PN-1320 enclosures, boxes, & case 系列
Bud Industries, Inc.壁挂或接线盒安装用的紧凑型聚碳酸酯和ABS外壳
Bud Industries, Inc. 的 PN-1320 系列包括紧凑型聚碳酸酯和ABS外壳，适用于墙装或接线盒安装。这些外壳适用于工业和商业环境中空间有限的情况，能够有效保护电子元件。它们有多种尺寸可供选择，因此具有很高的灵活性，能满足不同的应用需求。
如果您正在处理涉及小型电子设备或传感器的项目，这些外壳能提供简洁且坚固的解决方案。值得一提的是，它们的耐用性很强，能够抵抗紫外线、化学物质和冲击，因此适合户外或恶劣室内环境使用。当工程师需要一个轻巧但坚固的外壳，并且易于安装且不需要复杂安装工具时，往往会选用这个系列。
另一个实用的好处是它们的美观性；透明聚碳酸酯选项可以让内部组件一目了然，这对于维护或故障排除特别有用。此外，ABS型号还具有出色的电气绝缘性能，使其成为需要保护和电气隔离的项目的理想选择。
总体而言，PN-1320 系列在功能、易用性和耐用性方面达到了平衡，是许多工程师寻找可靠外壳时的首选。
系列图片（20 张）
文档与媒体
常见问答
PN-1320 enclosures, boxes, & case - 型号列表
共 8 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 产品 | 材料阻燃等级 | 颜色 | 深度 | 材料（通用） | 总宽度 | 外径-未扩张 | 密封等级 | NEMA 机架尺寸 | 标准包装数量 | RoHS | 高度 | 重量 | 厚度 | 壳体颜色 | 面积（长x宽） | 安装类型 | 尺寸/外形 | 类型 | 设计类型 | 产品特性 | 制造商全称 | 配置 | 运输信息 | 容器类型 | 额定等级 | 标准包装规格 | 海关税号 | 宽度（英寸） | 高度（英寸） | 供应商器件封装 | 外部壳体材料 | 外壳尺寸 - 插入（转换自） | 标准 | 宽度 | 长度 | 本体材料 | 外部壳体颜色 | 防护等级 | 工作温度 | 螺丝材料 | 应用细节 | 工厂包装数量 | 认证机构 | 导线线规 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 10 | 67: ¥70.38 | Enclosures, Boxes, & Cases | Electrical Boxes | UL 94 HB | Gray | 2.52 in | Acrylonitrile Butadiene Styrene (ABS) | 2.28 in | 1.38 in | IP 66 | 1, 2, 4, 4X, 12, 13 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 | - | - |
 Enclosures, Boxes, & Cases 2.52 x 2.28 x 1.38 POLYCARBONATE LT GRY BOX POLY 2.52X2.28X1.38" GRY ENCLOSURE, WALL MOUNT, POLYCARBONATE, LT GRAY Enclosure;Flanged;Polycarbonate,UL94HB;Gray;2.56x2.28x1.38In;NEMA13;PNSeries Bud Industries | 22 | 1: ¥48.416 | Enclosures, Boxes, & Cases | Electrical Boxes | UL94 HB | Gray | 2.52 in | Plastic, Polycarbonate | 2.28 in | 1.38 in | IP 66 | 1, 2, 4, 4X, 12, 13 | 1 | RoHS Compliant | 1.378" (35.00mm) | 0.22 lb (99.79g) | 0.118" (3.00mm) | :Grey | 5.75" (37.1cm) | PanelMount | 2.520" L x 2.283" W (64.01mm x 57.99mm) | Flanged | Cover Included | Card Guides, PCB Supports | PNSeries | WithoutKnock-Outs | Shipped from Digi-Key | Box with Mounting Flange | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | 1 | 39231000 | :2.28" | :2.52" | :Box | :Polycarbonate | :64.01mm | - | - | - | - | - | - | - | - | - | - | - | - |
 Enclosures, Boxes, & Cases 2.56 X 2.28 X 1.38 BOX POLY 2.52X2.28X1.38" GRY NEMA 4X SEALED POLYCAR. ENCLOSURE;LT.GRAY BODY & COVER;2.56L X 2.28W X 1.38H IN. ENCLOSURE JUNCTION BOX POLYCARBONATE GRY Enclosure;Box-Lid;Wallmount;Polycarbonate,UL94HB;Gray;2.56x2.28x1.38In;NEMA13 Bud Industries | 1490 | 1: ¥48.416 | Enclosures, Boxes, & Cases | Electrical Boxes | UL94 HB | Gray | 2.52 in | Plastic, Polycarbonate | 2.28 in | 1.38 in | IP 66 | 1, 2, 4, 4X, 12, 13 | 1 | Compliant | 1.379" (35.03mm) | 0.156 lb (70.76g) | 0.100" (2.54mm) | :Grey | 5.75" (37.1cm) | Wallmount | 2.520" L x 2.283" W (64.01mm x 57.99mm) | Box-Lid | Cover Included | Card Guides, PCB Supports | PNSeries | WithoutKnock-Outs | Shipped from Digi-Key | Box | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | 1 | 85381000 | :2.28" | :2.56" | :Junction Box | :Polycarbonate | :65mm | UL94V-2FlammabilityRating | 2.283in. | 2.520in. | Polycarbonate | LightGray | IP66 | -40to+120°C | StainlessSteel | Mobiledatarecordingandtransmissioninthefieldsofmedical,laboratoryandmeasuringtechnology,storageandsaleslogistics,digitalopenandclosed-loopcontroltechnology | - | - | - |
