cigen-DP4R60D

DP4R60D optoelectronic 系列

Custom Sensors & Technologies (CST)

Custom Sensors & Technologies (CST)

Solid state contactors and relays for DC switching applications

系列图片（24 张）

文档与媒体

d_p4_r.pdf

DP_brochure.pdf

IS_DP.pdf

108901.PDF

108902.PDF

d_p4_r.pdf

d_p4_r.pdf

常见问答

内容由 AI 生成，仅供参考

加载中...

03

DP4R60D optoelectronic - 型号列表

共 15 个型号

制造商零件编号	库存	价格	产品类别	标准包装数量	RoHS	输出端	电路	输出类型	负载电流	负载电压	供电电压	最大额定电流	最小输入电压	最小供电电压	导通电阻（最大）	包装方式	安装类型	安装样式	封装形式	端接样式	系列	继电器类型	产品子类型	工作模式	类型	卡标准	控制/显示类型	输出配置	其他名称	SVHC	海关税号	输出电流	电池组电压	输出电流（典型）	开关功能/额定值	关态电流（最大）	静态电流（最大）	输入偏置电流（最大）	深度	宽度	高度	长度	重量	端子类型	典型触点布局	开关类型	工作温度	欧盟RoHS	抗辐射加固	输入类型	额定电压	隔离电压	输出电压（最大）	峰值脉冲电流（8/20µs）	总长度	位数	外壳尺寸-插件	印刷电路板数量
4 DP4R60D40B2 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 40A 15VCNT RELAY SSR CONTACT 48VDC 40A 15V Contactor;PMDCHBridgeW/BRK48V40A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 40 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.2 sec Crydom	10	¥2,348.14	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	40A	1 ~ 48 V	4 VDC to 15 VDC	40 A	4.5 ~ 15VDC	1 VDC to 48 VDC	7 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.2 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D40 Solid State Relays - Industrial Mount PM DC H Bridge 48V 40A 15V CNT RELAY SSR CONTACT 48VDC 40A 15V Contactor;PMDCHBridge48V40A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 40 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Stop Mode Matches Start Mode Crydom	10	¥1,678.68	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	40A	1 ~ 48 V	4 VDC to 15 VDC	40 A	4.5 ~ 15VDC	1 VDC to 48 VDC	7 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Stop Mode Matches Start Mode	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D20B5 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 20A 15VCNT RELAY SSR CONTACT 48VDC 20A 15V Contactor;PMDCHBridgeW/BRK48V20A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 20 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.5 sec Crydom	10	¥2,117.95	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	20A	1 ~ 48 V	4 VDC to 15 VDC	20 A	4.5 ~ 15VDC	1 VDC to 48 VDC	14 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.5 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
6 DP4R60D20B Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 20A 15VCNT RELAY SSR CONTACTOR 20A 48V 20A Panel Mount, DC Switching MOSFET Solid State Relay, 48V dc CONTACTORS, W/BRK 48V 20A 15VDC CTL Contactor;PMDCHBridgeW/BRK48V20A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 20 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, Continuous Crydom	29	¥2,110.97	-	2	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	20A	1 ~ 48 V	4 VDC to 15 VDC	20 A	4.5 ~ 15VDC	1 VDC to 48 VDC	14 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	-	-	-	-	-	CC1832	:No SVHC (20-Jun-2013)	85364900	:1mA	1 V dc	:20A	:Reversing	20 μA	0.10 A	:13A	73.5mm	:73.5mm	20mm	104mm	0.31	Screw	:(Not Available)	DC Switching	:80°C	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D60B5 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 60A 15VCNT RELAY SSR CONTACT 48VDC 60A 15V Contactor;PMDCHBridgeW/BRK48V60A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 60 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.5 sec Crydom	10	¥2,693.52	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	60A	1 ~ 48 V	4 VDC to 15 VDC	60 A	4.5 ~ 15VDC	1 VDC to 48 VDC	5 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.5 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D40B5 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 40A 15VCNT RELAY SSR CONTACT 48VDC 40A 15V Contactor;PMDCHBridgeW/BRK48V40A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 40 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.5 sec Crydom	10	¥2,348.14	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	40A	1 ~ 48 V	4 VDC to 15 VDC	40 A	4.5 ~ 15VDC	1 VDC to 48 VDC	7 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.5 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D40B Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 40A 15VCNT RELAY SSR CONTACT 48VDC 40A 15V Contactor;PMDCHBridgeW/BRK48V40A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 40 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, Continuous Crydom	10	¥1,851.05	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	40A	1 ~ 48 V	4 VDC to 15 VDC	40 A	4.5 ~ 15VDC	1 VDC to 48 VDC	7 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, Continuous	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D20B8 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 20A 15VCNT RELAY SSR CONTACT 48VDC 20A 15V Contactor;PMDCHBridgeW/BRK48V20A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 20 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.8 sec Crydom	10	¥2,117.95	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	20A	1 ~ 48 V	4 VDC to 15 VDC	20 A	4.5 ~ 15VDC	1 VDC to 48 VDC	14 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.8 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D20B2 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 20A 15VCNT RELAY SSR CONTACT 48VDC 20A 15V Contactor;PMDCHBridgeW/BRK48V20A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 20 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.2 sec Crydom	10	¥2,117.95	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	20A	1 ~ 48 V	4 VDC to 15 VDC	20 A	4.5 ~ 15VDC	1 VDC to 48 VDC	14 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.2 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
