封闭式AC-DC转换器
TRACO Electronic AG- 封闭式AC-DC转换器
封闭式AC-DC转换器 - 型号列表
共 221 个型号| 制造商零件编号 | 库存 | 价格 | 海关税号 | 噪声 | 效率 | 输出类型 | 最大功率 | 额定功率 | 额定电压 | 电源调整率 | 负载调整率 | 输出电流 | 输出数量 | 最小输入电压 | 深度 | 宽度 | 长度 | 重量 | 冷却的封装 | 工作温度 | 最高温度限值 | 高度 | 动作时间 | 频率 | 应用 | 供电电压 | 认证机构 | 供电类型 | 安装类型 | 输出电流2 | 输出电压2（可调范围） | 输出功率 | 隔离电压 | 最大频率 | 最低频率 | 输出纹波电压 | 最大持续工作电压（MCOV） | 输出电流 3 | 输出电压3 | 输出电压（最大） | 输出电压（最小/固定） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Power Supply,Encapsulated,IP67,15V 0.8A PSU, AC/DC, 0.8A, 12W, MODULE TRACOPOWER 12W 单输出 嵌入式开关模式电源 SMPS , 93 → 264V ac输入, 15V dc输出, 800mA输出, 80%效能, 密封封装 TRACOPOWER | 24 | 1: ¥288.29 | 85044082 | 500mV Pk-Pk | 80% | :Fixed | :12W | 12W | 93 → 264V ac | ±1% | ±2% | 0.8A | 1 | :93V to 264V | 23.6mm | 48mm | 50.2mm | 80g | Encapsulated | -25°C | +50°C | :23.6mm | - | :63Hz | :General Purpose | :115V AC, 230V AC | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Chassis mount power supply,TMP, 24V 15W CONVERTER, AC/DC, 24V, 0.6A/15W, MODULE TRACOPOWER 15W 单输出 嵌入式开关模式电源 SMPS , 120 → 370 V dc, 85 → 264 V ac输入, 24V dc输出, 625mA输出, 79%效能 TRACOPOWER | 66 | 1: ¥306.54 | 85044082 | ±1% | 79% | :Fixed | :15W | 15W | 120 → 370 V dc, 85 → 264 V ac | ±1% | ±1% | 625mA | 1 | :85V to 264V, 100V to 240V | 23.3mm | 54mm | 96mm | 162g | Encapsulated | -25°C | +60°C | :23.3mm | 280000h | - | - | :115V AC, 230V AC | :CB, EN, IEC, UL | :Enclosed | :Chassis | - | - | - | - | - | - | - | - | - | - | - | - |
Chassis mt power supply,TMP, +/-12V 15W CONVERTER, AC/DC, ±12V, 0.7A/15W, MOD. TRACOPOWER 15W 2输出 嵌入式开关模式电源 SMPS , 120 → 370 V dc, 85 → 264 V ac输入, ±12V dc输出, 650mA输出, 79%效能 TRACOPOWER | 17 | 1: ¥350.81 | 85044082 | ±1% | 79% | :Fixed | :15W | 15W | 120 → 370 V dc, 85 → 264 V ac | ±3% | ±2.5 %, ±5 % | 650mA | 2 | :85V to 264V, 100V to 240V | 23.3mm | 54mm | 96mm | 162g | Encapsulated | -25°C | +60°C | :23.3mm | 280000h | - | - | :115V AC, 230V AC | :CB, EN, IEC, UL | :Enclosed | :Chassis | :650mA | :-12V | - | - | - | - | - | - | - | - | - | - |
 TXL universal input SMPSU,24V 150W POWER SUPPLY, 24V, 150W TRACOPOWER 150W 单输出 嵌入式开关模式电源 SMPS , 85 → 264V ac输入, 24V dc输出, 6.3A输出, 70 → 84%效能, 封闭封装 TRACOPOWER | 303 | 1: ¥726.14 | 85044082 | ±1% | 70 → 84% | :Adjustable, Fixed | :150W | 150W | 120 → 375 V dc, 85 → 264 V ac | ±1% | ±2% | 6.3A | 1 | :85V to 264V | 50mm | 99mm | 211mm | 0.89kg | Enclosed | -10°C | +70°C | - | 250000h | - | - | - | :EN | :Switch Mode | :Chassis | - | - | - | - | - | - | - | - | - | - | - | - |
