OCP-PCT optoisolators - transistor, photovoltaic output 系列
Lumex, Inc.高压晶体管输出光耦合器，用于电气隔离
Lumex, Inc. 的OCP-PCT 系列由高电压晶体管输出光耦合器组成，适用于各种工业和汽车应用中的电气隔离。这些器件采用光电输出晶体管，在输入电路和输出电路之间实现电隔离，这对于防止电气干扰和确保安全至关重要。
如果您正在设计需要高压隔离的电源系统，那么这些光耦合器是一个很好的选择。它们能够处理高达500V的电压，使其非常适合用于电力分配系统、电机驱动和其他高压环境中的开关和控制电路。值得一提的是，它们对电磁干扰（EMI）和射频干扰（RFI）具有较强的抵抗力，即使在嘈杂的工业环境中也能保持可靠性。
当工程师们需要一个紧凑的解决方案来提供强大的电气隔离而不牺牲性能时，往往会选用这一系列产品。OCP-PCT 系列在隔离强度和信号完整性之间提供了良好的平衡，这一点在信号质量可能因高压尖峰或电磁干扰而受损的应用中尤为重要。总体而言，这些光耦合器是提高设计安全性和可靠性的可靠选择。
系列图片（16 张）
文档与媒体
常见问答
OCP-PCT optoisolators - transistor, photovoltaic output - 型号列表
共 13 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 标准包装数量 | RoHS | 输入类型 | 输出类型 | 供电电压 | 通道数量 | 隔离电压 | Vce饱和电压（最大） | 最小输入电压 | 上升/下降时间（典型） | 输出电压（最大） | 输出电流/通道 | 电流传输比（最大） | 电流传输比（最小） | 直流正向电流（If）（最大） | 平均整流电流（每二极管） | 包装方式 | 安装类型 | 封装形式 | 供应商器件封装 | 工作温度 | 其他名称 | 输出端 | 机械寿命 | 制造商全称 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Transistor Output Optocouplers Photocoupler 1.2Vf 200mW, 200-400 CTR OPTOCOUPLER TRANS 5KVRMS 4DIP OPTOISOLATR 5KV TRANSISTOR 4-DIP Lumex | 10 | 50000: ¥0.7684 | Transistor Output Optocouplers | 100 | RoHS Compliant | DC | Transistor | 1.2V | 1 Channel | 5000 Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Bulk | Through Hole | 4-DIP (0.300", 7.62mm) | 4-DIP | -30°C ~ 100°C | - | NPN Phototransistor | Obsolete | - |
 Transistor Output Optocouplers DC 60/600 CTR 1 Circuit 1.2Vf SMT OPTOCOUPLER TRANS 5KVRMS 4SMD OPTOISOLATR 5KV TRANSISTOR 4-SMD Lumex | 10 | 46500: ¥0.816 | Transistor Output Optocouplers | 2,000 | RoHS Compliant | DC | Transistor | 1.2V | 1 Channel | 5000 Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Tape & Reel (TR) | Surface Mount | 4-SMD, Gull Wing | 4-SMD | -30°C ~ 100°C | 67-1613-2 | NPN Phototransistor | - | Lumex |
Transistor Output Optocouplers DC 60/600 CTR 1 Circuit 1.2Vf SMT OPTOCOUPLER TRANS 5KVRMS 6SMD OPTOISO 5KV TRANS W/BASE 6SMD Lumex | 10 | 50000: ¥1.1288 | Transistor Output Optocouplers | 1,000 | RoHS Compliant | DC | Transistor with Base | 1.2V | 1 Channel | 5000 Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Tape & Reel (TR) | Surface Mount | 6-SMD, Gull Wing | 6-SMD | -30°C ~ 100°C | 67-1615-2 | NPN Phototransistor | Obsolete | - |
 OPTOCOUPLER 1-CH W/BASE 6-DIP OPTOCOUPLER TRANS 5KVRMS 6DIP OPTOISO 5KV TRANS W/BASE 6DIP Lumex Opto/Components Inc | 10 | 50050: ¥0.884 | - | 65 | Lead free / RoHS Compliant | DC | Transistor with Base | 1.2V | 1 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Tube | Through Hole | 6-DIP (0.300", 7.62mm) | 6-DIP | -30°C ~ 100°C | 67-1563-5 | - | - | - |
 OPTOCOUPLER 1-CH TRANS OUT 4-DIP OPTOCOUPLER TRANS 5KVRMS 4DIP OPTOISOLATR 5KV TRANSISTOR 4-DIP Lumex Opto/Components Inc | 10 | 50000: ¥0.7684 | - | 100 | Lead free / RoHS Compliant | DC | Transistor | 1.2V | 1 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Tube | Through Hole | 4-DIP (0.300", 7.62mm) | 4-DIP | -30°C ~ 100°C | 67-1560-5 | - | - | - |
