220QG(M) P410003 E-SWITCH	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
