DAT72415 signal relays, up to 2 amp 系列
Sensata Technologies Holding N.V.高电压reed继电器，配置为SPST-NO，适用于各种安装选项
Sensata Technologies生产的DAT72415系列信号继电器是高压reed继电器，适用于单极单投常开（SPST-NO）配置。这些继电器能够处理高达2安培的电流，使其适用于各种需要可靠信号切换的工业和商业应用。
如果您正在从事涉及高压信号传输的项目，这些继电器可以是一个有价值的补充。它们提供多种安装选项，因此在不同的安装场景中具有很高的灵活性。值得一提的是，这些继电器非常坚固，能够在恶劣环境中工作，即使在挑战性条件下也能确保可靠性。当工程师们需要一个紧凑而强大的解决方案来进行信号隔离和切换时，往往会选择这种类型的继电器。
另一个实用的观察是，这些继电器经常用于控制系统、自动化和电力分配面板中。它们无需物理接触即可切换信号的能力使它们成为防止电气电弧并提高系统安全的理想选择。此外，它们的低接触电阻确保了最小的信号衰减，这对于保持长距离传输中的信号完整性至关重要。
总体而言，DAT72415系列为需要高压信号继电器的应用提供了可靠且灵活的解决方案，使其成为许多工程师的首选组件。
系列图片（22 张）
文档与媒体
常见问答
DAT72415 signal relays, up to 2 amp - 型号列表
共 7 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 供电电压 | 开关电流 | 安装类型 | 典型触点布局 | 开关电压 | 类型 | 卡标准 | 隔离 | 释放时间 | 接触电阻 | 动作时间 | 工作温度 | 标准包装数量 | RoHS | 线圈类型 | 线圈电流 | 线圈电阻 | Vgs(th)（最大）@ Id | 集电极-发射极饱和电压（最大）@ Vge, Ic | 触点额定电流 | 包装方式 | 触点形式 | 触头类型 | 触头材料 | 端接样式 | 继电器类型 | 电阻 | 最大开关负载 | 绝缘电阻 | 通态电流（It (RMS)）（最大） | 接触件端接 | 释放值 | 必须动作（继电器术语，指必须吸合） | 海关税号 | 最大功率 | 隔离类型 | 直流开关电压 | 深度 | 高度 | 长度 | 重量 | 高度（最大） | 端子类型 | 机械寿命 | 材料（通用） | 总线连接 | 其他名称 | SVHC | 宽度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 RELAY REED SPST 2A 24V Reed Relays SPST-NO 2A 24VDC 350Ohm Panel Mount RELAY;15KV24VSPNOTUNGSTEN-PANELMOUNTSTUDSSOLDERTURRETCOIL/HVCONTACT Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Base Mount Switching Current: 2 Amps Switching Voltage: 10000 Volts Sensata Technologies Holding N.V. | 0 | - | 24VDC | 2 Amps | Chassis Mount | 1A SPST-NO | 10000VAC, 10000VDC - Max | Relays | Reed Relay | 15 kv | 2ms | 250 ohms (100 ohms) | 3ms | -20°C ~ 70°C | 20 | RoHS Compliant Part | Non Latching | 68.57mA | 350 Ohms | 4 VDC | 20 VDC | 2A | Tray | SPST-NO (1 Form A) | Tungsten | Tungsten (W) | Solder Turret | Reed | 350 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 2 A | 17 kv | 4 V | 20 V | - | - | - | - | - | - | - | - | - | - | - | - | - | DAT72415P-ND | - | - | |
 RELAY REED SPST 2A 24V SP-NO Reed Relay, 2A, 24V dc Reed Relays SPST-NO 2A 24VDC 350Ohm RELAY, 15KV, 24V COIL RELAY;15KV24VSPNOTUNGSTEN-SOLDERTURRETHVCONTACTCONNECTIONS Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Flying Leads Switching Current: 2 Amps Switching Voltage: 10000 Volts Reed relay 24 VDC 350 Ohm, DAT72415F, Cynergy3 Sensata Technologies Holding N.V. | 0 | - | 24VDC | 2 A | Through Hole | SP-NO | 10000VAC, 10000VDC - Max | - | - | - | 2ms | 250 mΩ | 3ms | -20°C ~ 70°C | 20 | Compliant | Non Latching | 68.57mA | 350 Ohms | 4 VDC | 20 VDC | 2A | Tray | SPST-NO (1 Form A) | - | Tungsten (W) | PC Pin, Wire Leads | Reed | - | - | - | - | - | - | - | 85353010 | 50 W | 15kV ac/dc | 10000V dc | 15.8mm | 18.5mm | 60mm | 0.038 | :18.5mm | Through Hole | 100000000 (Electrical) cycles | - | - | - | :No SVHC (20-Jun-2013) | :60mm | |
 RELAY REED SPST 2A 24V SP-NO Reed Relay, 2A, 24V dc Reed Relays SPST-NO 2A 24VDC 350Ohm Thru-Hole DRY REED RELAY, SPST-NO, 24VDC, 2A, THD RELAY;REED;HIGHVOLTAGE;SPNO;15KV;24VCOIL;PCB Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 2 Amps Switching Voltage: 10000 Volts Reed relay 24 VDC 350 Ohm, DAT72415, Cynergy3 Sensata Technologies Holding N.V. | 0 | - | 24VDC | 2 A | Through Hole | SP-NO | 10000VAC, 10000VDC - Max | - | - | - | 2ms | 250 mΩ | 3ms | -20°C ~ 70°C | 20 | Compliant | Non Latching | 68.57mA | 350 Ohms | 4 VDC | 20 VDC | 2A | Tray | SPST-NO (1 Form A) | - | Tungsten (W) | PC Pin | Reed | - | - | - | - | - | - | - | 85364900 | 50 W | 15kV ac/dc | 10000V dc | 15.8mm | 18.5mm | 60mm | 0.005 | :18.5mm | Through Hole | 100000000 (Electrical) cycles | - | - | - | - | - | |
 None Reed Relays SPST-NO 2A 24VDC 350Ohm Panel Mount RELAY;10KV05VSPNCRHODIUM-PCBMOUNT Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Base Mount Switching Current: 2 Amps Switching Voltage: - Sensata Technologies Holding N.V. | 0 | - | 24 VDC | 2 Amps | Base Mount | 1A SPST-NO | - | Relays | Reed Relay | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Tungsten | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 15KV 24V SPNO Tungsten - PCB mount - HR Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 3 Amps Switching Voltage: 10000 Volts Sensata Technologies Holding N.V. | 0 | - | 24 VDC | 3 Amps | PC Board | 1A SPST-NO | 10000 Volts | Relays | Reed Relay | 15kV | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Tungsten | PC Board | - | - | - | |
 15KV 24V SPNO Tungsten - Flying Lead HVcontact connections - HR Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 3 Amps Switching Voltage: 10000 Volts Sensata Technologies Holding N.V. | 0 | - | 24 VDC | 3 Amps | PC Board | 1A SPST-NO | 10000 Volts | Relays | Reed Relay | 15kV | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Tungsten | Flying Leads | - | - | - | |
 Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Base Mount Switching Current: 2 Amps Switching Voltage: 10000 Volts Sensata Technologies Holding N.V. | 0 | - | 24 VDC | 2 Amps | Base Mount | 1A SPST-NO | 10000 kv | Relays | Reed Relay | 15 kv | 2.0ms | 250 ohms (100 ohms) | 3.0ms | -20C to +70C | - | - | - | - | - | - | - | - | - | - | Tungsten | - | - | - | 350 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 2 A | 17 kv | 4 V | 20 V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
