ADQ13Q relay 系列
Panasonic Corporation通用继电器，具有多种线圈电压
Panasonic生产的ADQ13Q继电器系列是一款适用于广泛工业和商业应用的通用继电器，具有多种用途。这些继电器提供不同的线圈电压，使其能够适应各种控制系统。如果您需要在电路之间进行可靠的切换，那么这些继电器是一个不错的选择。
值得注意的是，它们非常坚固耐用。这些继电器设计用于频繁操作而不会退化，因此适合高循环计数的环境。当工程师需要一个能够在自动化系统、暖通空调控制甚至家用电器中可靠切换交流或直流负载的继电器时，往往会选择这种继电器。
另一个实际应用是在电源分配面板中，这些继电器帮助管理不同电源电路的切换。它们的小巧尺寸和易于安装的特点也使它们成为空间受限安装的理想选择。可以从不同线圈电压中进行选择，确保与广泛的控制信号兼容，从简单的开/关开关到更复杂的PLC输出。
总体而言，ADQ13Q继电器在性能和成本效益方面达到了平衡，是许多电气和电子系统中的可靠组件。
系列图片（8 张）
文档与媒体
常见问答
ADQ13Q relay - 型号列表
共 6 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 线圈功率 | 开关电压 | 开关电流 | 保护电压（VP）（2416） | 触头材料 | 继电器类型 | 工作温度 | 标准包装数量 | 工厂包装数量 | RoHS | 转速 | 电流 | 线圈类型 | 频率 | 线圈电流 | 释放时间 | 最大电压 | 额定输出功率 | 线圈电阻 | 额定电压值 | 供电电压 | 标称电压 | 接触电阻 | 击穿电压 | 最大额定电流 | 绝缘电阻 | 平均正向功率 | 集电极-发射极饱和电压（最大）@ Vge, Ic | 触点额定电流 | 重量 | 包装方式 | 触点形式 | 安装类型 | 安装样式 | 端接样式 | 接触件端接 | 典型触点布局 | 类型 | 产品特性 | 功能 | 卡标准 | 电气寿命 | 温度 | 动作时间 | 湿度范围 | 机械寿命 | 抗冲击能力 | 抗振性（功能） | 抗振性（破坏） | 电感量 | 测试电压 | 开关容量 | 尺寸 | 触点数 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 General Purpose Relays 1 Form A, 24VDC Sealed, 500mW RELAY GEN PURPOSE SPST 30A 24V Electromechanical Relay SPST-NO 30A 24VDC 1.152KOhm Through Hole Power Relay Coil Voltage: 24 VDC Contact Configuration: 1A SPST-NO Current: 30 Amps Mounting: PC Board Operating Function: 1 Coil Latching Panasonic Electric Works | 68 | 1: ¥113.22 | General Purpose Relays | 500 mW | 250VAC - Max | 100 mA, 5 V DC | Min. 10,000 V (initial) | Silver Tin Oxide | General Purpose | -40°C ~ 65°C | 20 | 20 | RoHS Compliant | 10 cpm | 30 Amps | Latching Single Coil | 30 A 250V AC | 20.8mA | 20ms | 16.8 VDC | 7,500 V A | 1.15 kOhms | 31.2 VDC | 24 V | 24 VDC | 30 mohm | 4,000 Vrms for 1 min. | 30 A | Min. 1,000 Mohm (at 500 V DC) | 500 mW | 16.8 VDC | 30A | Approx. 35 g 1.23 oz | Tube | 1 Form A (SPST-NO) | Through Hole | Through Hole | Solder Pin | Quick Connect | 1A SPST-NO | Relays | Sealed - Fully | 1 Coil Latching | Power Relay | 10^4 | 40C to +65C, 40F to +149F | 20ms | 5 to 75% R.H. | 10^6 | Min. 1,000 m/s^2{100 G} | 10 to 55Hz at double amplitude of 1.5mm | 10 to 55Hz at double amplitude of 2.0mm | - | - | - | - | - |
 General Purpose Relays 1 Form A, 4.5VDC Sealed, 500mW RELAY GEN PURPOSE SPST 30A 4.5V Electromechanical Relay SPST-NO 30A 4.5VDC 40.5Ohm Through Hole Power Relay Coil Voltage: 4.5 VDC Contact Configuration: 1A SPST-NO Current: 30 Amps Mounting: PC Board Operating Function: 1 Coil Latching Panasonic Electric Works | 22 | 1: ¥144.228 | General Purpose Relays | 500 mW | 250VAC - Max | 100 mA, 5 V DC | Min. 10,000 V (initial) | Silver Tin Oxide | General Purpose | -40°C ~ 65°C | 20 | 20 | RoHS Compliant | 10 cpm | 30 Amps | Latching Single Coil | 30 A 250V AC | 111.1mA | 20ms | 3.15 VDC | 7,500 V A | 40.5 Ohms | 5.85 VDC | 4.5 V | 4.5 VDC | 30 mohm | 4,000 Vrms for 1 min. | 30 A | Min. 1,000 Mohm (at 500 V DC) | 500 mW | 3.15 VDC | 30A | Approx. 35 g 1.23 oz | Tube | 1 Form A (SPST-NO) | Through Hole | Through Hole | Solder Pin | Quick Connect | 1A SPST-NO | Relays | Sealed - Fully | 1 Coil Latching | Power Relay | 10^4 | 40C to +65C, 40F to +149F | 20ms | 5 to 75% R.H. | 10^6 | Min. 1,000 m/s^2{100 G} | 10 to 55Hz at double amplitude of 1.5mm | 10 to 55Hz at double amplitude of 2.0mm | - | - | - | - | - |
