信号继电器，2安培及以下
Sensata Technologies Holding N.V.- 信号继电器，2安培及以下
信号继电器，2安培及以下 - 型号列表
共 73 个型号| 制造商零件编号 | 库存 | 价格 | 标准包装数量 | 线圈类型 | 线圈电流 | 线圈电阻 | 供电电压 | 开关电压 | 开关电流 | 触点额定电流 | 包装方式 | 触点形式 | 安装类型 | 触头材料 | 端接样式 | 典型触点布局 | 继电器类型 | 工作温度 | 释放时间 | 集电极-发射极饱和电压（最大）@ Vge, Ic | 动作时间 | Vgs(th)（最大）@ Id | 接触电阻 | 类型 | 卡标准 | 重量 | 隔离 | 电阻 | 最大开关负载 | 绝缘电阻 | 释放值 | 必须动作（继电器术语，指必须吸合） | 线圈功率 | 产品特性 | 触头类型 | 接触件端接 | 其他名称 | 屏幕对角线尺寸 | 承载电流 | 温度范围 | RoHS | 零件状态 | 屏蔽类型 | 引脚长度（针脚） | 海关税号 | 高度（最大） | 通态电流（It (RMS)）（最大） | 最大功率 | 隔离类型 | 直流开关电压 | 深度 | 高度 | 长度 | 端子类型 | 机械寿命 | SVHC | 宽度 | 电容 | 标称电压 | ESR（等效串联电阻） | 持续时间 | 总线连接 | 输入 - 侧1/侧2 | 开口尺寸 | 电压 | 核心电压 | 极数 | 最大额定电流 | 必须动作电压 | 释放电压 | 最大触点电流 | 最小输入电压 | 最小供电电压 | 供电电压 (Vcc/Vdd) | 位数 | 系列 | 开关次数 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 RELAY REED SPST 500MA 24V SPST-NO Reed Relay, 0.5A, 24V dc Reed Relays SPST-NO 0.5A 24VDC 1KOhm Thru-Hole RELAY, 3KV, 24V COIL RELAY;REED;HIGHVOLTAGE;SPNO;3KV;24VCOIL;PCB Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 0.5 Amps Switching Voltage: 20 Volts Reed relay 24 VDC 1000 Ohm, SAR92403, Cynergy3 Sensata Technologies Holding N.V. | - | 60 | Non Latching | 24mA | 1 kOhms | 24VDC | 20VAC, 20VDC - Max | 0.5 A | 500mA | Tray | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | PC Pin | SPST-NO | Reed | -20°C ~ 70°C | 0.5ms | 20 VDC | 1ms | 2 VDC | 30 mΩ | - | - | 0.003 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Compliant | - | - | - | 85353010 | :8.5mm | - | 10 W | 3kV ac/dc | 20V dc | 7.3mm | 8.5mm | 27.6mm | Through Hole | 100000000 (Electrical) cycles | :No SVHC (20-Jun-2013) | :27.6mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST 500MA 24V SPST-NO Reed Relay, 0.5A, 24V dc Reed Relays SPST-NO 0.5A 24VDC 1KOhm Thru-Hole RELAY, 5KV, 24V COIL ACCESSORY;EXTENSIONTUBE250MMSSG1/8 Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 60 | Non Latching | 24mA | 1 kOhms | 24VDC | 20VAC, 20VDC - Max | 0.5 A | 500mA | Tray | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | PC Pin | SPST-NO | Reed | -20°C ~ 70°C | 0.5ms | 20 VDC | 1ms | 3 VDC | 30 mΩ | - | - | 0.003 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Compliant | - | - | - | 85353010 | :8.5mm | - | 10 W | 5kV ac/dc | 20V dc | 7.3mm | 8.5mm | 27.6mm | Through Hole | 100000000 (Electrical) cycles | :No SVHC (20-Jun-2013) | :27.6mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 RELAY REED SPST-NO 500MA 5V RF REED RELAY, SPST-NO, 5VDC, 0.5A, THD Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 71.4mA | 70 Ohms | 5VDC | 20VAC, 20VDC - Max | :500mA | 500mA | Bulk | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | PC Pin | :SPST-NO | Reed | -40°C ~ 100°C | 0.5ms | 3.5 VDC | 1ms | 1 VDC | - | - | - | 0 | - | - | - | - | - | - | 357 mW | 30 MHz | - | - | 725-1172 | - | - | - | - | - | - | - | 85364190 | :11.2mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST-NO 500MA 24V Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 16mA | 1.5 kOhms | 24VDC | 20VAC, 20VDC - Max | 0.5 Amps | 500mA | Bulk | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | PC Pin | 1A SPST-NO | Reed | -40°C ~ 100°C | 0.5ms | 15 VDC | 1ms | 4 VDC | 80 ohms (30 ohms) | Relays | Reed Relay | 3.5 g | 3 kv | 1200 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 4V | 15 V | 384 mW | 30 MHz | Rhodium | 3 kv | 725-1174 | 95 @ 3A rms | 3.5 A | -40C to +125C | - | 80 @ 3A rms | Screened, | n/a | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST-NO 500MA 5V Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Flying Leads Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 71.4mA | 70 Ohms | 5VDC | 20VAC, 20VDC - Max | 0.5 Amps | 500mA | Bulk | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | PC Pin, Wire Leads | 1A SPST-NO | Reed | -40°C ~ 100°C | 0.5ms | 3.5 VDC | 1ms | 1 VDC | 80 ohms (30 ohms) | Relays | Reed Relay | 3.5 g | 3 kv | 70 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 1V | 3.5 V | 357 mW | 30 MHz | Rhodium | 3 kv | 725-1175 | 95 @ 3A rms | 3.5 A | -40C to +125C | - | 80 @ 3A rms | Screened, | n/a | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST-NO 500MA 12V RF REED RELAY, SPST-NO, 12VDC, 0.5A, THD Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Flying Leads Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 31.6mA | 380 Ohms | 12VDC | 20VAC, 20VDC - Max | :500mA | 500mA | Bulk | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | PC Pin, Wire Leads | :SPST-NO | Reed | -40°C ~ 100°C | 0.5ms | 8 VDC | 1ms | 2 VDC | - | - | - | 0 | - | - | - | - | - | - | 379 mW | 30 MHz | - | - | 725-1176 | - | - | - | - | - | - | - | 85364190 | :11.2mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST-NO 500MA 24V Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Flying Leads Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 16mA | 1.5 kOhms | 24VDC | 20VAC, 20VDC - Max | 0.5 Amps | 500mA | Bulk | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | PC Pin, Wire Leads | 1A SPST-NO | Reed | -40°C ~ 100°C | 0.5ms | 15 VDC | 1ms | 4 VDC | 80 ohms (30 ohms) | Relays | Reed Relay | 3.5 g | 3 kv | 1200 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 4V | 15 V | 384 mW | 30 MHz | Rhodium | 3 kv | 725-1177 | 95 @ 3A rms | 3.5 A | -40C to +125C | - | 80 @ 3A rms | Screened, | n/a | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 RELAY REED SPST-NO 1A 12V RELAY REED RF SPST-NO 1A 12V Reed Relays SPST-NO 1A 12VDC 340Ohm Thru-Hole Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 1 Amp Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 35.3mA | 340 Ohms | 12VDC | 20VDC - Max | 1 Amp | 1A | Bulk | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | Axial | 1A SPST-NO | Reed | -40°C ~ 85°C | - | - | - | - | - | Relays | Reed Relay | - | - | - | - | - | - | - | 424 mW | 30 MHz | - | - | - | Partial | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 RELAY REED SPST 2A 5V Reed Relays SPST-NO 2A 5VDC 28Ohm Panel Mount RELAY;10KV05VSPNOTUNGSTEN-SOLDERTURRETHVCONTACTCONNECTIONS Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Base Mount Switching Current: 