TXL series univ input SMPSU,48V 100W PSU, ENCLOSED, 100W, 48V TRACOPOWER 100W 单输出 嵌入式开关模式电源 SMPS , 85 → 264V ac输入, 48V dc输出, 2.3A输出, 70 → 84%效能, 封闭封装 TRACOPOWER | 23 | 1: ¥564.44 | 85044082 | ±1% | 70 → 84% | :Adjustable, Fixed | :100W | 100W | 120 → 375 V dc, 85 → 264 V ac | ±1% | ±2% | 2.3A | 1 | :85V to 264V, 100V to 240V | 38mm | 95mm | 208mm | 0.8kg | Enclosed | -10°C | +70°C | :38mm | 250000h | :63Hz | - | :50Hz | :EN | :Switch Mode | :Chassis | - | - | :100W | :3000VAC | :63Hz | :47Hz | :1.5% | :264VAC | - | - | - | - |
 Power Supply,Encap.,chassis,+/-5V 20W PSU, AC/DC, ±2A, 20W, MODULE TRACOPOWER 20W 2输出 嵌入式开关模式电源 SMPS , 100 → 375 V dc, 90 → 264 V ac输入, ±5V dc输出, 2A输出 TRACOPOWER | 35 | 1: ¥475.64 | 85044082 | ±0.7% | 75 → 84% | :Adjustable, Fixed | :20W | 20W | 100 → 375 V dc, 90 → 264 V ac | ±0.5% | ±3% | 2000mA | 2 | :90V to 264V | 27.6mm | 54.6mm | 96mm | 155g | Encapsulated | -25°C | +60°C | :27.6mm | 200000h | :440Hz | :General Purpose | - | - | - | - | :-2A | :-5V | - | - | - | - | - | - | - | - | - | - |
Power Supply,Encap.,chassis,3.3V 14.9W PSU, AC/DC, 4.5A, 20W, MODULE TRACOPOWER 14.9W 单输出 嵌入式开关模式电源 SMPS , 100 → 375 V dc, 90 → 264 V ac输入, 3.3V dc输出, 4.5A输出 TRACOPOWER | 10 | 1: ¥399.17 | 85044082 | ±0.7% | 75 → 84% | :Adjustable, Fixed | :14.9W | 14.9W | 100 → 375 V dc, 90 → 264 V ac | ±0.5% | ±1% | 4500mA | 1 | :90V to 264V | 27.6mm | 54.6mm | 96mm | 155g | Encapsulated | -25°C | +60°C | :27.6mm | 200000h | :440Hz | :General Purpose | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 TML chassis mount univ i/p SMPSU,12V 30W PSU, ENCAPSULATED, 30W, 12V TRACOPOWER 30W 单输出 嵌入式开关模式电源 SMPS , 100 → 370 V dc, 85 → 264 V ac输入, 12V dc输出, 2.5A输出 TRACOPOWER | 11 | 1: ¥675.28 | 85044082 | ±1% | 72 → 80% | :Fixed | :30W | 30W | 100 → 370 V dc, 85 → 264 V ac | ±0.3% | ±1% | 2500mA | 1 | :85V to 264V | 31mm | 64.7mm | 112mm | 275g | Encapsulated | -25°C | +60°C | :31mm | 660000h | :440Hz | :General Purpose | :264V | :CE, UL | :Switch Mode | :Chassis | - | - | :30W | :3000VAC | - | - | - | - | - | - | - | - |
TXL universal input SMPSU,3.3V 35W AC/DC, 3.3V, 9A TRACOPOWER 35W 单输出 嵌入式开关模式电源 SMPS , 120 → 375 V dc, 85 → 264 V ac输入, 3.3V dc输出, 9A输出 TRACOPOWER | 19 | 1: ¥315.21 | 85044090 | 50mV | 70 → 84% | :Fixed | :35W | 35W | 120 → 375 V dc, 85 → 264 V ac | ±1% | ±2% | 9A | 1 | :85V to 264V | 35mm | 82mm | 109mm | 0.3kg | Enclosed | -10°C | +70°C | :82mm | 250000h | - | :General Purpose | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Chassis mt power supply,TMP, +/-15V 15W CONVERTER, AC/DC, ±15V, 0.5A/15W, MOD. TRACOPOWER 15W 2输出 嵌入式开关模式电源 SMPS , 120 → 370 V dc, 85 → 264 V ac输入, ±15V dc输出, 500mA输出, 79%效能 TRACOPOWER | 12 | 1: ¥310.148 | 85044082 | ±1% | 79% | :Fixed | :15W | 15W | 120 → 370 V dc, 85 → 264 V ac | ±3% | ±2.5 %, ±5 % | 500mA | 2 | :85V to 264V, 100V to 240V | 23.3mm | 54mm | 96mm | 162g | Encapsulated | -25°C | +60°C | :23.3mm | 280000h | - | - | :115V AC, 230V AC | :CB, EN, IEC, UL | :Enclosed | :Chassis | :500mA | :-15V | - | - | - | - | - | - | - | - | - | - |
