CA11253 optoelectronic 系列
LEDiL Oy各种LED照明应用的透镜
LEDiL Oy 的 CA11253 系列由专为各种 LED 照明应用设计的精密透镜组成。这些透镜特别设计以优化 LED 照明装置的光分布、色域还原以及整体性能。如果您正在从事需要精确控制光输出的项目，例如汽车照明、建筑照明或特殊工业照明，这些透镜将是理想的选择。
值得一提的是它们的多功能性——不同焦距和角度可供选择，使工程师能够根据应用需求精确调整光束图案。这种灵活性使得 CA11253 系列成为设计师在无需复杂光学元件或额外组件的情况下实现特定照明效果的理想选择。
另一个实用的观察点是它们的耐用性和光学质量。CA11253 系列所使用的材料设计用于承受恶劣环境条件，在挑战性环境中也能确保一致的性能。这种可靠性对于长期安装来说至关重要，特别是在需要维持最佳照明条件的应用中。
总体而言，如果您正在从事需要高质量、精确控制的 LED 照明项目，CA11253 系列绝对值得考虑。
系列图片（6 张）
文档与媒体
常见问答
CA11253 optoelectronic - 型号列表
共 6 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | RoHS | 视角 | 颜色 | 形状 | 宽度 | 高度 | 长度 | 类型 | 样式 | 适用产品/相关产品 | 机械寿命 | 标准包装数量 | 欧盟RoHS | 海关税号 | 光束角 | 光学模式 | 重量 | 包装方式 | 透镜颜色 | 透镜样式 | 透镜材料 | 安装类型 | 透镜样式/尺寸 | 透镜类型 | 附件类型 | LED数量 | 其他规格 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Lenses With Lens Material Optical Grade PMMA With High UV And Temperature Resistance LED Lighting Lenses OSRAM OSLON SSL SNGL LENS & TAPE ledil | 4680 | 1: ¥7.072 | - | RoHS Compliant | 92 deg | Clear | Rectangular | 15.6 mm | 5.9 mm | 19.6 mm | Lens | Transparent | OSRAM Oslon SSL | Verify Status with Factory: Lifecycle information is unclear. Obtain a quote to verify the availability of this part number from the manufacturer. | Tape & Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Lens Material Optical Grade PMMA With High UV LED Lighting Lenses SHARP GM2BB SNGL LENS & POS PIN ledil | 0 | - | RoHS Compliant | 122 deg | Clear | Rectangular | 15.6 mm | 5.9 mm | 19.6 mm | Lenses | Transparent | Sharp GM2BB | Verify Status with Factory: Lifecycle information is unclear. Obtain a quote to verify the availability of this part number from the manufacturer. | Tape & Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
| 2160 | 1: ¥7.072 | - | RoHS Compliant | 124 deg | Clear | Rectangular | 15.6 mm | 5.9 mm | 19.6 mm | Lenses | Transparent | Cree XP-E | Verify Status with Factory: Lifecycle information is unclear. Obtain a quote to verify the availability of this part number from the manufacturer. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 726 | 2: ¥19.80 | - | RoHS Compliant | 120 deg | Clear | Rectangular | 15.6 mm | 5.9 mm | 19.6 mm | Lenses | Transparent | Luxeon Rebel | Verify Status with Factory: Lifecycle information is unclear. Obtain a quote to verify the availability of this part number from the manufacturer. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 0 | - | RoHS Compliant | 124 deg | Clear | Round | 15.5 mm | 6.9 mm | 19.6 mm | Lenses | Transparent | Nichia 119/219 | Verify Status with Factory: Lifecycle information is unclear. Obtain a quote to verify the availability of this part number from the manufacturer. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 LED Accessories LENS FOR SHARP GM2BB Strada C2 LED Optic,Taped Base LED Lighting Lenses Single Lens LENS, RECTNGLR, 124DEG, XP-E SERIES LED LEDiL Strada-C2 系列 街道照明 LED 透镜 LEDIL OY | 125 | 1: ¥29.512 | - | Lead free / RoHS Compliant | 122° | Clear | Round | 15.5 mm | 6.9 mm | 19.6 mm | Lens | Transparent | Sharp GM2BB | - | 240 | Compliant | 90019000 | :124° | Wide, Side Emitting | 0 | Tray | :Clear | :Rectangular | :PMMA | Adhesive, Position Pins | Round with Domed Top, 19.6mm | :Lens | :LED Lens | 1 | Wide Angle Batwing |
