F3480T line filter 系列
Curtis Industries, Inc.三相480V滤波器，带端子块连接，适用于各种电流等级
Curtis Industries 的 F3480T 线路滤波器设计用于减轻三相 480V 电气系统中的谐波失真并提高功率因数。这些滤波器常应用于制造工厂、数据中心和大型商业建筑等工业环境中，高功率设备如变频驱动器、不间断电源系统和电动机会产生大量谐波。
如果您正在处理这类负载相关的项目，F3480T 可以成为有价值的工具。值得注意的是，这些滤波器配备了端子块连接方式，使其无需进行大量重新布线即可轻松集成到现有电气系统中。这一特性在进行改造项目或处理复杂安装时尤为有用。
当工程师需要解决与不良电能质量相关的问题，例如电压下陷、电压突升和闪烁时，往往会选用这种滤波器。这些问题可能导致设备过早失效，并降低整体系统效率。通过减少谐波失真，这些滤波器有助于确保连接设备的稳定和高效运行，从而降低维护成本并提高可靠性。
系列图片（4 张）
文档与媒体
常见问答
F3480T line filter - 型号列表
共 12 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 标准包装数量 | 认证机构 | 电流 | 滤波器类型 | 工作频率 | 额定交流电压（相间） | 额定交流电压（相对地/中性线） | 安装类型 | 端接样式 | 应用 | 配置 | 输出电流 | 每极负载侧连接方式 | 类型 | 卡标准 | 其他名称 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 FILTER 3-PHASE 480V 9A 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 9 Amps Curtis Industries | 10 | 1: ¥1,258.00 | - | 1 | CE, UL | 9A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 9 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | - |
 FILTER 3-PHASE 480V 16A TERM BLK 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 16 Amps Curtis Industries | 10 | 10: ¥1,828.4112 | - | 1 | CE, UL | 16A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 16 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | 364-1126 |
 FILTER 3-PHASE 480V 32A TERM BLK 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 32 Amps Curtis Industries | 10 | 1: ¥2,079.508 | - | 1 | CE, UL | 32A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 32 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | 364-1127 |
 FILTER 3-PHASE 480V 50A TERM BLK 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 50 Amps Curtis Industries | 10 | 1: ¥2,435.76 | - | 1 | CE, UL | 50A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 50 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | 364-1128 |
FILTER 3-PHASE 480V 60A 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 60 Amps Curtis Industries | 10 | 1: ¥3,853.492 | - | 1 | CE, UL | 60A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 60 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | - |
FILTER 3-PHASE 480V 80A 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 80 Amps Curtis Industries | 10 | 1: ¥4,506.632 | - | 1 | CE, UL | 80A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 80 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | - |
FILTER 3-PHASE 480V 112A 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 112 Amps Curtis Industries | 10 | 1: ¥6,038.944 | - | 1 | CE, UL | 112A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 112 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | - |
FILTER 3-PHASE 480V 136A 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 135 Amps Curtis Industries | 10 | 1: ¥6,742.948 | - | 1 | CE, UL | 136A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 135 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | - |
 | 0 | - | 1 | CE, UL | 160A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | - | - | - | - | - | |
FILTER 3-PHASE 480V 185A 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 185 Amps Curtis Industries | 0 | - | 1 | CE, UL | 185A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 185 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | - | |
FILTER 3-PHASE 480V 322A 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 322 Amps Curtis Industries | 0 | - | 1 | CE, UL | 322A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 322 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | - | |
FILTER 3-PHASE 480V 608A 3-Phase Filters Line Termination: Terminal Blocks Load Termination: Terminal Blocks Output Current: 608 Amps Curtis Industries | 0 | - | 1 | CE, UL | 608A | Three Phase (Delta) | 50 ~ 60Hz | 600V | 480V | Chassis | Terminal Block | General Purpose | Two Stage | 608 Amps | Terminal Blocks | Filters - EMI | 3-Phase Filters | - |
