RS Components Ltd- 板对板连接器

RS Components是一家全球性电子元器件、自动化及维护产品全渠道分销商。公司总部位于英国北安普敦郡的科比，前身是1937年成立的Radiospares。其产品线涵盖超过50万种产品，来自2500多家领先制造商。核心品类包括半导体、连接器、无源器件、机电元件、传感器、电源和测试设备等。公司还推出自有品牌RS Pro，提供高质量电子和工业零部件。RS在30多个国家为工程师和企业提供快速交付与技术支持。它是全球电子分销市场的主要参与者，与艾睿、安富利等齐名。其电子商务平台RS Online是重要的数字化采购渠道。公司大力投入可持续发展、数字化转型以及工业物联网和自动化解决方案。

制造商零件编号	库存	价格	间距	排数	触点数	类型	触头材料	端接方式	安装类型	宽度	系列	最大额定电流	接触电阻	深度	长度	方向	接触镀层	连接器颜色	连接器性别	材料（通用）	法兰直径	齿数	非扩张内径	模块/板类型	CAD图纸
M22-2010905 RS M22-20 Series 2mm Pitch 9 Way 1 Row Straight PCB Header, Solder Termination, 1A RS	10	5: ¥3.2368	2mm	1	9	Unshrouded Header	Phosphor Bronze	Solder	Straight	-	M22-20	1A	-	-	-	-	-	-	-	-	-	-	-	-	3D CAD Model
W8010T50RC Black 2 way closed shorting link,2.54mm RS	42130	10: ¥13.60	2.54mm	1	2	Jumper	Phosphor Bronze	-	-	6.47mm	-	-	20mΩ	2.44mm	4.98mm	Straight	Tin over Nickel	Black	Female	-	-	-	-	-	-
W8011T50RC Blue 2 way closed shorting link,2.54mm RS	10	10: ¥1.36	2.54mm	1	2	Jumper	Phosphor Bronze	-	-	6.47mm	-	-	20mΩ	2.44mm	4.98mm	Straight	Tin over Nickel	Blue	Female	-	-	-	-	-	-
W582140SB1RC RS W5821 Series 1.27mm Pitch 40 Way 40 Row Straight PCB Header, Solder Termination, 1A RS	1925	5: ¥30.4844	1.27mm	40	40	Unshrouded Header	Phosphor Bronze	Solder	Straight	-	W5821	1A	-	-	-	-	-	-	-	-	-	-	-	-	-
M22-1900005 Black gold plated jumper link,2mm pitch RS	10	10: ¥2.0332	2mm	1	2	Jumper	Beryllium Copper	-	-	3.5mm	-	-	20mΩ	1.95mm	3.9mm	Straight	Gold	Black	Female	-	-	-	-	-	-
W8012T50RC Yellow 2 way closed shorting link,2.54mm RS	10	10: ¥1.36	2.54mm	1	2	Jumper	Phosphor Bronze	-	-	6.47mm	-	-	20mΩ	2.44mm	4.98mm	Straight	Tin over Nickel	Yellow	Female	-	-	-	-	-	-
W82172T3816RC RS W82172 Series 2.54mm Pitch 72 Way 2 Row Straight PCB Header, Solder Termination RS	10	10: ¥15.7148	2.54mm	2	72	Unshrouded Header	-	Solder	Straight	-	W82172	-	-	-	-	-	-	-	-	-	-	-	-	-	-
BWW10/30/1R RS Bronze 30 Teeth Worm Wheel Gear, 30mm PitchDiam. , 32.7mm Hub Diam. , 16.5mm Face Width RS	10	1: ¥117.096	-	-	-	-	-	-	-	16.5mm	-	-	-	-	-	-	-	-	-	Bronze	32.7mm	30	30mm	1	-
W3481103TRC RS 2.54mm 3 Way 1 Row Straight PCB Socket Through Hole Socket Strip RS	10	10: ¥2.1352	2.54mm	1	3	Socket Strip	-	Solder	Straight	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
W53482140SARC RS 1.27mm 80 Way 2 Row Straight PCB Socket Through Hole Socket Strip RS	10	5: ¥21.0256	1.27mm	2	80	Socket Strip	Phosphor Bronze	Solder	Straight	-	-	1A	-	-	-	-	-	-	-	-	-	-	-	-	-
M22-1920005 Red gold plated jumper link,2mm pitch RS	10	10: ¥2.6656	2mm	1	2	Jumper	Beryllium Copper	-	-	3.5mm	-	-	20mΩ	1.95mm	3.9mm	Straight	Gold	Red	Female	-	-	-	-	-	-
M22-2021846 RS M22-20 Series 2mm Pitch 36 Way 2 Row Straight PCB Header, Solder Termination, 1A RS	10	5: ¥10.2816	2mm	2	36	Unshrouded Header	Phosphor Bronze	Solder	Straight	-	M22-20	1A	-	-	-	-	-	-	-	-	-	-	-	-	3D CAD Model
W81936T3825RC RS W81136 Series 2.54mm Pitch 36 Way 1 Row Right Angle PCB Header, Solder Termination RS	5723	10: ¥10.2544	2.54mm	1	36	Unshrouded Header	-	Solder	Right Angle	-	W81136	-	-	-	-	-	-	-	-	-	-	-	-	-	-
W8013T50RC Red 2 way closed shorting link,2.54mm RS	10	10: ¥1.36	2.54mm	1	2	Jumper	Phosphor Bronze	-	-	6.47mm	-	-	20mΩ	2.44mm	4.98mm	Straight	Tin over Nickel	Red	Female	-	-	-	-	-	-
BWW08/20/2R RS Bronze 20 Teeth Worm Wheel Gear, 16.11mm PitchDiam. , 17.6mm Hub Diam. , 18mm Face Width RS	10	1: ¥73.78	-	-	-	-	-	-	-	18mm	-	-	-	-	-	-	-	-	-	Bronze	17.6mm	20	16.11mm	0.8	-
W82172T3813RC RS W82172 Series 2.54mm Pitch 72 Way 2 Row Straight PCB Header, Solder Termination RS	10	10: ¥17.3468	2.54mm	2	72	Unshrouded Header	-	Solder	Straight	-	W82172	-	-	-	-	-	-	-	-	-	-	-	-	-	-
BWW10/40/1R RS Bronze 40 Teeth Worm Wheel Gear, 40mm PitchDiam. , 42.7mm Hub Diam. , 16.5mm Face Width RS	10	1: ¥165.308	-	-	-	-	-	-	-	16.5mm	-	-	-	-	-	-	-	-	-	Bronze	42.7mm	40	40mm	1	-
M22-7132542 RS 2mm 25 Way 1 Row Straight PCB Socket Through Hole Socket Strip RS	10	5: ¥17.204	2mm	1	25	Socket Strip	Phosphor Bronze	Solder	Straight	-	-	1A	-	-	-	-	-	-	-	-	-	-	-	-	-
W3481104TRC RS 2.54mm 4 Way 1 Row Straight PCB Socket Through Hole Socket Strip RS	10	10: ¥2.7472	2.54mm	1	4	Socket Strip	-	Solder	Straight	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
W582180SB1RC RS W5821 Series 1.27mm Pitch 60 Way 80 Row Straight PCB Header, Solder Termination, 1A RS	10	5: ¥40.12	1.27mm	80	60	Unshrouded Header	Phosphor Bronze	Solder	Straight	-	W5821	1A	-	-	-	-	-	-	-	-	-	-	-	-	-