Power Supply,Encap.,chassis,5/12V 40W PSU, AC/DC, 5V,&12V, 40W, MODULE TRACOPOWER 40W 2输出 嵌入式开关模式电源 SMPS , 100 → 375 V dc, 90 → 264 V ac输入, 5 V dc, 12 V dc输出 TRACOPOWER | 16 | 1: ¥615.75 | 85044082 | ±1% | 75 → 84% | :Adjustable, Fixed | :40W | 40W | 100 → 375 V dc, 90 → 264 V ac | ±0.5 %, ±5 % | ±2 %, ±3 %, ±6 % | 1250 mA, 5000 mA | 2 | :90V to 264V | 32.5mm | 63.7mm | 112mm | 325g | Encapsulated | -40°C | +60°C | :32.5mm | 200000h | :440Hz | :General Purpose | - | - | - | - | :1.25A | :12V | - | - | - | - | - | - | - | - | - | - |
TML chassis univ i/p SMPSU,5V +/-12V 15W PSU, ENCAPSULATED, 15W, 5V, +/-12V TRACOPOWER 15W 3输出 嵌入式开关模式电源 SMPS , 85 → 264 V ac, 85 → 370 V dc输入, 5 V dc, ±12 V dc输出 TRACOPOWER | 19 | 1: ¥676.11 | 85044082 | ±1 %, ±1.5 % | 72 → 80% | :Fixed | :15W | 15W | 85 → 264 V ac, 85 → 370 V dc | ±0.3% | ±5% | 200 mA, 2000 mA | 3 | :85V to 264V | 26.5mm | 54mm | 96mm | 150g | Encapsulated | -25°C | +60°C | :26.5mm | 660000h | :440Hz | :General Purpose | :264V | :CE, UL | :Switch Mode | :Chassis | :200mA | :12V | :15W | :3000VAC | - | - | - | - | :200mA | :12V | - | - |
Power Supply,Encap.,chassis,+/-12V 20W PSU, AC/DC, 0.8A, 20W, MODULE TRACOPOWER 20W 2输出 嵌入式开关模式电源 SMPS , 100 → 375 V dc, 90 → 264 V ac输入, ±12V dc输出, 833mA输出 TRACOPOWER | 15 | 1: ¥412.50 | 85044082 | ±0.7% | 75 → 84% | :Adjustable, Fixed | :20W | 20W | 100 → 375 V dc, 90 → 264 V ac | ±0.5% | ±3% | 833mA | 2 | :90V to 264V | 27.6mm | 54.6mm | 96mm | 155g | Encapsulated | -25°C | +60°C | :27.6mm | 200000h | :440Hz | :General Purpose | - | - | - | - | :-833mA | :-12V | - | - | - | - | - | - | - | - | - | - |
 Power Supply,Switch Mode,12V,10A,120W PSU, AC TO DC, 120W, 12V, 10A TRACOPOWER 120W 单输出 嵌入式开关模式电源 SMPS , 120 → 370 V dc, 90 → 264 V ac输入, 12V dc输出, 10A输出, 90%效能 TRACOPOWER | 56 | 1: ¥728.45 | 85044082 | 120mV Pk-Pk | 90% | :Fixed | :120W | 120W | 120 → 370 V dc, 90 → 264 V ac | ±1% | ±1% | 10A | 1 | :90V to 264V | 38mm | 82mm | 137mm | 390g | Enclosed | -25°C | +70°C | :38mm | 120000h | - | :General Purpose | :110V AC, 230V AC | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
TXL series univ input SMPSU,5/12V 35W POWER SUPPLY, SWITCH MODE, 5V, 12V TRACOPOWER 35W 2输出 嵌入式开关模式电源 SMPS , 85 → 264V ac输入, 5 V dc, 12 V dc输出, 2.5 A, 4 A输出 TRACOPOWER | 280 | 1: ¥438.76 | 85044082 | ±1% | 70 → 84% | :Fixed | :35W | 35W | 120 → 375 V dc, 85 → 264 V ac | ±1% | ±4 %, ±6 % | 2.5 A, 4 A | 2 | :85V to 264V | 35mm | 82mm | 109mm | 0.3kg | Enclosed | -10°C | +70°C | :99mm | 250000h | - | - | - | :CE, UL | :Switch Mode | :Chassis | - | - | - | - | - | - | - | - | - | - | - | - |
