ABJ263 switche 系列
Panasonic Corporation具有各种特性的快动开关
Panasonic 的 ABJ263 开关系列是一系列快动开关，适用于广泛工业和消费电子应用领域。这些开关具有快速可靠的动作特性，适用于需要频繁切换而不会出现磨损问题的环境。如果您正在从事涉及机械设备控制、家用电器或任何需要坚固响应开闭机制的项目，这些开关都是不错的选择。
值得注意的是，它们具有很高的灵活性；不同型号和规格可以满足特定需求。例如，有些型号可能具有更高的电流处理能力，而其他型号则更适合高频操作。当工程师们需要一个既能有效承受机械应力又能承受电气应力的开关时，往往会选用这个系列，以确保长期的可靠性和性能。
另一个实用方面是其紧凑的设计，这使得它们易于集成到空间受限的应用中。此外，由于快动机制可以减少接触反弹并延长开关寿命，因此它们在需要承受恶劣条件和连续使用情况的苛刻工业环境中特别有用。
系列图片（5 张）
文档与媒体
常见问答
ABJ263 switche - 型号列表
共 14 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 致动器类型 | 操作力 | 包装方式 | 释放力 | 端接样式 | 机械寿命 | 工作温度 | 工厂包装数量 | RoHS | 最大额定电流 | 触点形式 | 防护等级 | 标准包装数量 | 电路 | 额定电压 | 开关功能 | 差动行程 | 预行程 | 超行程 | 安装类型 | 电气寿命 | 工作高度 | 触点额定电流 | 端子类型 | 触头材料 | 典型触点布局 | 密封等级 | 保持力 | 连接器类型 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Basic / Snap Action Switches SPST, NO, Long Stroke Type, Wire SWITCH TURQ SPST-NO LONG WIRE Switch Snap Action N.O. SPST Long Stroke Wire Lead 1A 125VAC 30VDC 2.45N Screw Mount Case Panasonic Electric Works | 128 | 1: ¥58.548 | Basic / Snap Action Switches | Plunger | 2.45 N | Bulk | 20gf | Wire | 500,000 Cycles | -40°C ~ 85°C | 50 | RoHS Compliant By Exemption | 1A (AC/DC) | 1 Form A (SPST-NO) | IP67 - Dust Tight, Waterproof | 50 | SPST-NO | 125V | Off-Mom | 0.005" (0.12mm) | 0.024" (0.6mm) | 0.010" (0.25mm) | Chassis Mount | 30,000 Cycles | 0.276" (7.0mm) | - | - | - | - | - | - | - |
 Basic / Snap Action Switches SPST, NO, Hinge Roller Lever, Wire SWITCH TURQ SPST-NO ROLLER WIRE Switch Snap Action N.O. SPST Roller Lever Wire Lead 0.1A 125VAC 24VDC 0.64N Screw Mount Case Panasonic Electric Works | 182 | 1: ¥41.14 | Basic / Snap Action Switches | Roller Lever | 0.64 N | Bulk | 5gf | Wire | 1,000,000 Cycles | -40°C ~ 85°C | 50 | RoHS Compliant By Exemption | 100mA (AC) | 1 Form A (SPST-NO) | IP67 - Dust Tight, Waterproof | 50 | SPST-NO | 125V | Off-Mom | 0.020" (0.5mm) | 0.120" (3.0mm) | 0.020" (0.5mm) | Chassis Mount | 6,000 Cycles | 0.575" (14.6mm) | - | - | - | - | - | - | - |
 Basic / Snap Action Switches SPST, NO, Hinge Lever, Wire Switch Snap Action N.O. SPST Hinge Lever Wire Lead 0.1A 125VAC 0.64N Screw Mount Case Panasonic Electric Works | 189 | 1: ¥39.576 | - | Lever | 0.6 N | Bulk | - | Wire Leads | - | - | 50 | RoHS Compliant By Exemption | - | SPST | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Basic / Snap Action Switches SPST, NO, Hinge Roller Lever, Wire Switch Snap Action N.O. SPST Roller Lever Wire Lead 0.1A 125VAC 0.39N Screw Mount Case Panasonic Electric Works | 171 | 1: ¥43.724 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Basic / Snap Action Switches ABJ(Turquoise) Switch Switch Snap Action N.O. SPST Pin Plunger Wire Lead 1A 125VAC 30VDC 1.23N Screw