Würth Elektronik GmbH & Co. KG- 共模扼流圈
共模扼流圈 - 型号列表
共 264 个型号| 制造商零件编号 | 库存 | 价格 | 其他名称 | 标准包装数量 | RoHS | 电流 | 电感量 | 滤波器类型 | 直流电阻（DCR） | 最大额定电流 | 初始电阻（最小） | 深度 | 高度 | 长度 | 包装方式 | 高度（最大） | 柱间距 | 安装类型 | 封装形式 | 尺寸/外形 | 系列 | 线路数量 | 工作温度 | SVHC | 海关税号 | 核心类型 | 量程（°/s） | 额定直流电流 | 直流电阻（DCR）（最大） | 重量 | 磁芯材料 | 引脚数 | 容差 | 电感量范围 | 引脚直径 | 自谐振频率 | 总体尺寸 | 25°C时电阻（典型） | 导线线规 | 连接器间距 | 端接样式 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CHOKE POWER LINE 33MH .3A Wurth 33mH Manganese Zinc Ferrite Leaded Inductor, 300mA Idc, 2.5Ω Rdc CHOKE, COMMON MODE, 33MH 0.3A Wurth WE-FC 系列 33 mH 锰锌铁氧体 引线型电感器, 300mA Idc, 2.5Ω Rdc Wurth Electronics Inc | 284 | 1: ¥15.232 | 732-1680-5 | 345 | Compliant | 300mA | 33mH | Power Line | 2.5 Ohm | 300mA | 2.5Ω | 16.6mm | 22.5mm | 21.2mm | Tube | 0.886" (22.50mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.654" W (21.20mm x 16.60mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :300mA | :2.5ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 10MH .6A Wurth 10mH Manganese Zinc Ferrite Leaded Inductor, 600mA Idc, 710mΩ Rdc CHOKE, COMMON MODE, 10MH 0.6A Wurth WE-FC 系列 10 mH 锰锌铁氧体 引线型电感器, 600mA Idc, 710mΩ Rdc Wurth Electronics Inc | 197 | 1: ¥15.61 | 732-1677-5 | 348 | Compliant | 600mA | 10mH | Power Line | 710 mOhm | 600mA | 710mΩ | 16.6mm | 22.5mm | 21.2mm | Tube | 0.886" (22.50mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.654" W (21.20mm x 16.60mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :600mA | :0.71ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE TOROID 1.0MH 25A VERT WE-CMB Common Mode Choke XXL 1mH 25A CHOKE, COMMON MODE, 1MH 25A Wurth WE-CMB HC 系列 1 mH ±30% 铁氧体 引线型电感器, 0.1MHz最大自谐振频率, 25A Idc, 4.5mΩ Rdc Wurth Electronics Inc | 12 | 1: ¥141.372 | 732-3242 | 30 | Compliant | 25A | 1mH | Power Line | 3.6 mOhm | 25A | 4.5mΩ | 23.5mm | 43mm | 44mm | Tray | 1.693" (43.00mm) | 10mm | Through Hole | Vertical, 4 PC Pin | 1.732" L x 0.926" W (44.00mm x 23.50mm) | :WE-CMB | 2 | -40°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Common Mode | :WURTH ELEKTRONIK - WE-CMB Series | :25A | :0.0036ohm | 0.0423 | Ferrite | :4 | ±30% | :± 30% | 2mm | 100kHz | :44mm x 23.5mm x 43mm | - | - | - | - |
 CHOKE TOROID .5MH 35A VERT WE-CMB Common Mode Choke XXL 0.5mH 35A CHOKE, COMMON MODE, 0.5MH 35A Wurth WE-CMB HC 系列 500 μH ±30% 铁氧体 引线型电感器, 0.1MHz最大自谐振频率, 35A Idc, 2.3mΩ Rdc Wurth Electronics Inc | 10 | 1: ¥174.6465 | 732-3243 | 30 | Compliant | 35A | 500µH | Power Line | 1.7 mOhm | 35A | 2.3mΩ | 23.5mm | 43mm | 47mm | Tray | 1.693" (43.00mm) | 10.5mm | Through Hole | Vertical, 4 PC Pin | 1.850" L x 0.926" W (47.00mm x 23.50mm) | :WE-CMB | 2 | -40°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Common Mode | :WURTH ELEKTRONIK - WE-CMB Series | :35A | :0.0017ohm | 0.0423 | Ferrite | :4 | ±30% | :± 30% | 2.5mm | 100kHz | :47mm x 23.5mm x 43mm | - | - | - | - |