Power Supply,Encap.,chassis,+/-15V 20W PSU, AC/DC, 0.7A, 20W, MODULE TRACOPOWER 20W 2输出 嵌入式开关模式电源 SMPS , 100 → 375 V dc, 90 → 264 V ac输入, ±15V dc输出, 667mA输出 TRACOPOWER | 36 | 1: ¥1,154.96 | 85044082 | ±0.7% | 75 → 84% | :Adjustable, Fixed | :20W | 20W | 100 → 375 V dc, 90 → 264 V ac | ±0.5% | ±3% | 667mA | 2 | :90V to 264V | 27.6mm | 54.6mm | 96mm | 155g | Encapsulated | -25°C | +60°C | :27.6mm | 200000h | :440Hz | :General Purpose | - | - | - | - | :-667mA | :-15V | - | - | - | - | - | - | - | - | - | - |
 Power Supply,Switch Mode,5V,6A,30W POWER SUPPLY, AC/DC, 35W, 5V, 6A TRACOPOWER 35W 单输出 嵌入式开关模式电源 SMPS , 90 → 264V ac输入, 5V dc输出, 6A输出, 80%效能, 封闭封装 TRACOPOWER | 11 | 1: ¥216.75 | 85044090 | 1% | 85% | :Adjustable, Fixed | :35W | 30W | 88 → 264V ac | 0.5% | 2% | 6A | 1 | :90V to 264V | 33mm | 64mm | 102mm | 0.19 | Enclosed | -20°C | +70°C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | :5.5V | :4.7V |
Power Supply,Encapsulatd,chassis,15V 20W PSU, AC/DC, 1.3A, 20W, MODULE TRACOPOWER 20W 单输出 嵌入式开关模式电源 SMPS , 100 → 375 V dc, 90 → 264 V ac输入, 15V dc输出, 1.34A输出 TRACOPOWER | 17 | 1: ¥399.17 | 85044082 | ±0.7% | 75 → 84% | :Adjustable, Fixed | :20W | 20W | 100 → 375 V dc, 90 → 264 V ac | ±0.5% | ±1% | 1340mA | 1 | :90V to 264V | 27.6mm | 54.6mm | 96mm | 155g | Encapsulated | -25°C | +60°C | :27.6mm | 200000h | :440Hz | :General Purpose | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Power Supply, Chassis mount,24Vdc 50W PSU, MODULE, 50W, 24V/2, 1A TRACOPOWER 50W 单输出 嵌入式开关模式电源 SMPS , 85 → 264 V ac, 85 → 370 V dc输入, 24V dc输出, 2.3A输出, 83%效能 TRACOPOWER | 10 | 1: ¥999.60 | 85044082 | 150mV Pk-Pk | 83% | :Fixed | :50W | 50W | 85 → 264 V ac, 85 → 370 V dc | 20mV | 50mV | 2300mA | 1 | :85V to 264V | 33.5mm | 64mm | 110mm | 295g | Encapsulated | -25°C | +50°C | :33.5mm | 180000h | :63Hz | :General Purpose | :264V | :EN 60601, IEC 60601 | :Switch Mode | :Chassis | - | - | - | - | - | - | - | - | - | - | - | - |
TXL series universal input SMPSU,5V 50W 1% V out TRACOPOWER 50W 单输出 嵌入式开关模式电源 SMPS , 85 → 264V ac输入, 5V dc输出, 10A输出, 70 → 84%效能, 封闭封装 TRACOPOWER | 25 | 1: ¥363.19 | 85044082 | ±1% | 70 → 84% | :Adjustable, Fixed | :50W | 50W | 120 → 375 V dc, 85 → 264 V ac | ±1% | ±2% | 10A | 1 | :85V to 264V, 100V to 240V | 35mm | 82mm | 109mm | 0.3kg | Enclosed | -10°C | +70°C | :35mm | 250000h | :63Hz | - | :264V | :CE, UL | :Switch Mode | :Chassis | - | - | - | - | :63Hz | :47Hz | :< | :264VAC | - | - | - | - |