 General Purpose Relays 1 Form A, 9VDC Sealed, 500mW RELAY GEN PURPOSE SPST 30A 9V Electromechanical Relay SPST-NO 30A 9VDC 162Ohm Through Hole Power Relay Coil Voltage: 9 VDC Contact Configuration: 1A SPST-NO Current: 30 Amps Mounting: PC Board Operating Function: 1 Coil Latching Panasonic Electric Works | 68 | 1: ¥113.22 | General Purpose Relays | 500 mW | 250VAC - Max | 100 mA, 5 V DC | Min. 10,000 V (initial) | Silver Tin Oxide | General Purpose | -40°C ~ 65°C | 20 | 20 | RoHS Compliant | 10 cpm | 30 Amps | Latching Single Coil | 30 A 250V AC | 55.6mA | 20ms | 6.3 VDC | 7,500 V A | 162 Ohms | 11.7 VDC | 9 V | 9 VDC | 30 mohm | 4,000 Vrms for 1 min. | 30 A | Min. 1,000 Mohm (at 500 V DC) | 500 mW | 6.3 VDC | 30A | Approx. 35 g 1.23 oz | Tube | 1 Form A (SPST-NO) | Through Hole | Through Hole | Solder Pin | Quick Connect | 1A SPST-NO | Relays | Sealed - Fully | 1 Coil Latching | Power Relay | 10^4 | 40C to +65C, 40F to +149F | 20ms | 5 to 75% R.H. | 10^6 | Min. 1,000 m/s^2{100 G} | 10 to 55Hz at double amplitude of 1.5mm | 10 to 55Hz at double amplitude of 2.0mm | - | - | - | - | - |
 General Purpose Relays 1 Form A, 12VDC Sealed, 500mW RELAY GEN PURPOSE SPST 30A 12V Electromechanical Relay SPST-NO 30A 12VDC 288Ohm Through Hole Power Relay Coil Voltage: 12 VDC Contact Configuration: 1A SPST-NO Current: 30 Amps Mounting: PC Board Operating Function: 1 Coil Latching Panasonic Electric Works | 68 | 1: ¥113.22 | General Purpose Relays | 500 mW | 250VAC - Max | 100 mA, 5 V DC | Min. 10,000 V (initial) | Silver Tin Oxide | General Purpose | -40°C ~ 65°C | 20 | 20 | RoHS Compliant | 10 cpm | 30 Amps | Latching Single Coil | 30 A 250V AC | 41.7mA | 20ms | 8.4 VDC | 7,500 V A | 288 Ohms | 15.6 VDC | 12 V | 12 VDC | 30 mohm | 4,000 Vrms for 1 min. | 30 A | Min. 1,000 Mohm (at 500 V DC) | 500 mW | 8.4 VDC | 30A | Approx. 35 g 1.23 oz | Tube | 1 Form A (SPST-NO) | Through Hole | Through Hole | Solder Pin | Quick Connect | 1A SPST-NO | Relays | Sealed - Fully | 1 Coil Latching | Power Relay | 10^4 | 40C to +65C, 40F to +149F | 20ms | 5 to 75% R.H. | 10^6 | Min. 1,000 m/s^2{100 G} | 10 to 55Hz at double amplitude of 1.5mm | 10 to 55Hz at double amplitude of 2.0mm | - | - | - | - | - |
 General Purpose Relays 1 Form A, 6VDC Sealed, 500mW RELAY GEN PURPOSE SPST 30A 6V Electromechanical Relay SPST-NO 30A 6VDC 72Ohm Through Hole Power Relay Coil Voltage: 6 VDC Contact Configuration: 1A SPST-NO Current: 30 Amps Mounting: PC Board Operating Function: 1 Coil Latching Panasonic Electric Works | 68 | 1: ¥113.22 | General Purpose Relays | 500 mW | 250VAC - Max | 100 mA, 5 V DC | Min. 10,000 V (initial) | Silver Tin Oxide | General Purpose | -40°C ~ 65°C | 20 | 20 | RoHS Compliant | 10 cpm | 30 Amps | Latching Single Coil | 30 A 250V AC | 83.3mA | 20ms | 4.2 VDC | 7,500 V A | 72 Ohms | 7.8 VDC | 6 V | 6 VDC | 30 mohm | 4,000 Vrms for 1 min. | 30 A | Min. 1,000 Mohm (at 500 V DC) | 500 mW | 4.2 VDC | 30A | Approx. 35 g 1.23 oz | Tube | 1 Form A (SPST-NO) | Through Hole | Through Hole | Solder Pin | Quick Connect | 1A SPST-NO | Relays | Sealed - Fully | 1 Coil Latching | Power Relay | 10^4 | 40C to +65C, 40F to +149F | 20ms | 5 to 75% R.H. | 10^6 | Min. 1,000 m/s^2{100 G} | 10 to 55Hz at double amplitude of 1.5mm | 10 to 55Hz at double amplitude of 2.0mm | - | - | - | - | - |
 | 0 | - | 4.5 | 250 | 30 A@ 250 VAC | RT IV | AgSnO2 | Bistable, 1 coil | -40...+65 °C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 40.5 | 4 | 7500 VA | 38 x 29 x 17.3 mm | 1 make contact (NO) |