 CHOKE TOROID 1.3MH 20A VERT WE-CMB Common Mode Choke XXL 1.3mH 20A CHOKE, COMMON MODE, 1.3MH 20A Wurth WE-CMB HC 系列 1.3 mH ±30% 铁氧体 引线型电感器, 0.01MHz最大自谐振频率, 20A Idc, 6.2mΩ Rdc Wurth Electronics Inc | 10 | 1: ¥121.254 | 732-3241 | 30 | Compliant | 20A | 1.3mH | Power Line | 4.7 mOhm | 20A | 6.2mΩ | 23.5mm | 43mm | 43.5mm | Tray | 1.693" (43.00mm) | 10mm | Through Hole | Vertical, 4 PC Pin | 1.713" L x 0.926" W (43.50mm x 23.50mm) | :WE-CMB | 2 | -40°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Common Mode | :WURTH ELEKTRONIK - WE-CMB Series | :20A | :0.0047ohm | 0.0423 | Ferrite | :4 | ±30% | :± 30% | 1.8mm | 10kHz | - | - | - | - | - |
 CHOKE TOROID 1.8MH 14A VERT WE-CMB Common Mode Choke XXL 1.8mH 14A CHOKE, COMMON MODE, 1.8MH 14A Wurth WE-CMB HC 系列 1.8 mH ±30% 铁氧体 引线型电感器, 0.01MHz最大自谐振频率, 14A Idc, 9.5mΩ Rdc Wurth Electronics Inc | 138 | 1: ¥141.372 | 732-3240 | 30 | Compliant | 14A | 1.8mH | Power Line | 7.9 mOhm | 14A | 9.5mΩ | 23.5mm | 43mm | 43mm | Tray | 1.693" (43.00mm) | 10mm | Through Hole | Vertical, 4 PC Pin | 1.693" L x 0.926" W (43.00mm x 23.50mm) | :WE-CMB | 2 | -40°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Common Mode | :WURTH ELEKTRONIK - WE-CMB Series | :14A | :0.0079ohm | 0.0423 | Ferrite | :4 | ±30% | :± 30% | 1.5mm | 10kHz | :43mm x 23.5mm x 43mm | - | - | - | - |
 CHOKE POWER LINE .82MH 2.0A Wurth 820μH Manganese Zinc Ferrite Leaded Inductor, 2A Idc, 70mΩ Rdc CHOKE, COMMON MODE, 820UH 2A Wurth WE-FC 系列 820 μH 锰锌铁氧体 引线型电感器, 2A Idc, 70mΩ Rdc Wurth Electronics Inc | 92 | 29: ¥10.817 | 732-1668-5 | 29 | Compliant | 2A | 820µH | Power Line | 70 mOhm | 2A | 70mΩ | 16.6mm | 22.5mm | 21.2mm | Tube | 0.886" (22.50mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.654" W (21.20mm x 16.60mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :2A | :0.065ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 3.3MH 1.2A Wurth 3.3mH Manganese Zinc Ferrite Leaded Inductor, 1.2A Idc, 210mΩ Rdc CHOKE, COMMON MODE, 3.3MH 1.2A Wurth WE-FC 系列 3.3 mH 锰锌铁氧体 引线型电感器, 1.2A Idc, 210mΩ Rdc Wurth Electronics Inc | 26 | 1: ¥15.61 | 732-1673-5 | 345 | Compliant | 1.2A | 3.3mH | Power Line | 210 mOhm | 1.2A | 210mΩ | 16.6mm | 22.5mm | 21.2mm | Tube | 0.886" (22.50mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.654" W (21.20mm x 16.60mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :1.2A | :0.21ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 6.8MH .7A Wurth 6.8mH Manganese Zinc Ferrite Leaded Inductor, 700mA Idc, 470mΩ Rdc CHOKE, COMMON MODE, 6.8MH 0.7A Wurth WE-FC 系列 6.8 mH 锰锌铁氧体 引线型电感器, 700mA Idc, 470mΩ Rdc Wurth Electronics Inc | 14 | 1: ¥20.11 | 732-1676-5 | 345 | Compliant | 700mA | 6.8mH | Power Line | 470 mOhm | 700mA | 470mΩ | 16.6mm | 22.5mm | 21.2mm | Tube | 0.886" (22.50mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.654" W (21.20mm x 16.60mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :700mA | :0.47ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 22MH .4A Wurth 