 Enclosures, Boxes, & Cases 2.52 x 2.28 x 1.38 POLYCARBONAT CLR LID BOX POLY 2.52X2.28X1.38" GRY/CLR Gray Polycarbonate Wall Mount Box ENCLOSURE, WALL MOUNT, POLYCARBONATE, LT GRAY Enclosure;Flanged;Polycarbonate,UL94HB;Gray/ClearLid;2.56x2.28x1.38In;PNSeries Bud Industries | 28 | 1: ¥56.644 | Enclosures, Boxes, & Cases | Electrical Boxes | UL94 HB | Gray, Clear Cover/Door | 2.52 in | Plastic, Polycarbonate | 2.28 in | 1.38 in | IP 66 | 1, 2, 4, 4X, 12, 13 | 1 | RoHS Compliant | 1.378" (35.00mm) | 0.22 lb (99.79g) | 0.118" (3.00mm) | :Grey | 5.75" (37.1cm) | PanelMount | 2.520" L x 2.283" W (64.01mm x 57.99mm) | Flanged | Cover Included | Card Guides, PCB Supports | PNSeries | WithoutKnock-Outs | Shipped from Digi-Key | Box with Mounting Flange | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | - | 39231000 | :2.28" | :2.52" | :Box | :Polycarbonate | :64.01mm | - | - | - | - | - | - | - | - | - | - | - | - |
 Enclosures, Boxes, & Cases 2.56 X 2.28 X 1.38 BOX ABS 2.52X2.28X1.38" GRY ENCLOSURE; NEMA 4X SEALED; DARK GRAY ABS COVER AND BODY; 2.56L X 2.28W X 1.38H ENCLOSURE, JUNCTION BOX, PLASTIC, GRAY Enclosure;Box-Lid;Wallmount;ABS,UL94HB;Gray;2.56x2.28x1.38In;NEMA13;PNSeries Bud Industries | 80 | 1: ¥49.0217 | Enclosures, Boxes, & Cases | Electrical Boxes | UL94 HB | Gray | 2.52 in | Plastic, ABS | 2.28 in | 1.38 in | IP 66 | 1, 2, 4, 4X, 12, 13 | 1 | Compliant | 1.379" (35.03mm) | 0.156 lb (70.76g) | 0.100" (2.54mm) | :Grey | 5.75" (37.1cm) | Wallmount | 2.520" L x 2.283" W (64.01mm x 57.99mm) | Box-Lid | Cover Included | Card Guides, PCB Supports | PNSeries | WithoutKnock-Outs | Shipped from Digi-Key | Box | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | 1 | 85381000 | :2.28" | :2.56" | :Junction Box | :ABS | :65mm | UL94-HBFlammabilityRating | 2.283in. | 2.520in. | HighImpactABS | DarkGray | IP66 | -40to+80°C | StainlessSteel | Mobiledatarecordingandtransmissioninthefieldsofmedical,laboratoryandmeasuringtechnology,storageandsaleslogistics,digitalopenandclosed-loopcontroltechnology | - | - | - |
 Enclosures, Boxes, & Cases 2.52 x 2.28 x 1.38 ABS DK GRAY BODY/CVR BOX ABS 2.52X2.28X1.38" GRY ENCLOSURE, WALL MOUNT,ABS, DARK GRAY Enclosure;Flanged;Polycarbonate,UL94HB;Gray;2.56x2.28x1.38In;NEMA13;PNSeries Bud Industries | 190 | 1: ¥40.80 | Enclosures, Boxes, & Cases | Electrical Boxes | UL94 HB | Gray | 2.52 in | Plastic, ABS | 2.28 in | 1.38 in | IP 66 | 1, 2, 4, 4X, 12, 13 | 1 | RoHS Compliant | 1.378" (35.00mm) | 0.22 lb (99.79g) | 0.118" (3.00mm) | :Grey | 5.75" (37.1cm) | PanelMount | 2.520" L x 2.283" W (64.01mm x 57.99mm) | Flanged | Cover Included | Card Guides, PCB Supports | PNSeries | WithoutKnock-Outs | Shipped from Digi-Key | Box with Mounting Flange | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | 1 | 39231000 | :2.28" | :2.52" | :Box | :ABS | :64.01mm | - | - | - | - | - | - | - | - | - | - | - | - |
 Enclosures, Boxes, & Cases 2.56 X 2.28 X 1.38 BOX POLY 2.52X2.28X1.38" GRY/CLR NEMA 4X SEALED POLYCAR.ENCLOSURE;LT.GRAY BODY;CLEAR COVER;2.56L X 2.28W X 1.38H Enclosure;Box-Lid;Polycarbonate,UL94HB;Gray/ClearLid;2.56x2.28x1.38In;PNSeries Bud Industries | 4990 | 1: ¥50.32 | Enclosures, Boxes, & Cases | Electrical Boxes | UL94 HB | Gray, Clear Cover/Door | 2.52 in | Plastic, Polycarbonate | 2.28 in | 1.38 in | IP 66 | 1, 2, 4, 4X, 12, 13 | 1 | Compliant | 1.379" (35.03mm) | 0.16 lb (72.57g) | 0.100" (2.54mm) | LightGray | 5.75" (37.1cm) | Wallmount | 2.520" L x 2.283" W (64.01mm x 57.99mm) | Box-Lid | Cover Included | Card Guides, PCB Supports | PNSeries | WithoutKnock-Outs | Shipped from Digi-Key | Box | IP65, IP66, IP67, NEMA 1,2,4,4X,12,13, UL-508 | 1 | - | - | - | - | - | - | ULListed | 2.283in. | 2.52in. | Polycarbonate | Clear | IP66 | -40to+120 | - | - | - | 4X | TransparentCover |
BUD INDUSTRIES | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