2 Amps Switching Voltage: 7000 Volts Sensata Technologies Holding N.V. | - | 20 | Non Latching | 178.57mA | 28 Ohms | 5VDC | 7000VAC, 7000VDC - Max | 2 Amps | 2A | Tray | SPST-NO (1 Form A) | Chassis Mount | Tungsten (W) | Solder Turret | 1A SPST-NO | Reed | -20°C ~ 70°C | 2ms | 3.7 VDC | 3ms | 0.5 VDC | 250 ohms (100 ohms) | Relays | Reed Relay | - | 10 kv | 38 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 0.5 V | 3.7 V | - | - | Tungsten | 17 kv | DAT70510P-ND | - | - | - | RoHS Compliant Part | - | - | - | - | - | 3 A | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST 2A 12V RELAY;10KV12VSPNOTUNGSTEN-SOLDERTURRETHVCONTACTCONNECTIONS Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Base Mount Switching Current: 2 Amps Switching Voltage: 7000 Volts Sensata Technologies Holding N.V. | - | 20 | Non Latching | 80mA | 150 Ohms | 12VDC | 7000VAC, 7000VDC - Max | 2 Amps | 2A | Tray | SPST-NO (1 Form A) | Chassis Mount | Tungsten (W) | Solder Turret | 1A SPST-NO | Reed | -20°C ~ 70°C | 2ms | 9 VDC | 3ms | 1.25 VDC | 250 ohms (100 ohms) | Relays | Reed Relay | - | 10 kv | 240 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 1.25 V | 9 V | - | - | Tungsten | 17 kv | DAT71210P-ND | - | - | - | RoHS Compliant Part | - | - | - | - | - | 3 A | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST 2A 24V RELAY; REED; HIGH VOLTAGE; SPNO; 10KV; 24V COIL; PANEL MOUNT Reed Relays SPST-NO 2A 24VDC 780Ohm Panel Mount RELAY;REED;HIGHVOLTAGE;SPNO;10KV;24VCOIL;PANELMOUNT Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Base Mount Switching Current: 2 Amps Switching Voltage: 7000 Volts Sensata Technologies Holding N.V. | - | 20 | Non Latching | 30.7mA | 780 Ohms | 24VDC | 7000VAC, 7000VDC - Max | 2 Amps | 2A | Tray | SPST-NO (1 Form A) | Chassis Mount | Tungsten (W) | Solder Turret | 1A SPST-NO | Reed | -20°C ~ 70°C | 2ms | 20 VDC | 3ms | 4 VDC | 250 ohms (100 ohms) | Relays | Reed Relay | - | 10 kv | 925 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 4 V | 20 V | - | - | Tungsten | 17 kv | DAT72410P-ND | - | - | - | Compliant | - | - | - | - | - | 3 A | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 RELAY REED SPST 2A 5V Reed Relays SPST-NO 2A 5VDC 28Ohm Thru-Hole RELAY;10KV05VSPNOTUNGSTEN-PCBMOUNT1/4SPADEHVCONNECTIONS Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Base Mount Switching Current: 2 Amps Switching Voltage: 7000 Volts Sensata Technologies Holding N.V. | - | 20 | Non Latching | 178.57mA | 28 Ohms | 5VDC | 7000VAC, 7000VDC - Max | 2 Amps | 2A | Bulk | SPST-NO (1 Form A) | Chassis Mount | Tungsten (W) | Quick Connect - 0.250" (6.3mm) | 1A SPST-NO | Reed | -20°C ~ 70°C | 2ms | 3.7 VDC | 3ms | 0.5 VDC | 250 ohms (100 ohms) | Relays | Reed Relay | - | 10 kv | 38 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 0.5 V | 3.7 V | - | - | Tungsten | 17 kv | DAT70510S-ND | - | - | - | RoHS Compliant Part | - | - | - | - | - | 3 A | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 RELAY REED SPST 2A 5V SPST-NC Reed Relay, 2A, 5V