22mH Manganese Zinc Ferrite Leaded Inductor, 400mA Idc, 1.64Ω Rdc CHOKE, COMMON MODE, 22MH 0.4A Wurth Electronics Inc | 10 | 1: ¥13.532 | 732-1679-5 | 345 | Compliant | 400mA | 22mH | Power Line | 1.64 Ohm | 400mA | 1.64Ω | 16.6mm | 22.5mm | 21.2mm | Tube | 0.886" (22.50mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.654" W (21.20mm x 16.60mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :400mA | :1.64ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE .82MH 2.0A Wurth 0.82mH Manganese Zinc Ferrite Leaded Inductor, 2A Idc, 70mΩ Rdc CHOKE, COMMON MODE, 0.82MH 2A Wurth WE-FC 系列 820 μH 锰锌铁氧体 引线型电感器, 2A Idc, 70mΩ Rdc Wurth Electronics Inc | 141 | 1: ¥13.16 | 732-1657-5 | 345 | Compliant | 2A | 820µH | Power Line | 70 mOhm | 2A | 70mΩ | 21.2mm | 17.8mm | 21.2mm | Tube | 0.701" (17.80mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.835" W (21.20mm x 21.20mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :2A | :0.065ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 1.8MH 1.5A Wurth 1.8mH Manganese Zinc Ferrite Leaded Inductor, 1.5A Idc, 150mΩ Rdc CHOKE, COMMON MODE, 1.8MH 1.5A Wurth WE-FC 系列 1.8 mH 锰锌铁氧体 引线型电感器, 1.5A Idc, 150mΩ Rdc Wurth Electronics Inc | 23 | 1: ¥26.83 | 732-1658-5 | 345 | Compliant | 1.5A | 1.8mH | Power Line | 150 mOhm | 1.5A | 150mΩ | 21.2mm | 17.8mm | 21.2mm | Tube | 0.701" (17.80mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.835" W (21.20mm x 21.20mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :1.5A | :0.15ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 3.3MH 1.1A Wurth 3.3mH Manganese Zinc Ferrite Leaded Inductor, 1.1A Idc, 250mΩ Rdc CHOKE, COMMON MODE, 3.3MH 1.1A Wurth WE-FC 系列 3.3 mH 锰锌铁氧体 引线型电感器, 1.1A Idc, 250mΩ Rdc Wurth Electronics Inc | 23 | 23: ¥11.32 | 732-1660-5 | 345 | Compliant | 1.1A | 3.3mH | Power Line | 250 mOhm | 1.1A | 250mΩ | 21.2mm | 17.8mm | 21.2mm | Tube | 0.701" (17.80mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.835" W (21.20mm x 21.20mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :1.1A | :0.25ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 6.8MH .8A Wurth 6.8mH Manganese Zinc Ferrite Leaded Inductor, 800mA Idc, 480mΩ Rdc CHOKE, COMMON MODE, 6.8MH 0.8A Wurth Electronics Inc | 2932 | 1: ¥20.0124 | 732-1663-5 | 345 | Compliant | 800mA | 6.8mH | Power Line | 480 mOhm | 800mA | 480mΩ | 21.2mm | 17.8mm | 21.2mm | Tube | 0.701" (17.80mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.835" W (21.20mm x 21.20mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :800mA | :0.48ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 10MH .6A Wurth 10mH Manganese Zinc Ferrite Leaded Inductor, 600mA Idc, 720mΩ Rdc CHOKE, COMMON MODE, 10MH 0.6A Wurth WE-FC 系列 10 mH 锰锌铁氧体 引线型电感器, 600mA Idc, 720mΩ Rdc Wurth Electronics Inc | 20 | 1: ¥23.82 | 732-1664-5 | 345 | Compliant | 600mA | 10mH | Power Line | 720 mOhm | 600mA | 720mΩ | 21.2mm | 17.8mm | 21.2mm | Tube | 