OPTOCOUPLER 1-CH AC-IN 4-DIP OPTOCOUPLER TRANS 5KVRMS 4DIP OPTOISOLATR 5KV TRANSISTOR 4-DIP Lumex Opto/Components Inc | 10 | 50000: ¥1.156 | - | 100 | Lead free / RoHS Compliant | AC, DC | Transistor | 1.2V | 1 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 1mA | 60% @ 1mA | 50mA | ±50mA | Tube | Through Hole | 4-DIP (0.300", 7.62mm) | 4-DIP | -30°C ~ 100°C | 67-1564-5 | - | - | - |
 OPTOCOUPLER 1-CH AC-IN SMD OPTOCOUPLER TRANS 5KVRMS 4SMD OPTOISOLATR 5KV TRANSISTOR 4-SMD Lumex Opto/Components Inc | 10 | 50000: ¥1.7884 | - | 2,000 | Lead free / RoHS Compliant | AC, DC | Transistor | 1.2V | 1 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 1mA | 60% @ 1mA | 50mA | ±50mA | Tape & Reel (TR) | Surface Mount | 4-SMD, Gull Wing | 4-SMD | -30°C ~ 100°C | 67-1616-2 | - | - | - |
 OPTOCOUPLER 2-CH TRANS OUT 8DIP OPTOCOUPLER TRANS 5KVRMS 8DIP OPTOISOLATOR 5KV 2CH TRANS 8-DIP Lumex Opto/Components Inc | 10 | 60000: ¥2.0196 | - | 48 | Lead free / RoHS Compliant | DC | Transistor | 1.2V | 2 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Tube | Through Hole | 8-DIP (0.300", 7.62mm) | 8-DIP | -30°C ~ 100°C | 67-1561-5 | - | - | - |
 OPTOCOUPLER 2-CH TRANS OUT SMD OPTOCOUPLER TRANS 5KVRMS 8SMD OPTOISOLATOR 5KV 2CH TRANS 8-DIP Lumex Opto/Components Inc | 10 | 50000: ¥2.856 | - | 1,000 | Lead free / RoHS Compliant | DC | Transistor | 1.2V | 2 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Tape & Reel (TR) | Surface Mount | 8-SMD, Gull Wing | 8-DIP | -30°C ~ 100°C | 67-1614-2 | - | - | - |
 OPTOCOUPLER 4-CH TRANS OUT 16DIP OPTOCOUPLER TRANS 5KVRMS 16DIP OPTOISOLTR 5KV 4CH TRANS 16-DIP Lumex Opto/Components Inc | 10 | 60000: ¥4.7192 | - | 24 | Lead free / RoHS Compliant | DC | Transistor | 1.2V | 4 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Tube | Through Hole | 16-DIP (0.300", 7.62mm) | 16-DIP | -30°C ~ 100°C | 67-1562-5 | - | - | - |
 OPTOCOUPLER 4-CH TRANS OUT SMD OPTOCOUPLER TRANS 5KVRMS 16SMD OPTOISOLTR 5KV 4CH TRANS 16-SMD Lumex Opto/Components Inc | 10 | 50016: ¥4.7192 | - | 24 | Lead free / RoHS Compliant | DC | Transistor | 1.2V | 4 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 2mA | 60% @ 2mA | 50mA | 50mA | Tube | Surface Mount | 16-SMD, Gull Wing | 16-SMD | -30°C ~ 100°C | 67-1618-5 | - | - | - |
OPTOCOUPLER 4-CH AC-IN 16 DIP OPTOCOUPLER TRANS 5KVRMS 16DIP OPTOISOLTR 5KV 4CH TRANS 16-DIP Lumex Opto/Components Inc | 10 | 50016: ¥6.6572 | - | 24 | Lead free / RoHS Compliant | AC, DC | Transistor | 1.2V | 4 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 1mA | 60% @ 1mA | 50mA | ±50mA | Tube | Through Hole | 16-DIP (0.300", 7.62mm) | 16-DIP | -30°C ~ 100°C | 67-1565-5 | - | - | - |
OPTOCOUPLER 4-CH AC-IN SMD OPTOCOUPLER TRANS 5KVRMS 16SMD OPTOISOLTR 5KV 4CH TRANS 16-SMD Lumex Opto/Components Inc | 10 | 50016: ¥6.6572 | - | 24 | Lead free / RoHS Compliant | AC, DC | Transistor | 1.2V | 4 | 5000Vrms | 300mV | 60V | 5µs, 4µs | 60V | 50mA | 600% @ 1mA | 60% @ 1mA | 50mA | ±50mA | Tube | Surface Mount | 16-SMD, Gull Wing | 16-SMD | -30°C ~ 100°C | 67-1619-5 | - | - | - |
