Weidmüller Holding AG & Co. KG- 光纤连接器适配器
03
光纤连接器适配器 - 型号列表
共 22 个型号| 制造商零件编号 | 库存 | 价格 | 标准包装数量 | RoHS | IEC标准 | 频率 | 重量 | 第一连接器 | 安装类型 | 壳体材料 | 连接器颜色 | 连接器/触点类型 | 第二连接器安装类型 | 工作模式 | 类型 | ETIM 6*0 | 光纤类型 | GTIN（EAN） | 固件版本 | 转换端（适配器端） | 转换自（适配器端） | 插拔次数 | ET（伏秒积） | 防护等级 | 工作温度 | 其他名称 | 颜色 | 保护特性 | 回波损耗 | 插入损耗 | 外壳镀层 | 单工/双工 | 描述 | 标准编号 | 材料阻燃等级 | 认证机构 | 系列 | 电流 - UL | 制造商全称 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 10 | 5: ¥159.12 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 29.3 g | SC | Panel Mount, Flange | Polyamide (PA), Nylon | Miscellaneous | IEC 61076-3-106 Var. 4, IEC 61754-4, IEC 61754-24 | SCRJ | Singlemode | Adapter | EC001122 | Singlemode | 4032248645510 | Flange FO, IP67, Version 4, coupling from SCRJ on 2*SC, Singlemode | SCRJ Receptacle | SC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-PS-V04P-2SCRJ2SC-SM-C | Black | IP67 | ≥ 40 dB | ≤ 0.5 dB | NBR | - | Version 4, coupling from SCRJ on 2*SC | 30-21-18-17 | UL94 V-0 | POCC DE.ME25.B01411.pdf | - | - | - |
 | 10 | 1: ¥318.24 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 28.7 g | SC | Panel Mount, Flange | Polyamide (PA), Nylon | Miscellaneous | IEC 61076-3-106 Var. 4, IEC 61754-4, IEC 61754-24 | SCRJ | Multimode | Coupler | EC001122 | Multimode, POF | 4032248649075 | Flange FO, IP67, Version 4, coupling from SCRJ on 2*SC, Multimode, POF | SCRJ Receptacle | SCRJ Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BS-V04P-SCRJ2SC-MM-C | Gray | IP67 | ≥ 30 dB | ≤ 0.4 dB | NBR | - | Version 4, coupling from SCRJ on 2*SC | 30-21-18-17 | UL94 V-0 | POCC DE.ME25.B01411.pdf | - | - | - |
 | 49 | 6: ¥126.412 | 1 | Lead free / RoHS Compliant | 24-44-03-20 | 19-17-01-25 | 39.3 g | SC-Duplex | DIN Rail | Polyamide (PA), Nylon | Light Grey | IEC 61754-4 | SC-Duplex | POF | Coupler | EC000313 | Singlemode | 4032248734993 | Mounting rail outlet, fibre-optic, SC duplex, Singlemode, IP20 | SC Receptacle | SC Receptacle | 1000 | EC000018 | IP20 | -40°C ~ 70°C | IE-TO-SCD-SM | Blue | IP20 | - | - | - | Duplex | - | 30-21-18-01 | UL94 V-0 | - | * | MLE477798 | - |
 | 10 | 1: ¥315.248 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 26.69 g | SCRJ | Panel Mount, Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-117 Var. 14, IEC 61754-24 | SCRJ | Singlemode | Coupler | EC001122 | Singlemode | 4032248799251 | Flange FO, Variant 14 standardized flange, SCRJ Duplex coupling, Singlemode | SCRJ Receptacle | SCRJ Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-FCM-RJ45-C | Silver | - | ≥ 40 dB | ≤ 0.5 dB | EPDM | Duplex | Variant 14 standardized flange, SCRJ Duplex coupling | - | - | - | - | - | - |
 | 10 | 1: ¥322.184 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 26.86 g | SCRJ | Panel Mount, Flange (2 Hole) | Zinc Die Cast | Miscellaneous | IEC 61076-3-117 Var. 14, IEC 61754-24 | SCRJ | POF | Coupler | EC001122 | Multimode, POF | 4032248799237 | Flange FO, Variant 14 standardized flange, SCRJ Duplex coupling, Multimode, POF | SCRJ Receptacle | SCRJ Receptacle | 500 | EC001121 | 27-26-12-03 | -40°C ~ 70°C | IE-PH-V01P-RJ45-FH-BP | - | - | ≥ 30 dB | ≤ 0.4 dB | EPDM | Duplex | Variant 14 standardized flange, SCRJ Duplex coupling | - | - | - | * | - | - |
 | 10 | 1: ¥369.58 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 25.3 g | LC Duplex | Panel Mount, Flange | Polyamide (PA), Nylon | Miscellaneous | IEC 61076-3-106 Var. 4, IEC 61754-20 | LC Duplex | Multimode | Coupler | EC001122 | Multimode | 4032248651924 | Flange FO, IP67, Version 4, LC Duplex coupling, Multimode | LC Receptacle | LC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BS-V04P-LCD-MM-C | Gray | IP67 | ≥ 30 dB | ≤ 0.4 dB | NBR | Duplex | Version 4, LC Duplex coupling | 30-21-18-17 | UL94 V-0 | POCC DE.ME25.B01411.pdf | - | - | - |
