PN-1321 enclosures, boxes, & case 系列
Bud Industries, Inc.灰色聚碳酸酯或ABS壁挂式防护箱，NEMA 4X密封
Bud Industries, Inc. 的 PN-1321 系列包括壁挂式机箱、盒子和外壳，既坚固又防风雨。这些机箱由灰色聚碳酸酯或ABS制成，提供一种坚固但轻便的选择，用于保护电子元件。它们具有NEMA 4X密封等级，这意味着它们能够防护水射流、灰尘和腐蚀，使其非常适合工业环境、户外安装和海上应用等恶劣环境。
值得注意的是，这些机箱能够很好地应对温度变化。虽然它们提供了对环境因素的 robust 保护，但也有效地管理了热胀冷缩，从而降低了因温度波动而导致损坏的风险。当工程师需要一个能够在恶劣条件下可靠安装且易于安装的密封机箱时，往往会选择这个系列。如果你正在处理涉及户外设备或暴露在雨水、尘土或腐蚀性物质中的机械装置的项目，PN-1321 系列无疑是一个很好的选择。
系列图片（21 张）
文档与媒体
常见问答
PN-1321 enclosures, boxes, & case - 型号列表
共 6 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 产品 | 标准包装数量 | RoHS | 海关税号 | 材料阻燃等级 | 颜色 | 深度 | 高度 | 重量 | 材料（通用） | 厚度 | 壳体颜色 | 面积（长x宽） | 宽度（英寸） | 高度（英寸） | 总宽度 | 尺寸/外形 | 供应商器件封装 | 外部壳体材料 | 外径-未扩张 | 外壳尺寸 - 插入（转换自） | 设计类型 | 产品特性 | 运输信息 | 容器类型 | 额定等级 | 密封等级 | NEMA 机架尺寸 | 安装类型 | 类型 | 制造商全称 | 配置 | 标准包装规格 | 标准 | 宽度 | 长度 | 螺丝材料 | 本体材料 | 外部壳体颜色 | 应用细节 | 防护等级 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Enclosures, Boxes, & Cases 4.53 x 2.56 x 1.58 ABS DK GRAY BODY/CVR BOX ABS 4.53X2.56X1.58" GRY ENCLOSURE, WALL MOUNT,ABS, DARK GRAY Enclosure;Flanged;Polycarbonate,UL94HB;Gray;4.53x2.56x1.57In;NEMA13;PNSeries Bud Industries | 570 | 1: ¥54.40 | Enclosures, Boxes, & Cases | Electrical Boxes | 1 | RoHS Compliant | 39231000 | UL94 HB | Gray | 4.53 in | 1.575" (40.00mm) | 0.31 lb (140.61g) | Plastic, ABS | 0.118" (3.00mm) | :Grey | 11.6" (75cm) | :2.56" | :4.53" | 2.56 in | 4.528" L x 2.559" W (115.01mm x 65.00mm) | :Box | :ABS | 1.57 in | :115.06mm | Cover Included | Card Guides, PCB Supports | Shipped from Digi-Key | Box with Mounting Flange | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | IP 66 | 1, 2, 4, 4X, 12, 13 | PanelMount | Flanged | PNSeries | WithoutKnock-Outs | 1 | - | - | - | - | - | - | - | - | - |
 Enclosures, Boxes, & Cases 4.53 x 2.56 x 1.58 POLYCARBONATE LT GRY BOX POLY 4.53X2.56X1.58" GRY Gray Polycarbonate Wall Mount Box ENCLOSURE, WALL MOUNT, POLYCARBONATE, LT GRAY Enclosure;Flanged;Polycarbonate,UL94HB;Gray;4.53x2.56x1.57In;NEMA13;PNSeries Bud Industries | 11 | 1: ¥72.48 | Enclosures, Boxes, & Cases | Electrical Boxes | 1 | RoHS Compliant | 39231000 | UL94 HB | Gray | 4.53 in | 1.575" (40.00mm) | 0.31 lb (140.61g) | Plastic, Polycarbonate | 0.118" (3.00mm) | :Grey | 11.6" (75cm) | :2.56" | :4.53" | 2.56 in | 4.528" L x 2.559" W (115.01mm x 65.00mm) | :Box | :Polycarbonate | 1.57 in | :115.06mm | Cover Included | Card Guides, PCB Supports | Shipped from Digi-Key | Box with Mounting Flange | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | IP 66 | 1, 2, 4, 4X, 12, 13 | PanelMount | Flanged | PNSeries | WithoutKnock-Outs | - | - | - | - | - | - | - | - | - | - |
 Enclosures, Boxes, & Cases 4.53 X 2.56 X 1.57 BOX ABS 4.53X2.56X1.58" GRY ENCLOSURE; NEMA 4X; SEALED; DARK GRAY; ABS; 4.53 X 2.56 X 1.57 IN. Enclosure Nema 4X Sealed Dark Gray ABS 453 X 256 X 157 Inch ENCLOSURE, JUNCTION BOX, PLASTIC, GRAY Enclosure;Box-Lid;Wallmount;ABS,UL94HB;Gray;4.53x2.56x1.57In;NEMA13;PNSeries Bud Industries | 257 | 1: ¥54.36 | Enclosures, Boxes, & Cases | Electrical Boxes | 1 | Compliant | 85381000 | UL94 HB | Gray | 4.53 in | 1.576" (40.03mm) | 0.25 lb (113.4g) | Plastic, ABS | 0.100" (2.54mm) | :Grey | 11.6" (75cm) | :2.56" | :4.53" | 2.56 in | 4.528" L x 2.559" W (115.01mm x 65.00mm) | :Junction Box | :ABS | 1.57 in | :115mm | Cover Included | Card Guides, PCB Supports | Shipped from Digi-Key | Box | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | IP 66 | 1, 2, 4, 4X, 12, 13 | Wallmount | Box-Lid | PNSeries | WithoutKnock-Outs | - | UL94-HBFlammabilityRating | 2.559in. | 4.528in. | StainlessSteel | HighImpactABS | DarkGray | Mobiledatarecordingandtransmissioninthefieldsofmedical,laboratoryandmeasuringtechnology,storageandsaleslogistics,digitalopenandclosed-loopcontroltechnology | IP66 | -40to+80°C |
