DPC-16 系列
pulse
signal-transformers
电子设备用层压式通孔安装电源变压器
DPC-16系列是一款高性能数字电源控制器产品线，专为满足现代电源管理系统日益增长的需求而设计。该系列控制器能够为各类应用场景提供精准、高效且可靠的电源控制，是要求先进电源调节与监控功能的工业领域的理想选择。凭借其坚固耐用的设计和前沿技术，DPC-16系列成为工业及商业电力系统中极具适应性的解决方案。
该系列的核心优势在于其先进的数字控制架构，可实现高精度的电压与电流调节，确保即使在动态负载条件下仍能保持最佳性能和效率。其宽输入电压范围支持与多输出配置特性，可适配各种电源需求。控制器还配备完善的保护功能，包括过压保护、过流保护及热关断保护，确保在严苛环境下安全可靠运行。
DPC-16系列采用紧凑型模块化设计，既便于系统集成又简化配置监控流程。优质元器件保障了长期耐用性与稳定性能，同时支持I2C和SPI通信协议，可实现实时数据交换与远程控制功能。
该系列特别适用于可再生能源系统、工业自动化、通信设备和数据中心。在可再生能源领域，这些控制器对电力转换与储能管理起着关键作用；在工业环境中，可为电机驱动、机器人等高功率设备提供精准控制；其为通信基站和数据中心敏感电子元件提供稳定电力供应的能力尤为突出。
作为数字电源控制领域的尖端解决方案，DPC-16系列集先进技术、稳健设计和多功能性于一体，其可靠性、高效性和适应能力已成为跨行业工程师的首选方案。
系列图片（12 张）
常见问答
内容由 AI 生成，仅供参考
加载中...
DPC-16 - 型号列表共 12 个型号
| 制造商零件编号 | 价格/库存 | Standard Package | Subcategory | Lead Time | Secondary Winding(s) | Voltage - Secondary (Full Load) | Height - Seated (Max) | Mounting Type | Voltage - Isolation | Primary Winding(s) | Termination Style | Size / Dimension | Power - Max | Current - Output (Max) | Center Tap | Type | Voltage - Primary | rohs | Transformer Type | Primary Side Voltage | Secondary Side Voltage | Secondary Side Current | Power Rating | Primary Frequency | Mounting | Factory Pack Quantity | Product Category | Dimensions | Height | Width | Length | Isolation Voltage | RoHS | Frequency Range | Shielding | Maximum DC Current | Series | Product | Product Type | Other Names | Packaging | High Potential | Product Length | Secondary Side Connection | Lead Style | Product Depth | Number of Terminals | Primary Side Connection | Product Height | Secondary Configuration | Primary Frequency | Secondary Side Voltage | Secondary Side Current | Primary Configuration | Core Type | Primary Side Voltage | Pin Count | Mounting Style | Product Length (mm) | Product Depth (mm) | Product Height (mm) | Power Rating (W) or (VA) | 电流 - 输出（最大值） | 中心抽头 | 系列 | 高度 - 安装（最大值） | 次级绕组 | 初级绕组 | 电压 - 隔离 | 电压 - 初级 | 大小/尺寸 | 类型 | 功率 - 最大值 | 电压 - 次级（满负载） |
|---|
 DPC-16-55B55 Power Transformer 1500Vrms Dual Prim. Dual Sec. 115V/230V Prim. 16V/8V Sec. Through Hole pulse | 询价 | Bulk | Power Transformer | 70 Days | Dual | Parallel 8V, Series 16V | 21.08mm | Through Hole | 1500Vrms | Dual | PC Pin | 25.40mm L x 34.93mm W | 1 VA | Parallel 110mA, Series 55mA | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | Laminated Transformer | 115/230 V | 16|8 V | 55|110 mA | 1 VA | 47/500 Hz | Through Hole | 50 | Transformers Audio & Signal | 1 mm L x 1.375 mm W x 0.83 mm H | 0.83 mm | 1.375 mm | 1 mm | 1.5 kV | No | 47 Hz to 500 Hz | Unshielded | 55 mA | PC Plug-In | Laminated Low Frequency Tranformers | Laminated Transformers | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
DPC-16-1500B12 Power Transformer 1500Vrms Dual Prim. Dual Sec. 115V/230V Prim. 16V/8V Sec. Through Hole pulse | 询价 | Bulk | Power Transformer | 84 Days | Dual | Parallel 8V, Series 16V | 34.93mm | Through Hole | 1500Vrms | Dual | PC Pin | 41.28mm L x 57.15mm W | 24 VA | Parallel 3A, Series 1.5A | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | Laminated Transformer | 115/230 V | 16|8 V | 1500|3000 mA | 24 VA | 47/500 Hz | Through Hole | 12 | Transformers Audio & Signal | 1.625 mm L x 2.25 mm W x 1.375 mm H | 1.375 mm | 2.25 mm | 1.625 mm | 1.5 kV | No | 47 Hz to 500 Hz | Unshielded | 1500 mA | PC Plug-In | Laminated Low Frequency Tranformers | Laminated Transformers | - | Bulk | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