 | 10 | 1: ¥369.58 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 26.7 g | LC Duplex | Panel Mount, Flange | Polyamide (PA), Nylon | Miscellaneous | IEC 61076-3-106 Var. 4, IEC 61754-20 | LC Duplex | Singlemode | Coupler | EC001122 | Singlemode | 4032248645541 | Flange FO, IP67, Version 4, LC Duplex coupling, Singlemode | LC Receptacle | LC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BS-V04P-LCD-SM-C | Black | IP67 | ≥ 40 dB | ≤ 0.5 dB | NBR | Duplex | Version 4, LC Duplex coupling | 30-21-18-17 | UL94 V-0 | POCC DE.ME25.B01411.pdf | - | - | - |
 | 10 | 1: ¥365.16 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 24.81 g | LC Duplex | Panel Mount, Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-117 Var. 14, IEC 61754-20 | LC Duplex | Singlemode | Coupler | EC001122 | Singlemode | 4032248799268 | Flange FO, Variant 14 standardized flange, LC Duplex coupling, Singlemode | LC Receptacle | LC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-FCM-RJ45-FJ-A | Silver | - | ≥ 40 dB | ≤ 0.5 dB | EPDM | Duplex | Variant 14 standardized flange, LC Duplex coupling | - | - | - | - | - | - |
 | 10 | 1: ¥365.16 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 24.7 g | LC Duplex | Panel Mount, Flange (2 Hole) | Zinc Die Cast | Miscellaneous | IEC 61076-3-117 Var. 14, IEC 61754-20 | LC Duplex | Multimode | Coupler | EC001122 | Multimode | 4032248799244 | Flange FO, Variant 14 standardized flange, LC Duplex coupling, Multimode | LC Receptacle | LC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | - | Beige | - | ≥ 30 dB | ≤ 0.4 dB | EPDM | Duplex | Variant 14 standardized flange, LC Duplex coupling | - | - | - | - | - | - |
 | 10 | 1: ¥468.996 | 1 | Lead free / RoHS Compliant | 24-44-03-20 | 19-17-01-25 | 38.7 g | SCRJ | DIN Rail | Polyamide (PA), Nylon | Light Grey | IEC 61754-24 | SCRJ | POF | Coupler | EC000313 | Multimode, POF | 4032248735006 | Mounting rail outlet, fibre-optic, SCRJ, Multimode, POF, IP20 | SC Receptacle | SC Receptacle | 1000 | EC000018 | IP20 | -40°C ~ 70°C | IE-TO-SCRJ-MM | Beige | IP20 | - | - | - | Duplex | - | 30-21-18-01 | UL94 V-0 | - | * | MLE477798 | PN Manufacturer Declaration.pdf |
 | 10 | 1: ¥468.996 | 1 | Lead free / RoHS Compliant | 24-44-03-20 | 19-17-01-25 | 38.1 g | SCRJ | DIN Rail | Polyamide (PA), Nylon | Light Grey | IEC 61754-24 | SCRJ | Singlemode | Coupler | EC000313 | Singlemode | 4032248735013 | Mounting rail outlet, fibre-optic, SCRJ, Singlemode, IP20 | SC Receptacle | SC Receptacle | 1000 | EC000018 | IP20 | -40°C ~ 70°C | IE-TO-SCRJ-SM | Blue | IP20 | - | - | - | Duplex | - | 30-21-18-01 | UL94 V-0 | - | * | MLE477798 | PN Manufacturer Declaration.pdf |
 | 10 | 1: ¥693.872 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 55.72 g | SCRJ | Panel Mount, Square Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-117 Var. 14, IEC 61754-24 | SCRJ | Multimode | Coupler | EC001122 | Multimode, POF | 4032248813100 | Flange FO, IP67, Variant 14 central cable gland, SCRJ Duplex coupling, Multimode, POF | SCRJ Receptacle | SCRJ Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BSC-V14M-SCRJ-MM-C | Silver | IP67 | ≥ 30 dB | ≤ 0.4 dB | NBR | Duplex | Variant 14 central cable gland, SCRJ Duplex coupling | - | - | - | - | - | - |
 | 10 | 1: ¥415.004 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 55.81 g | SCRJ | Panel Mount, Square Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-117 Var. 14, IEC 61754-24 | SCRJ | Singlemode | Coupler | EC001122 | Singlemode | 4032248813315 | Flange FO, IP67, Variant 14 central cable gland, SCRJ Duplex coupling, Singlemode | SCRJ Receptacle | SCRJ Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BSC-V14M-SCRJ-SM-C | Silver | IP67 | ≥ 40 dB | ≤ 0.5 dB | NBR | Duplex | Variant 14 central cable gland, SCRJ Duplex coupling | - | - | - | - | - | - |
