G6H-2F-TR signal relays, up to 2 amp 系列
Omron CorporationSurface mount low-signal DPDT relays for telecom and PCB applications
系列图片（7 张）
常见问答
G6H-2F-TR signal relays, up to 2 amp - 型号列表
共 14 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 包装方式 | 标准包装数量 | 电流 | 线圈类型 | 线圈功率 | 线圈电流 | 释放时间 | 线圈电阻 | 供电电压 | 开关电压 | Vgs(th)（最大）@ Id | 开关电流 | 最小负载要求 | 集电极-发射极饱和电压（最大）@ Vge, Ic | 触点额定电流 | 每极负载侧连接方式 | 触点形式 | 安装类型 | 触头材料 | 端接样式 | 典型触点布局 | 类型 | 功能 | 继电器类型 | 卡标准 | 额定寿命 | 动作时间 | 工作温度 | 交货时间 | 子类别 | 行业别名 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 G6H-2F-TR DC48 Low Signal Relays - PCB SURFACE MOUNT RELAY Tape & Reel RELAY TELECOM DPDT 1A 48V Relay Low-Signal Surface Mount Coil Voltage: 48 Vdc Configuration: DPDT Omron Electronics | 0 | - | Tape & Reel (TR) | 1,000 | 1 Amp | Non Latching | 300 mW | 5.8mA | 2ms | 8.23 kOhms | 48VDC | 125VAC, 110VDC - Max | 4.8 VDC | 62.5VA/ 33W | 10A @ 10mVDC | 36 VDC | 1A | 0.3A @ 125VAC, 1A @ 30VDC | DPDT (2 Form C) | Surface Mount | Silver (Ag), Gold (Au) | Gull Wing | 2C DPDT | Relays | Single Side Stable | Telecom | Signal Relay | 200,000 ops | 3ms | -40°C ~ 70°C | - | - | - | |
G6H-2F-TR DC3 Low Signal Relays - PCB Surface Mount Relay Tape & Reel RELAY TELECOM DPDT 1A 3V Surface Mount Tape&Reel Relay Omron Electronics | 0 | - | Tape & Reel (TR) | 1,000 | 1 Amp | Non Latching | 140 mW | 46.7mA | 2ms | 64.3 Ohms | 3VDC | 125VAC, 110VDC - Max | 0.3 VDC | 62.5VA/ 33W | 10A @ 10mVDC | 2.25 VDC | 1A | 0.3A @ 125VAC, 1A @ 30VDC | DPDT (2 Form C) | Surface Mount | Silver (Ag), Gold (Au) | Gull Wing | 2C DPDT | Relays | Single Side Stable | Telecom | Signal Relay | 200,000 ops | 3ms | -40°C ~ 70°C | - | - | - | |
 G6H-2F-TR DC24 Low Signal Relays - PCB SURFACE MOUNT RELAY Tape & Reel RELAY TELECOM DPDT 1A 24V Relay Low-Signal Surface Mount Coil Voltage: 24 Vdc Configuration: DPDT Omron Electronics | 0 | - | Tape & Reel (TR) | 1,000 | 1 Amp | Non Latching | 200 mW | 8.3mA | 2ms | 2.88 kOhms | 24VDC | 125VAC, 110VDC - Max | 2.4 VDC | 62.5VA/ 33W | 10A @ 10mVDC | 18 VDC | 1A | 0.3A @ 125VAC, 1A @ 30VDC | DPDT (2 Form C) | Surface Mount | Silver (Ag), Gold (Au) | Gull Wing | 2C DPDT | Relays | Single Side Stable | Telecom | Signal Relay | 200,000 ops | 3ms | -40°C ~ 70°C | - | - | - | |
G6H-2F-TR DC9 Low Signal Relays - PCB SURFACE MOUNT RELAY Tape & Reel RELAY TELECOM DPDT 1A 9V Relay Low-Signal Surface Mount Coil Voltage: 9 Vdc Configuration: DPDT Omron Electronics | 0 | - | Tape & Reel (TR) | 1,000 | 1 Amp | Non Latching | 140 mW | 15.5mA | 2ms | 579 Ohms | 9VDC | 125VAC, 110VDC - Max | 0.9 VDC | 62.5VA/ 33W | 10A @ 10mVDC | 6.75 VDC | 1A | 0.3A @ 125VAC, 1A @ 30VDC | DPDT (2 Form C) | Surface Mount | Silver (Ag), Gold (Au) | Gull Wing | 2C DPDT | Relays | Single Side Stable | Telecom | Signal Relay | 200,000 ops | 3ms | -40°C ~ 70°C | - | - | - | |