DPC-16-75B9 Power Transformer 1500Vrms Dual Prim. Dual Sec. 115V/230V Prim. 16V/8V Sec. Through Hole pulse | 询价 | Bulk | Power Transformer | 84 Days | Dual | Parallel 8V, Series 16V | 30.18mm | Through Hole | 1500Vrms | Dual | PC Pin | 34.93mm L x 28.58mm W | 1.2 VA | Parallel 150mA, Series 75mA | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | Laminated Transformer | 115/230 V | 16|8 V | 75|150 mA | 1.2 VA | 47/500 Hz | Through Hole | 40 | Transformers Audio & Signal | 1.375 mm L x 1.125 mm W x 1.188 mm H | 1.188 mm | 1.125 mm | 1.375 mm | 1.5 kV | No | - | - | - | - | - | - | - | - | 1500Vrms | 34.925 | Series|Parallel | PC Pin | 28.575 | 8 | Series|Parallel | 30.175 | Dual | 47/500 | 16|8 | 75|150 | Dual | Bobbin | 230|115 | 8 | Through Hole | 34.92 mm | 28.57 mm | 30.17 mm | 1.2 | Parallel 150mA, Series 75mA | No | PC Plug-In | 30.18mm | Dual | Dual | 1500Vrms | 115V, 230V | 34.93mm L x 28.58mm W | Laminated Core | 1.2 VA | Parallel 8V, Series 16V |
DPC-16-260B10 Power Transformer 1500Vrms Dual Prim. Dual Sec. 115V/230V Prim. 16V/8V Sec. Through Hole pulse | 询价 | Bulk | Power Transformer | 70 Days | Dual | Parallel 8V, Series 16V | 34.93mm | Through Hole | 1500Vrms | Dual | PC Pin | 41.28mm L x 31.75mm W | 4.4 VA | Parallel 520mA, Series 260mA | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | Laminated Transformer | 115/230 V | 16|8 V | 260|520 mA | 4.4 VA | 47/500 Hz | Through Hole | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
DPC-16-640B11 Power Transformer 1500Vrms Dual Prim. Dual Sec. 115V/230V Prim. 16V/8V Sec. Through Hole pulse | 询价 | Bulk | Power Transformer | 70 Days | Dual | Parallel 8V, Series 16V | 41.28mm | Through Hole | 1500Vrms | Dual | PC Pin | 47.63mm L x 36.53mm W | 10 VA | Parallel 1.28A, Series 640mA | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | Laminated Transformer | 115/230 V | 16|8 V | 640|1280 mA | 10 VA | 47/500 Hz | Through Hole | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 100 | Power Transformer | 56 Days | Dual | Parallel 8V, Series 16V | 34.92mm | Through Hole | 1500Vrms | Dual | PC Pin | 41.30mm L x 31.80mm W | 4.4 VA | Parallel 520mA, Series 260mA | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 50 | Power Transformer | 20 Days | Dual | Parallel 8V, Series 16V | 34.93mm | Through Hole | 1500Vrms | Dual | PC Pin | 41.30mm L x 57.20mm W | 24 VA | Parallel 3A, Series 1.5A | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 100 | Power Transformer | 56 Days | Dual | Parallel 8V, Series 16V | 30.15mm | Through Hole | 1500Vrms | Dual | PC Pin | 34.90mm L x 28.60mm W | 1.2 VA | Parallel 150mA, Series 75mA | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 595-1135 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 100 | Power Transformer | 56 Days | Dual | Parallel 8V, Series 16V | 21.08mm | Through Hole | 1500Vrms | Dual | PC Pin | 25.40mm L x 34.92mm W | 1 VA | Parallel 110mA, Series 55mA | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 50 | Power Transformer | 56 Days | Dual | Parallel 8V, Series 16V | 41.27mm | Through Hole | 1500Vrms | Dual | PC Pin | 47.60mm L x 36.50mm W | 10 VA | Parallel 1.28A, Series 640mA | No | Laminated Core | 115V, 230V | Lead free / RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 595-1137 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
共 12 个型号