Mount Case Panasonic Electric Works | 259 | 1: ¥28.628 | - | - | - | Bulk | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Basic / Snap Action Switches SPST, NO, Hinge Simultd. Roller Levr Switch Snap Action N.O. SPST Simulated Roller Lever Wire Lead 0.1A 125VAC 0.64N Screw Mount Case Panasonic Electric Works | 164 | 1: ¥45.152 | - | Roller Lever | 0.6 N | Bulk | - | Wire Leads | - | - | 10 | RoHS Compliant By Exemption | - | SPST | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Basic / Snap Action Switches SPST, NO, Hinge Simultd. Roller Levr Switch Snap Action N.O. SPST Simulated Roller Lever Wire Lead 0.1A 125VAC 24VDC 0.64N Screw Mount Case ABJ SW 2.2MM SPST-NO SIM ROLLER Panasonic Electric Works | 168 | 1: ¥44.132 | - | Roller Lever | 0.6 N | Bulk | 5gf | Wire Leads | 1,000,000 Cycles | -40°C ~ 85°C | 10 | RoHS Compliant By Exemption | 100mA (AC) | SPST | IP67 - Dust Tight, Waterproof | 10 | SPST-NO | 125V | Off-Mom | 0.020" (0.5mm) | 0.120" (3.0mm) | 0.020" (0.5mm) | Chassis Mount | 100,000 Cycles | 0.445" (11.3mm) | - | - | - | - | - | - | - |
Basic / Snap Action Switches ABJ(Turquoise) Switch Switch Snap Action N.O. SPST Pin Plunger Wire Lead 0.1A 125VAC 1.23N Screw Mount Case Panasonic Electric Works | 216 | 1: ¥34.272 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 SPST-NO Simulated Roller Lever Microswitch, 1 A @ 30 V dc Panasonic 单刀单掷 - 常开 模拟滚轮杠杆 微动开关, 1 A @ 30 V 直流 Panasonic Corporation | 36 | 1: ¥53.69 | - | Simulated Roller Lever | 0.39 N | - | 0.029N | - | 1000000Operations | +85°C | - | - | 1 @ 30 V 直流 A | - | IP67 | - | - | - | - | - | - | - | - | - | - | 1 A @ 30 V dc | Pre-wired | Silver Nickel Alloy | SPST-NO | IP67 | 0.029N | Pre-wired |
 | 934 | 1: ¥62.8048 | - | Hinge Lever | 0.64 N | - | 0.049N | - | 10^6Operations | +85°C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 0.1 A @ 125 V ac | Pre-wired | Gold Clad Silver Nickel Alloy | SPST-NO | IP67 | - | - |
Switch Snap Action N.O. SPST Pin Plunger Wire Lead 2A 125VAC 30VDC 1.96N Screw Mount Case Panasonic EW/Aromat | 250 | 1: ¥29.92 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Switch Snap Action N.O. SPST Long Stroke Wire Lead 0.1A 125VAC 30VDC 2.45N Screw Mount Case Panasonic EW/Aromat | 92 | 1: ¥87.72 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 10 | 100: ¥35.836 | - | Lever, Roller | 40gf | Bulk | 3gf | Wire Leads | 1,000,000 Cycles | -40°C ~ 85°C | - | - | 100mA (AC) | - | IP67 - Dust Tight, Waterproof | 100 | SPST-NO | 125V | Off-Mom | 0.020" (0.5mm) | 0.120" (3.0mm) | 0.020" (0.5mm) | Chassis Mount | 100,000 Cycles | 0.575" (14.6mm) | - | - | - | - | - | - | - |
| 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
