LXC120 power supplies - external/internal (off-board)

LXC120 power supplies - external/internal (off-board) 系列

120W LED电源，具有AC/DC转换功能，满足各种电压和电流需求

Excelsys Technologies 的 LXC120 系列为需要最高 120W 功率的 LED 照明应用提供了灵活的解决方案。这些电源供应器有外部和内部两种配置，工程师可以根据系统设计需求进行选择。如果您正在从事需要精确控制电压和电流的 LED 项目，这些电源供应器非常适合。它们支持广泛的输入电压范围，并能输出各种电压和电流组合，适用于多种 LED 阵列。

值得一提的是其模块化设计，这使得它们很容易集成到现有系统中。这对于您在升级或扩展照明设置时无需彻底改造整个电源供应基础设施非常有用。此外，LXC120 系列以其可靠性和效率著称，在严苛环境下的长期运行至关重要。当工程师需要为他们的 LED 项目寻找一个坚固且适应性强的电源解决方案时，往往会选择这一系列。

系列图片（1 张）

文档与媒体

PDF 文档

Complete-LED-Brochure.pdf

PDF 文档

LXC120-01-07-2011.pdf

常见问答

内容由 AI 生成，仅供参考

加载中...

LXC120 power supplies - external/internal (off-board) - 型号列表

共 13 个型号

制造商零件编号	库存	价格	产品类别	标准包装数量	认证机构	效率	功率（瓦）	输出电流	输出数量	隔离电压	最小输入电压	重量	安装类型	尺寸/外形	端接样式	类型	产品特性	拓扑	额定等级	工作温度
LXC120-0350SW POWER SUPPLY LED 120W 350MA LED SUPPLY CC AC/DC 206-343V Excelsys Technologies Ltd	40	1: ¥563.176	-	1	CE, cULus, EN	92%	120W	350mA	1	3.75kV (3750V)	206 ~ 343 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-0450SW POWER SUPPLY LED 120W 450MA LED SUPPLY CC AC/DC 160-266V Excelsys Technologies Ltd	10	1: ¥650.08	-	1	CE, cULus, EN	92%	120W	450mA	1	3.75kV (3750V)	160 ~ 266 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-0700SW POWER SUPPLY LED 120W 700MA LED SUPPLY CC AC/DC 103-171V Excelsys Technologies Ltd	36	1: ¥563.176	-	1	CE, cULus, EN	92%	120W	700mA	1	3.75kV (3750V)	103 ~ 171 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-1050SW POWER SUPPLY LED 120W 1050MA LED SUPPLY CC AC/DC 68-114V Excelsys Technologies Ltd	10	1: ¥563.176	-	1	CE, cULus, EN	91%	120W	1.05A	1	3.75kV (3750V)	68 ~ 114 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-1400SW POWER SUPPLY LED 120W 1400MA LED SUPPLY CC AC/DC 52-86V 1.4A Excelsys Technologies Ltd	10	1: ¥563.176	-	1	CE, cULus, EN	91%	120W	1.4A	1	3.75kV (3750V)	52 ~ 86 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-3500SW POWER SUPPLY LED 120W 3500MA LED SUPPLY CC AC/DC 20-34V 3.5A Excelsys Technologies Ltd	10	1: ¥563.176	-	1	CE, cULus, EN	90.5%	120W	3.5A	1	3.75kV (3750V)	20 ~ 34 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-1750SW POWER SUPPLY LED 120W 1750MA LED SUPPLY CC AC/DC 41-68V 1.75A Excelsys Technologies Ltd	10	10: ¥650.0596	-	1	CE, cULus, EN	91%	120W	1.75A	1	3.75kV (3750V)	41 ~ 68 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-2100SW POWER SUPPLY LED 120W 2100MA LED SUPPLY CC AC/DC 34-57V 2.1A Excelsys Technologies Ltd	10	10: ¥650.0596	-	1	CE, cULus, EN	91%	120W	2.1A	1	3.75kV (3750V)	34 ~ 57 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-2450SW POWER SUPPLY LED 120W 2450MA LED SUPPLY CC AC/DC 29-49V 2.45A Excelsys Technologies Ltd	10	10: ¥650.0596	-	1	CE, cULus, EN	91%	120W	2.45A	1	3.75kV (3750V)	29 ~ 49 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-2800SW POWER SUPPLY LED 120W 2800MA LED SUPPLY CC AC/DC 26-43V 2.8A Excelsys Technologies Ltd	10	10: ¥650.0596	-	1	CE, cULus, EN	91%	120W	2.8A	1	3.75kV (3750V)	26 ~ 43 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-3150SW POWER SUPPLY LED 120W 3150MA LED SUPPLY CC AC/DC 23-38V 3.15A Excelsys Technologies Ltd	10	10: ¥650.0596	-	1	CE, cULus, EN	90.5%	120W	3.15A	1	3.75kV (3750V)	23 ~ 38 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-4200SW POWER SUPPLY LED 120W 4200MA LED SUPPLY CC AC/DC 17-28V 4.2A Excelsys Technologies Ltd	10	10: ¥650.0596	-	1	CE, cULus, EN	90.5%	120W	4.2A	1	3.75kV (3750V)	17 ~ 28 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
LXC120-4900SW POWER SUPPLY LED 120W 4900MA LED SUPPLY CC AC/DC 14-24V 4.9A Excelsys Technologies Ltd	10	10: ¥650.0596	-	1	CE, cULus, EN	90.5%	120W	4.9A	1	3.75kV (3750V)	14 ~ 24 V	2.3 lbs (1kg)	Chassis Mount	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)	Wire Leads	Constant Current	OVP, SCP	AC DC Converter	IP67	-35°C ~ 70°C