G6H-2F-TR DC6 Low Signal Relays - PCB SURFACE MOUNT RELAY Tape & Reel RELAY TELECOM DPDT 1A 6V Relay Low-Signal Surface Mount Coil Voltage: 6 Vdc Configuration: DPDT Omron Electronics | 0 | - | Tape & Reel (TR) | 1,000 | 1 Amp | Non Latching | 140 mW | 23.3mA | 2ms | 257 Ohms | 6VDC | 125VAC, 110VDC - Max | 0.6 VDC | 62.5VA/ 33W | 10A @ 10mVDC | 4.2 VDC | 1A | 0.3A @ 125VAC, 1A @ 30VDC | DPDT (2 Form C) | Surface Mount | Silver (Ag), Gold (Au) | Gull Wing | 2C DPDT | Relays | Single Side Stable | Telecom | Signal Relay | 200,000 ops | 3ms | -40°C ~ 70°C | - | - | - | |
G6H-2F-TR DC12 Low Signal Relays - PCB SURFACE MOUNT RELAY Tape & Reel RELAY TELECOM DPDT 1A 12V Relay Low-Signal Surface Mount Coil Voltage: 12 Vdc Configuration: DPDT Omron Electronics | 0 | - | Tape & Reel (TR) | 500 | 1 Amp | Non Latching | 140 mW | 11.7mA | 2ms | 1.03 kOhms | 12VDC | 125VAC, 110VDC - Max | 1.2 VDC | 62.5VA/ 33W | 10A @ 10mVDC | 9 VDC | 1A | 0.3A @ 125VAC, 1A @ 30VDC | DPDT (2 Form C) | Surface Mount | Silver (Ag), Gold (Au) | Gull Wing | 2C DPDT | Relays | Single Side Stable | Telecom | Signal Relay | 200,000 ops | 3ms | -40°C ~ 70°C | - | - | - | |
G6H-2F-TR DC5 RELAY TELECOM DPDT 1A 5V 欧姆龙(OMRON) 功率继电器 Relay Low-Signal Surface Mount Coil Voltage: 5 Vdc Configuration: DPDT Omron Electronics Inc-EMC Div | 0 | - | Tape & Reel (TR) | 1,000 | 1 Amp | Non Latching | 140 mW | 28.1mA | 2ms | 178 Ohms | 5VDC | 125VAC, 110VDC - Max | 0.5 VDC | 62.5VA/ 33W | 10A @ 10mVDC | 3.75 VDC | 1A | 0.3A @ 125VAC, 1A @ 30VDC | DPDT (2 Form C) | Surface Mount | Silver (Ag), Gold (Au) | Gull Wing | 2C DPDT | Relays | Single Side Stable | Telecom | Signal Relay | 200,000 ops | 3ms | -40°C ~ 70°C | - | - | - | |
 G6H-2F-TRDC12 Omron Electronic Components | 0 | - | Tape and Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 365 Days | Electromechanical Relay | G6H-2F-TR-DC12 | |
G6H-2F-TRDC5 Omron Electronic Components | 0 | - | Tape and Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 365 Days | Electromechanical Relay | G6H-2F-TR-DC5 | |
G6H-2F-TRDC24 Omron Electronic Components | 0 | - | Tape and Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 365 Days | Electromechanical Relay | G6H-2F-TR-DC24 | |
 G6H-2F-TRDC9 Omron Electronic Components | 0 | - | Tape and Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 365 Days | Electromechanical Relay | G6H-2F-TR-DC9 | |