0.701" (17.80mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.835" W (21.20mm x 21.20mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :600mA | :0.72ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 22MH .4A Wurth 22mH Manganese Zinc Ferrite Leaded Inductor, 400mA Idc, 1.61Ω Rdc CHOKE, COMMON MODE, 22MH 0.4A Wurth Electronics Inc | 2932 | 1: ¥20.0124 | 732-1666-5 | 345 | Compliant | 400mA | 22mH | Power Line | 1.61 Ohm | 400mA | 1.61Ω | 21.2mm | 17.8mm | 21.2mm | Tube | 0.701" (17.80mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.835" W (21.20mm x 21.20mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :400mA | :1.61ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE POWER LINE 33MH .3A Wurth 33mH Manganese Zinc Ferrite Leaded Inductor, 300mA Idc, 2Ω Rdc CHOKE, COMMON MODE, 33MH 0.3A Wurth WE-FC 系列 33 mH 锰锌铁氧体 引线型电感器, 300mA Idc, 2Ω Rdc Wurth Electronics Inc | 10 | 1: ¥13.16 | 732-1667-5 | 345 | Compliant | 300mA | 33mH | Power Line | 2 Ohm | 300mA | 2Ω | 21.2mm | 17.8mm | 21.2mm | Tube | 0.701" (17.80mm) | 13mm | Through Hole | Vertical, 4 PC Pin | 0.835" L x 0.835" W (21.20mm x 21.20mm) | :WE-FC | 2 | -25°C ~ 125°C | :No SVHC (20-Jun-2013) | 85045095 | :Line Filter | :WURTH ELEKTRONIK - WE-FC Series | :300mA | :2ohm | 0.0148 | Manganese Zinc Ferrite | :4 | - | - | - | - | - | - | - | - | - |
 CHOKE COMMON MODE HC 700UH VERT Wurth 700μH ±30% Leaded Inductor, 5A Idc, 13mΩ Rdc Wurth WE-CMB HC 系列 700 μH ±30% 引线型电感器, 5A Idc, 13mΩ Rdc Wurth Electronics Inc | 974 | 1: ¥40.392 | 732-3882 | 80 | Compliant | 5A | 700µH | Power Line | 13 mOhm | 5A | 13mΩ | 14.5mm | 22mm | 18.5mm | Tray | 0.866" (22.00mm) | 5mm | Through Hole | Vertical, 4 PC Pin | 0.728" L x 0.571" W (18.50mm x 14.50mm) | WE-CMB HC | 2 | -40°C ~ 125°C | - | - | - | - | - | - | - | - | - | ±30% | 700 μH | 1mm | - | - | 13mΩ | 1mm | 5mm | 通孔安装 |
CHOKE COMMON MODE HC 450UH VERT Wurth 450μH ±30% Leaded Inductor, 6.5A Idc, 8.1mΩ Rdc Wurth WE-CMB HC 系列 450 μH ±30% 引线型电感器, 6.5A Idc, 8.1mΩ Rdc Wurth Electronics Inc | 413 | 1: ¥40.392 | 732-3883 | 80 | Compliant | 6.5A | 450µH | Power Line | 8.1 mOhm | 6.5A | 8.1mΩ | 14.5mm | 22mm | 18.5mm | Tray | 0.866" (22.00mm) | 5mm | Through Hole | Vertical, 4 PC Pin | 0.728" L x 0.571" W (18.50mm x 14.50mm) | WE-CMB HC | 2 | -40°C ~ 125°C | - | - | - | - | - | - | - | - | - | ±30% | 450 μH | 1mm | - | - | 8.1mΩ | 1mm | 5mm | 通孔安装 |
CHOKE COMMON MODE HC 350UH VERT Wurth 350μH ±30% Leaded Inductor, 8.5A Idc, 5.5mΩ Rdc Wurth WE-CMB HC 系列 350 μH ±30% 引线型电感器, 8.5A Idc, 5.5mΩ Rdc Wurth Electronics Inc | 59 | 1: ¥40.392 | 732-3884 | 80 | Compliant | 8.5A | 350µH | Power Line | 5.5 mOhm | 8.5A | 5.5mΩ | 14.5mm | 22mm | 18.5mm | Tray | 0.866" (22.00mm) | 5mm | Through Hole | Vertical, 4 PC Pin | 0.728" L x 0.571" W (18.50mm x 14.50mm) | WE-CMB HC | 2 | -40°C ~ 125°C | - | - | - | - | - | - | - | - | - | ±30% | 350 μH | 1mm | - | - | 5.5mΩ | 1mm | 5mm | 通孔安装 |
