PKM33EP speakers & transducer 系列

External drive pin type piezoelectric buzzers for sound applications

文档与媒体

S0040E.pdf

p37e.pdf

Piezoelectric%20Sound%20Components.pdf

CatalogAction.do?sHinnm=?&nbsp&sNHinnm=PKM33EPH1202C&sNhin_key=PKM33EPH1202C&sLang=en&sParam=PKM33

CatalogAction.do?sHinnm=?&nbsp&sNHinnm=PKM33EPH1201C&sNhin_key=PKM33EPH1201C&sLang=en&sParam=PKM33

L0475E.pdf

内容由 AI 生成，仅供参考

加载中...

共 2 个型号

制造商零件编号	库存	价格	产品类别	最小起订量	产品	单位包装	标准包装数量	工厂包装数量	RoHS	频率	输入类型	电压范围	工作模式	额定电压	驱动电路	最小供电电压	电容 @ 频率	声压级 (SPL)	形状	高度	直径	包装方式	端接方式	安装类型	尺寸/外形	端接样式	类型	系列	可清洗	技术	机械寿命	工作温度	其他名称
PKM33EPH1202C Speakers & Transducers 40.0nF +/-30% Sound Component PKM33EPH1202C BUZZER PIEZO Murata Electronics	1195	¥17.16	Speakers & Transducers	60	Speakers	60	60	60	RoHS Compliant	1.2 kHz	peak-peak Signal	40V (Max)	Continuous	30Vp-p	Transducer, Externally Driven	40 V	40000pF @ 120Hz	68 dB	Round	7.5 mm	33 mm	Bulk	PC Pins	Through Hole	Circular - 33.00mm Dia x 8.00mm H	Solder Pin	Piezoelectric	PKM	No	Piezo	End of Life: Scheduled for obsolescence and will be discontinued by the manufacturer.	- 20 C to + 70 C	-
4 PKM33EPH1201C Speakers & Transducers 1.2KHz External Drv Pin Type PKM33EPH1201C BUZZER PIEZO 40VP-P 1.2KHZ PC Murata Electronics	180	¥10.44	Speakers & Transducers	300	Speakers	300	600	300	RoHS Compliant	1.2 kHz	peak-peak Signal	40V (Max)	Continuous	30Vp-p	Transducer, Externally Driven	40 V	40000pF @ 120Hz	68 dB	Round	7.5 mm	33 mm	Bulk	PC Pins	Through Hole	Circular - 33.00mm Dia x 8.00mm H	Solder Pin	Piezoelectric	PKM	No	Piezo	End of Life: Scheduled for obsolescence and will be discontinued by the manufacturer.	- 20 C to + 70 C	490-4687

第 1 / 1 页