 Enclosures, Boxes, & Cases 4.53 X 2.56 X 1.57 BOX POLY 4.53X2.56X1.58" GRY/CLR NEMA 4X SEALED; POLYCARBONATE; LIGHT GRAY BODY; CLEAR COVER; 4.53 X 2.56 X 1.57 Nema 4X Sealed Polycarbonate Light Gray Body Clear Cover 453 X 256 X 157 ENCLOSURE JUNCTION BOX POLYCARBONATE GRY Enclosure;Box-Lid;Polycarbonate,UL94HB;Gray/ClearLid;4.53x2.56x1.57In;PNSeries Bud Industries | 14 | 1: ¥76.84 | Enclosures, Boxes, & Cases | Electrical Boxes | 1 | Compliant | 85381000 | UL94 HB | Gray, Clear Cover/Door | 4.53 in | 1.576" (40.03mm) | 0.25 lb (113.4g) | Plastic, Polycarbonate | 0.100" (2.54mm) | :Grey | 11.6" (75cm) | :2.56" | :4.53" | 2.56 in | 4.528" L x 2.559" W (115.01mm x 65.00mm) | :Junction Box | :Polycarbonate | 1.57 in | :115mm | Cover Included | Card Guides, PCB Supports | Shipped from Digi-Key | Box | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | IP 66 | 1, 2, 4, 4X, 12, 13 | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Enclosures, Boxes, & Cases 4.53 x 2.56 x 1.58 POLYCARBONAT CLR LID BOX POLY 4.53X2.56X1.58" GRY/CLR Light Gray Polycarbonate Wall Mount Box ENCLOSURE, WALL MOUNT, POLYCARBONATE, LT GRAY Enclosure;Flanged;Polycarbonate,UL94HB;Gray/ClearLid;4.53x2.56x1.57In;PNSeries Bud Industries | 127 | 1: ¥60.656 | Enclosures, Boxes, & Cases | Electrical Boxes | 1 | RoHS Compliant | 39231000 | UL94 HB | Gray, Clear Cover/Door | 4.53 in | 1.575" (40.00mm) | 0.31 lb (140.61g) | Plastic, Polycarbonate | 0.118" (3.00mm) | :Grey | 11.6" (75cm) | :2.56" | :4.53" | 2.56 in | 4.528" L x 2.559" W (115.01mm x 65.00mm) | :Box | :Polycarbonate | 1.57 in | :115.06mm | Cover Included | Card Guides, PCB Supports | Shipped from Digi-Key | Box with Mounting Flange | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | IP 66 | 1, 2, 4, 4X, 12, 13 | PanelMount | Flanged | PNSeries | WithoutKnock-Outs | - | - | - | - | - | - | - | - | - | - |
Enclosures, Boxes, & Cases 4.53 X 2.56 X 1.57 BOX POLY 4.53X2.56X1.58" GRY NEMA 4X SEALED POLYCAR. ENCLOSURE;LT.GRAY BODY & COVER;4.53L X 2.56W X 1.57H IN. Access Nema 4X Sealed Polycar Enclosure LT Gray Body Cover 453L X 256W X 157H Inch ENCLOSURE JUNCTION BOX POLYCARBONATE GRY Enclosure;Box-Lid;Wallmount;Polycarbonate,UL94HB;Gray;4.53x2.56x1.57In;NEMA13 Bud Industries | 34 | 1: ¥81.54 | Enclosures, Boxes, & Cases | Electrical Boxes | 1 | Compliant | 85381000 | UL94 HB | Gray | 4.53 in | 1.576" (40.03mm) | 0.25 lb (113.4g) | Plastic, Polycarbonate | 0.100" (2.54mm) | :Grey | 11.6" (75cm) | :2.56" | :4.53" | 2.56 in | 4.528" L x 2.559" W (115.01mm x 65.00mm) | :Junction Box | :Polycarbonate | 1.57 in | :115mm | Cover Included | Card Guides, PCB Supports | Shipped from Digi-Key | Box | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | IP 66 | 1, 2, 4, 4X, 12, 13 | Wallmount | Box-Lid | PNSeries | WithoutKnock-Outs | 1 | UL94V-2FlammabilityRating | 2.559in. | 4.528in. | StainlessSteel | Polycarbonate | LightGray | Mobiledatarecordingandtransmissioninthefieldsofmedical,laboratoryandmeasuringtechnology,storageandsaleslogistics,digitalopenandclosed-loopcontroltechnology | IP66 | -40to+120°C |