6 DP4R60D20 Solid State Relays - Industrial Mount PM DC H Bridge 48V 20A 15V CNT RELAY SSR CONTACTOR 20A 48V 20A Panel Mount, DC Switching MOSFET Solid State Relay, 48V dc CONTACTORS, 48V 20A 15VDC CTL Contactor;PMDCHBridge48V20A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 20 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Stop Mode Matches Start Mode Crydom	12	¥2,109.82	-	2	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	20A	1 ~ 48 V	4 VDC to 15 VDC	20 A	4.5 ~ 15VDC	1 VDC to 48 VDC	14 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	-	-	-	-	-	CC1831	:No SVHC (20-Jun-2013)	85364900	:1mA	1 V dc	:20A	:Reversing	20 μA	0.10 A	:13A	73.5mm	:73.5mm	20mm	104mm	0.31	Screw	:(Not Available)	DC Switching	:80°C	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D60B2 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 60A 15VCNT RELAY SSR CONTACT 48VDC 60A 15V Contactor;PMDCHBridgeW/BRK48V60A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 60 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.2 sec Crydom	10	¥2,812.05	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	60A	1 ~ 48 V	4 VDC to 15 VDC	60 A	4.5 ~ 15VDC	1 VDC to 48 VDC	5 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.2 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
6 DP4R60D60B Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 60A 15VCNT RELAY SSR CONTACTOR 60A 48V 60A Panel Mount, DC Switching MOSFET Solid State Relay, 48V dc CONTACTORS, W/BRK 48V 60A 15VDC CTL Contactor;PMDCHBridgeW/BRK48V60A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 60 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, Continuous Crydom	10	¥2,269.73	-	2	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	60A	1 ~ 48 V	4 VDC to 15 VDC	60 A	4.5 ~ 15VDC	1 VDC to 48 VDC	5 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	-	-	-	-	-	CC1834	:No SVHC (20-Jun-2013)	85364900	:1mA	1 V dc	:60A	:Reversing	20 μA	0.10 A	:15A	73.5mm	:73.5mm	20mm	104mm	0.345	Screw	:(Not Available)	DC Switching	:80°C	-	-	-	-	-	-	-	-	-	-	-
4 DP4R60D60B8 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 60A 15VCNT RELAY SSR CONTACT 48VDC 60A 15V Contactor;PMDCHBridgeW/BRK48V60A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 60 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.8 sec Crydom	10	¥2,693.52	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	60A	1 ~ 48 V	4 VDC to 15 VDC	60 A	4.5 ~ 15VDC	1 VDC to 48 VDC	5 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.8 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
7 DP4R60D60 Solid State Relays - Industrial Mount PM DC H Bridge 48V 60A 15V CNT Relay SSR 20mA 15V DC-IN 60A 48V DC-OUT 4-Pin RELAY SSR CONTACTOR 60A 48V 60A Panel Mount, DC Switching MOSFET Solid State Relay, 48V dc CONTACTORS, 48V 60A 15VDC CTL Contactor;PMDCHBridge48V60A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 60 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Stop Mode Matches Start Mode Crydom 60 A 面板安装安装固态继电器, MOSFET输出, 直流切换, 48 V 直流 Crydom	10	¥2,081.02	-	2	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	60A	1 ~ 48 V	4 VDC to 15 VDC	60 A	4.5 ~ 15VDC	1 VDC to 48 VDC	5 mOhm	Bulk	Screw	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	-	-	-	-	-	CC1833	:No SVHC (20-Jun-2013)	85364900	60000 mA	1 V dc	:60A	:Reversing	20 μA	0.10 A	20 mA	73.5mm	:73.5mm	20mm	104mm	0.345	Screw	:(Not Available)	DC Switching	-30C to 80C	Compliant	No	DC	15 V	2500 V	48 V	240	104	4	35.1	4
4 DP4R60D40B8 Solid State Relays - Industrial Mount PM DC H Bridge W/BRK 48V 40A 15VCNT RELAY SSR CONTACT 48VDC 40A 15V Contactor;PMDCHBridgeW/BRK48V40A15VCNT Solid State Contactor Control Voltage: 4.5-15 VDC Load Current: 40 Amps Load Voltage: 1-48 VDC Output Configuration: 1A SPST-NO Start Mode: Start Stop Mode: Dynamic Brake, 0.8 sec Crydom	10	¥2,348.14	-	5	RoHS Compliant	DC Output	SPST-NO (1 Form A)	DC	40A	1 ~ 48 V	4 VDC to 15 VDC	40 A	4.5 ~ 15VDC	1 VDC to 48 VDC	7 mOhm	Bulk	Chassis Mount or Panel Mount	Panel	Hockey Puck	Screw	DP4R	Contactor	Industrial Mount	Dynamic Brake, 0.8 sec	Contactors	Solid State Contactor	4.5-15 VDC	1A SPST-NO	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-

第 1 / 1 页
