FBA08A12 fba 系列型号列表/参数/数据手册

MinebeaMitsumi Inc. 的 FBA08A12 系列是一款采用水波轴承的 12V 直流冷却风扇，与传统的球轴承相比，水波轴承提供了更好的耐用性和更低的噪音。这些风扇有多种瓦数和尺寸可供选择，适用于需要可靠冷却但又不能产生过多噪音的各种应用场合。

如果您正在开发需要安静且高效的冷却解决方案的项目，这些风扇绝对值得考虑。例如，它们常用于服务器机架、游戏电脑和工业控制面板等场合，在这些场合中保持安静的操作环境至关重要。水波轴承还提供了更好的抗污染能力，特别是在灰尘或其他颗粒物较多的环境中特别有用。

值得注意的是，不同的瓦数选项允许您根据具体需求精细调整风量和噪音水平。例如，较低瓦数的风扇可能更适合安静的应用场景，而较高瓦数的型号则可能对于更苛刻的冷却任务更为必要。当工程师们需要在性能和声学舒适性之间取得平衡，尤其是在噪音可能成为问题的空间中，往往会选用这一系列产品。

制造商零件编号	库存	价格	产品类别	噪声	额定电压	端接方式	轴承类型	工作温度	标准包装数量	功率（瓦）	电压范围	最大额定电流	RPM	重量	风量	风扇类型	静压	尺寸/外形	额定寿命	交货时间	子类别	RoHS	产品特性	欧盟RoHS	转速	输入范围	额定功率	输出电流	深度	高度	安装类型	总长度	最大压力	壳体材料	其他名称
3 FBA08A12L1A DC Fan Hydro Wave Bearing 12V 0.068A 0.82W 1900RPM 24CFM 21dB Flange Mount FAN 12VDC 0.82W 80MM FBA HYDRO NMB Technologies Corporation	377	1: ¥58.412	-	21 dB	12VDC	Lead Wire	Hydro Wave	14 ~ 158°F (-10 ~ 70°C)	100	0.82W	7 ~ 13.8VDC	0.068A	1900 RPM	0.22 lb (99.79g)	24.0 CFM (0.680m³/min)	Tubeaxial	0.062 in H2O (15.4 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	365 Days	Blowers and Fans	Lead free / RoHS Compliant	-	Compliant	Clockwise	7 to 13.8	0.82	0.068	80	25.4	Flange Mount	80	1.57inH2O	Plastic	-
3 FBA08A12H1A DC Fan Hydro Wave Bearing 12V 0.173A 2.08W 2950RPM 39.6CFM 32dB Flange Mount FAN 12VDC 2.08W 80MM FBA HYDRO NMB Technologies Corporation	0		-	32 dB	12VDC	Lead Wire	Hydro Wave	14 ~ 158°F (-10 ~ 70°C)	100	2.08W	7 ~ 13.8VDC	0.173A	2950 RPM	0.22 lb (99.79g)	39.6 CFM (1.12m³/min)	Tubeaxial	0.149 in H2O (37.1 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	365 Days	Blowers and Fans	Lead free / RoHS Compliant	-	Compliant	Clockwise	7 to 13.8	2.08	0.173	80	25.4	Flange Mount	80	37.1Pa	Plastic	-
2 FBA08A12M1BS FAN 12VDC W 80MM HYDROWAVE NMB Technologies Corporation	0		-	28 dB	12VDC	3 Wire Leads	Hydro-wave (HWB)	14 ~ 158°F (-10 ~ 70°C)	100	1.49W	7 ~ 13.8VDC	0.124A	2450 RPM	0.22 lb (99.79g)	32.1 CFM (0.909m³/min)	Tubeaxial	0.099 in H2O (24.6 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	365 Days	Not Specified	Lead free / RoHS Compliant	Locked Rotor Sensor	-	-	-	-	-	-	-	-	-	-	-	P11038
FBA08A12H1BS FAN 12VDC W 80MM HYDROWAVE NMB Technologies Corporation	0		-	32 dB	12VDC	3 Wire Leads	Hydro-wave (HWB)	14 ~ 158°F (-10 ~ 70°C)	100	2.08W	7 ~ 13.8VDC	0.173A	2950 RPM	0.22 lb (99.79g)	39.6 CFM (1.12m³/min)	Tubeaxial	0.149 in H2O (37.1 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	365 Days	Not Specified	Lead free / RoHS Compliant	Locked Rotor Sensor	-	-	-	-	-	-	-	-	-	-	-	-
FBA08A12U1AZ DC Fan Hydro Wave Bearing 12V 0.27A 3.24W 3450RPM 46.9CFM 38.2dB Flange Mount NMB Technologies Corporation	13	1: ¥87.72	-	38.2	12	Lead Wire	Hydro Wave	70	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Supplier Unconfirmed	Clockwise	7 to 13.8	3.24	0.27	80	25.4	Flange Mount	80	47Pa	-	-
