SK 481 系列
fischer elektronik GmbH & Co. KGBlack anodized heatsinks for PCB and TO220/TO247 mounting
系列图片（4 张）
文档与媒体
PDF 文档
常见问答
内容由 AI 生成，仅供参考
加载中...
03
SK 481 - 型号列表
共 10 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 热阻 | 长度 | 宽度 | 高度 | 安装类型 | 尺寸/外形 | 连接器颜色 | 材料（通用） | 表面类型 | 位数 | 适用产品/相关产品 | SVHC | 海关税号 | 重量 | 冷却的封装 | 宽度（英寸） | 高度（英寸） | 总宽度 | 总长度 | 外壳尺寸 - 插入（转换自） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 2045 | ¥21.30 | - | 3K/W | 84mm | 30mm | 45mm | Clip | 84 x 30 x 45mm | Black | - | - | - | TO-220, TO-247 | - | - | - | - | - | - | - | - | - |
SK 481/ 37,5/ SA Heatsink SK 481 37.5mm PCB Heat sink 37.5 mm 5.6 K/W black anodised, SK 481/37,5/SA, Fischer Elektronik Fischer Elektronik | 3941 | ¥10.91 | - | 5K/W | 37.5mm | 30mm | 45mm | Clip | 37.5 x 30 x 45mm | Black | Aluminium | black anodised | without | - | - | - | - | - | - | - | - | - | - |
| 4049 | ¥10.85 | - | 5.5K/W | 25mm | 30mm | 45mm | Clip | 25 x 30 x 45mm | Black | - | - | - | TO-220, TO-247 | - | - | - | - | - | - | - | - | - |
SK 481/ 50/ SA Heatsink SK 481 50mm PCB Heat sink 50 mm 4.3 K/W black anodised, SK 481/50/SA, Fischer Elektronik Fischer Elektronik | 3409 | ¥12.62 | - | 4.2K/W | 50mm | 30mm | 45mm | Clip | 50 x 30 x 45mm | Black | Aluminium | black anodised | without | Universal Lock-in Retaining Springs | - | - | - | - | - | - | - | - | - |
 | 155 | ¥27.18 | - | :5.7°C/W | - | - | - | - | - | - | - | - | - | - | :No SVHC (20-Jun-2013) | 76042990 | 0.13 | :TO-3P, TO-218, TO-220, TO-247, TO-248 | :1.18" | :1.77" | :30mm | :3.94" | :45mm |
 | 397 | ¥18.12 | - | :5.7°C/W | - | - | - | - | - | - | - | - | - | - | :No SVHC (20-Jun-2013) | 76042990 | 0.063 | :TO-3P, TO-218, TO-220, TO-247, TO-248 | :1.18" | :1.77" | :30mm | :1.97" | :45mm |
 SK 481/30AL Fischer Elektronik | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
SK 481/65AL Fischer Elektronik | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 SK 481/75/SA Heat sink 75 mm 3.5 K/W black anodised, SK 481/75/SA, Fischer Elektronik Fischer Elektronik | 0 | - | 3.5 K/W | 75 | - | - | - | - | - | Aluminium | black anodised | without | - | - | - | - | - | - | - | - | - | - | |
SK 481/100/SA Heat sink 100 mm 2.8 K/W black anodised, SK 481/100/SA, Fischer Elektronik Fischer Elektronik | 0 | - | 2.8 K/W | 100 | - | - | - | - | - | Aluminium | black anodised | without | - | - | - | - | - | - | - | - | - | - |
第 1 / 1 页