 | 10 | 1: ¥480.012 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 63.9 g | SCRJ | Panel Mount, Square Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-106 Var. 1, IEC 61754-24 | SCRJ | Multimode | Coupler | EC001122 | Multimode, POF | 4050118003949 | Flange FO, IP67, Multimode, POF | SCRJ Receptacle | SCRJ Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BS-V01M-SCRJ-MM | Silver | IP67 | ≥ 30 dB | ≤ 0.4 dB | NBR | - | - | - | - | - | - | - | - |
 | 10 | 1: ¥464.78 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 52.9 g | LC Duplex | Panel Mount, Square Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-117 Var. 14, IEC 61754-20 | LC Duplex | Multimode | Coupler | EC001122 | Multimode | 4032248813322 | Flange FO, IP67, Variant 14 central cable gland, LC Duplex coupling, Multimode | LC Receptacle | LC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BSC-V14M-LCD-MM-C | Silver | IP67 | ≥ 30 dB | ≤ 0.4 dB | NBR | Duplex | Variant 14 central cable gland, LC Duplex coupling | - | - | - | - | - | - |
 | 10 | 1: ¥464.78 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 52.51 g | LC Duplex | Panel Mount, Square Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-117 Var. 14, IEC 61754-20 | LC Duplex | Singlemode | Coupler | EC001122 | Singlemode | 4032248813339 | Flange FO, IP67, Variant 14 central cable gland, LC Duplex coupling, Singlemode | LC Receptacle | LC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BSC-V14M-LCD-SM-C | Silver | IP67 | ≥ 40 dB | ≤ 0.5 dB | NBR | Duplex | Variant 14 central cable gland, LC Duplex coupling | - | - | - | - | - | - |
 | 5000 | 1: ¥470.288 | 1 | Lead free / RoHS Compliant | 24-44-03-20 | 19-17-01-25 | 32.5 g | LC Duplex | DIN Rail | Polyamide (PA), Nylon | Light Grey | IEC 61754-20 | LC Duplex | Multimode | Coupler | EC000313 | Multimode | 4032248735020 | Mounting rail outlet, fibre-optic, LC Duplex, Multimode, IP20 | LC Receptacle | LC Receptacle | 1000 | EC000018 | IP20 | -40°C ~ 70°C | IE-TO-LCD-MM | Beige | IP20 | - | - | - | Duplex | - | 30-21-18-01 | UL94 V-0 | - | - | - | - |
 | 10 | 1: ¥553.928 | 1 | Lead free / RoHS Compliant | 24-44-03-20 | 19-17-01-25 | 35 g | LC Duplex | DIN Rail | Polyamide (PA), Nylon | Light Grey | IEC 61754-20 | LC Duplex | Singlemode | Coupler | EC000313 | Singlemode | 4032248735037 | Mounting rail outlet, fibre-optic, LC Duplex, Singlemode, IP20 | LC Receptacle | LC Receptacle | 1000 | EC000018 | IP20 | -40°C ~ 70°C | IE-TO-LCD-SM | Blue | IP20 | - | - | - | Duplex | - | 30-21-18-01 | UL94 V-0 | - | - | - | - |
 | 10 | 1: ¥616.692 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 60.5 g | SC | Panel Mount, Square Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-106 Var. 1, IEC 61754-4, IEC 61754-24 | SCRJ | Multimode | Adapter | EC001122 | Multimode | 4032248649068 | Flange FO, IP67, Version 1, coupling from SCRJ on 2*SC, Multimode | SCRJ Receptacle | SC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BS-V01M-SCRJ2SC-MM | Silver | IP67 | ≥ 30 dB | ≤ 0.4 dB | NBR | - | Version 1, coupling from SCRJ on 2*SC | 30-21-18-17 | - | POCC DE.ME25.B01411.pdf | - | - | - |
 | 10 | 1: ¥616.692 | 1 | Lead free / RoHS Compliant | 19-07-01-22 | 19-17-01-25 | 62.7 g | SC | Panel Mount, Square Flange | Zinc Die Cast | Miscellaneous | IEC 61076-3-106 Var. 1, IEC 61754-4, IEC 61754-24 | SCRJ | Singlemode | Adapter | EC001122 | Singlemode | 4032248645534 | Flange FO, IP67, Version 1, coupling from SCRJ on 2*SC, Singlemode | SCRJ Receptacle | SC Receptacle | 500 | EC001121 | IP67 - Dust Tight, Waterproof | -40°C ~ 70°C | IE-BS-V01M-SCRJ2SC-SM | Silver | IP67 | ≥ 40 dB | ≤ 0.5 dB | NBR | - | Version 1, coupling from SCRJ on 2*SC | 30-21-18-17 | - | POCC DE.ME25.B01411.pdf | - | - | - |
第 1 / 2 页