dc Reed Relays SPST-NC 2A 5VDC 38Ohm Thru-Hole RELAY;REED;HIGHVOLTAGE;SPNC;10KV;5VCOIL;PCB Relays Reed Relays Contact Configuration: 1B SPST-NC Mounting: PC Board Switching Current: 2 Amps Switching Voltage: 7000 Volts Sensata Technologies Holding N.V. | - | 20 | Non Latching | 131.5mA | 38 Ohms | 5VDC | 7000VAC, 7000VDC - Max | 2 Amps | 2A | Tray | SPST-NC (1 Form B) | Through Hole | Tungsten (W) | PC Pin | SPST-NC | Reed | -20°C ~ 70°C | 3ms | 3.7 VDC | 2ms | 0.5 VDC | 250 mΩ | Relays | Reed Relay | - | 10 kv | 28 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 0.5 V | 3.7 V | - | - | Tungsten | 17 kv | - | - | - | - | Compliant | - | - | - | - | - | 3 A | 50 W | 17kV ac/dc | 7000V dc | 15.8mm | 18.5mm | 60mm | Through Hole | 1000000 (Electrical) cycles | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 RELAY REED SPST-NO 1A 24V RELAY REED RF SPST-NO 1A 24V Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: PC Board Switching Current: 1 Amp Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 24mA | 1 kOhms | 24VDC | 20VDC - Max | 1 Amp | 1A | Bulk | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | Axial | 1A SPST-NO | Reed | -40°C ~ 85°C | 1ms | 15 VDC | 2ms | 2 VDC | 50 (15) | Relays | Reed Relay | 24 g | 8 kv | 1000 ohm | 10^9 | 10^10 ohms (10^13 ohms) | 2 VDC | 15 VDC | 576 mW | 30 MHz | - | - | - | Partial | 6 A | -55C to +125C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 0.4 pF | 24 VDC | 100 mohm | 10 g | 1 & 6 | 100 g | Part | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST 2A 24V SPST-NO Reed Relay, 2A, 24V dc Reed Relays SPST-NO 2A 24VDC 780Ohm Panel Mount RELAY, REED, 24V, 1/4", SPADE DRY REED RELAY SPST-NO, 24VDC, 2A, SPADE RELAY;10KV24VSPNOTUNGSTEN-PANELMOUNTSTUDSSOLDERTURRETCOIL/HVCONTACT Relays Reed Relays Contact Configuration: 1A SPST-NO Mounting: Base Mount Switching Current: 2 Amps Switching Voltage: 7000 Volts Reed relay 24 VDC 780 Ohm, DAT72410S, Cynergy3 Cynergy3 单极常开 簧片继电器, 2 A, 24V dc, 60 x 15.8 x 24.8mm Sensata Technologies Holding N.V. | - | 20 | Non Latching | 30.7mA | 780 Ohms | 24VDC | 7000VAC, 7000VDC - Max | :2A | 2A | Tray | SPST-NO (1 Form A) | Chassis Mount | Tungsten (W) | Quick Connect - 0.250" (6.3mm) | SPST-NO | Reed | -20°C ~ 70°C | 2ms | 20 VDC | 3ms | 4 VDC | 250 mΩ | - | - | 0.03331 | - | - | - | - | - | - | - | - | - | - | 725-1055 | - | - | - | Compliant | - | - | - | 85364900 | :18.5mm | - | 50 W | 17kV ac/dc | 7000V dc | 15.8mm | 24.8mm | 60mm | Tab | 1000000 (Electrical) cycles | :No SVHC (20-Jun-2013) | :60mm | - | - | - | - | - | - | - | :20 V | :7kV | :1 | :2A | :20V | :4.0V | :2A | :20V | :20V | :7kV | :10 | :D | :1000000 | |