3 FBA08A12M1A DC Fan Hydro Wave Bearing 12V 0.124A 1.49W 2450RPM 32.1CFM 28dB Flange Mount FAN 12VDC 1.49W 80MM FBA HYDRO NMB Technologies Corporation	0		-	28 dB	12VDC	Lead Wire	Hydro Wave	14 ~ 158°F (-10 ~ 70°C)	100	1.49W	7 ~ 13.8VDC	0.124A	2450 RPM	0.22 lb (99.79g)	32.1 CFM (0.909m³/min)	Tubeaxial	0.099 in H2O (24.6 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	365 Days	Blowers and Fans	Lead free / RoHS Compliant	-	Compliant	Clockwise	7 to 13.8	1.49	0.124	80	25.4	Flange Mount	80	0.09inH2O	Plastic	-
FBA08A12U1BO FAN 12VDC 80X25.5MM WITH SENSOR NMB Technologies Corporation	0		-	32.8 dB	12VDC	3 Wire Leads	Hydro-wave (HWB)	14 ~ 158°F (-10 ~ 70°C)	100	3.24W	7 ~ 13.8VDC	0.270A	3450 RPM	0.22 lb (99.79g)	46.9 CFM (1.33m³/min)	Tubeaxial	0.188 in H2O (46.8 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	-	-	-	Locked Rotor Sensor	-	-	-	-	-	-	-	-	-	-	-	-
FBA08A12H1AZ FAN 12VDC W 80MM HYDROWAVE NMB Technologies Corporation	0		-	32 dB	12VDC	2 Wire Leads	Hydro-wave (HWB)	14 ~ 158°F (-10 ~ 70°C)	100	2.08W	7 ~ 13.8VDC	0.173A	2950 RPM	0.22 lb (99.79g)	39.6 CFM (1.12m³/min)	Tubeaxial	0.149 in H2O (37.1 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
FBA08A12U1A FAN 12VDC 3.24W 80MM FBA HYDRO NMB Technologies Corporation	10	1: ¥87.72	-	38.2 dB	12VDC	2 Wire Leads	Hydro-wave (HWB)	14 ~ 158°F (-10 ~ 70°C)	100	3.24W	7 ~ 13.8VDC	0.270A	3450 RPM	0.22 lb (99.79g)	46.9 CFM (1.33m³/min)	Tubeaxial	0.188 in H2O (46.8 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
FBA08A12L1AZ FAN 12VDC W 80MM HYDROWAVE NMB Technologies Corporation	161	1: ¥58.412	-	21 dB	12VDC	2 Wire Leads	Hydro-wave (HWB)	14 ~ 158°F (-10 ~ 70°C)	100	0.82W	7 ~ 13.8VDC	0.068A	1900 RPM	0.22 lb (99.79g)	24.0 CFM (0.680m³/min)	Tubeaxial	0.062 in H2O (15.4 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
FBA08A12M1BX FAN 12VDC W 80MM HYDROWAVE NMB Technologies Corporation	0		-	28 dB	12VDC	3 Wire Leads	Hydro-wave (HWB)	14 ~ 158°F (-10 ~ 70°C)	100	1.49W	7 ~ 13.8VDC	0.124A	2450 RPM	0.22 lb (99.79g)	32.1 CFM (0.909m³/min)	Tubeaxial	0.099 in H2O (24.6 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	-	-	-	Speed Sensor (Tach)	-	-	-	-	-	-	-	-	-	-	-	P11039
FBA08A12U1BS FAN 80X25MM 12 VOLT W/LOCKED R NMB Technologies Corporation	0		-	38.2 dB	12VDC	3 Wire Leads	Hydro-wave (HWB)	14 ~ 158°F (-10 ~ 70°C)	100	3.24W	7 ~ 13.8VDC	0.270A	3450 RPM	0.22 lb (99.79g)	46.9 CFM (1.33m³/min)	Tubeaxial	0.188 in H2O (46.8 Pa)	Square - 80mm L x 80mm H x 25.5mm W	50000 hrs @ 40°C	-	-	-	Locked Rotor Sensor	-	-	-	-	-	-	-	-	-	-	-	P9997
FBA08A12L1BX FAN LOW VOLUME 12V NMB Technologies Corporation	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
