cigen-CR4220S

CR4220S sensors, transducer 系列

CR Magnetics Inc.

CR Magnetics Inc.

AC current transmitters and sensors for various amperage ranges

系列图片（2 张）

文档与媒体

CR4220%20Series.pdf

常见问答

内容由 AI 生成，仅供参考

加载中...

03

CR4220S sensors, transducer - 型号列表

共 10 个型号

制造商零件编号	库存	价格	产品类别	标准包装数量	输出端	精度	频率	传感器类型	响应时间	供电电压	感应电流	包装方式	极化	安装类型	封装形式	工作温度	其他名称	系列
CR4220S-15 XMITTER AC CRRNT 4-20MA 0-15AAC CR Magnetics Inc	10	¥816.48	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	15A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
CR4220S-25 XMITTER AC CRRNT 4-20MA 0-25AAC CR Magnetics Inc	10	¥680.40	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	25A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
CR4220S-5 XMITTER AC CRRNT 4-20MA 0-5AAC CR Magnetics Inc	10	¥680.40	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	5A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
CR4220S-0.5 XMITTER AC CRRNT 4-20MA 0-0.5AAC CR Magnetics Inc	10	¥680.40	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	0.5A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
CR4220S-40 XMITTER AC CRRNT 4-20MA 0-40AAC CR Magnetics Inc	10	¥680.40	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	40A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
CR4220S-30 XMITTER AC CRRNT 4-20MA 0-30AAC CR Magnetics Inc	10	¥680.40	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	30A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
CR4220S-10 XMITTER AC CRRNT 4-20MA 0-10AAC CR Magnetics Inc	10	¥680.40	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	10A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
CR4220S-50 XMITTER AC CRRNT 4-20MA 0-50AAC CR Magnetics Inc	10	¥680.40	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	50A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
2 CR4220S-100 SENSOR CURRENT 100A 24V BI MOD CR Magnetics Inc	10	¥1,336.18	-	1	4 ~ 20mA DC	±1%	20Hz ~ 5kHz	Current Sensor	250ms	24V	100A	Bulk	Unidirectional	DIN Rail	Modular	0°C ~ 60°C	-	-
CR4220S-75 XMITTER AC CRRNT 4-20MA 0-75AAC CR Magnetics Inc	10	¥1,113.48	-	1	-	-	-	-	-	-	-	-	-	-	-	-	Q7150396	*