RELAY REED SPST-NC 500MA 5V Relays Reed Relays Contact Configuration: 1B SPST-NC Mounting: PC Board Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 77mA | 65 Ohms | 5VDC | 20VAC, 20VDC - Max | 0.5 Amps | 500mA | Bulk | SPST-NC (1 Form B) | Through Hole | Rhodium (Rh) | PC Pin | 1B SPST-NC | Reed | -40°C ~ 100°C | 0.5ms | 3.5 VDC | 1ms | 1 VDC | 80 ohms (30 ohms) | Relays | Reed Relay | 4.2 g | 3 kv | 70 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 1V | 3.5 V | 385 mW | 30 MHz | Rhodium | 3 kv | - | 95 @ 3A rms | 3.5 A | -40C to +125C | - | 80 @ 3A rms | Screened, | n/a | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST-NC 500MA 12V Relays Reed Relays Contact Configuration: 1B SPST-NC Mounting: PC Board Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 34.29mA | 350 Ohms | 12VDC | 20VAC, 20VDC - Max | 0.5 Amps | 500mA | Bulk | SPST-NC (1 Form B) | Through Hole | Rhodium (Rh) | PC Pin | 1B SPST-NC | Reed | -40°C ~ 100°C | 0.5ms | 8 VDC | 1ms | 2 VDC | 80 ohms (30 ohms) | Relays | Reed Relay | 4.2 g | 3 kv | 380 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 2V | 8 V | 411 mW | 30 MHz | Rhodium | 3 kv | - | 95 @ 3A rms | 3.5 A | -40C to +125C | - | 80 @ 3A rms | Screened, | n/a | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST-NC 500MA 24V Relays Reed Relays Contact Configuration: 1B SPST-NC Mounting: PC Board Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 20mA | 1.2 kOhms | 24VDC | 20VAC, 20VDC - Max | 0.5 Amps | 500mA | Bulk | SPST-NC (1 Form B) | Through Hole | Rhodium (Rh) | PC Pin | 1B SPST-NC | Reed | -40°C ~ 100°C | 0.5ms | 15 VDC | 1ms | 4 VDC | 80 ohms (30 ohms) | Relays | Reed Relay | 4.2 g | 3 kv | 1200 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | 4V | 15 V | 480 mW | 30 MHz | Rhodium | 3 kv | - | 95 @ 3A rms | 3.5 A | -40C to +125C | - | 80 @ 3A rms | Screened, | n/a | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 RELAY REED SPST-NC 1A 24V RELAY REED RF SPST-NC 1A 24V Relays Reed Relays Contact Configuration: 1B SPST-NC Mounting: PC Board Switching Current: 1 Amp Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Non Latching | 16mA | 1.5 kOhms | 24VDC | 20VDC - Max | 1 Amp | 1A | Bulk | SPST-NC (1 Form B) | Through Hole | Rhodium (Rh) | Axial | 1B SPST-NC | Reed | -40°C ~ 85°C | 2ms | 14 VDC | 3ms | 4 VDC | 50 (15) | Relays | Reed Relay | 33 g | 8 kv | 1500 ohm | 10^9 | 10^10 ohms (10^13 ohms) | 4 VDC | 14 VDC | 384 mW | 30 MHz | - | - | - | No | 6 A | -55C to +125C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 0.6 pF | 24 VDC | 150 mohm | 10 g | 1 & 6 | 100 g | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
RELAY REED SPST-NO 500MA 12V Relays Reed Relays Contact Configuration: 1A+1B SPST-NO+SPST-NC Mounting: PC Board Switching Current: 0.5 Amps Switching Voltage: 20 Volts Sensata Technologies Holding N.V. | - | 10 | Latching, Dual Coil | 24mA | 500 Ohms | 12VDC | 20VAC, 20VDC - Max | 0.5 Amps | 500mA | Bulk | SPST-NO (1 Form A) | Through Hole | Rhodium (Rh) | PC Pin | 1A+1B SPST-NO+SPST-NC | Reed | -40°C ~ 100°C | 1ms | 7 VDC | 1ms | - | 80 ohms (30 ohms) | Relays | Reed Relay | 3.1 g | 3.5 kv | 500 ohm | 10^9 operations | 10^10 ohms (10^13 ohns) | n/a | 7V | 288 mW | 30 MHz | Rhodium | 3.5 kv | 725-1179 | 200 @ 1.5A rms | 1.5 A | -40C to +125C | - | 180 @ 1.5A rms | Screened, | 2.0ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
