Phoenix Contact GmbH & Co. KG- 小型断路器
小型断路器 - 型号列表
共 118 个型号| 制造商零件编号 | 库存 | 价格 | 标准包装数量 | 工厂包装数量 | RoHS | 额定电压 | 极数 | 最大额定电流 | 宽度 | 长度 | 断路器类型 | 致动器类型 | 安装类型 | 系列 | 制造商全称 | 产品 | 标准包装规格 | 材料阻燃等级 | 供电电压 | 颜色 | 高度 | 安装样式 | 端接样式 | 类型 | 功能 | 照明类型 | 产品子类型 | 适用产品/相关产品 | 工作温度 | 包装方式 | CAD图纸 | 交货时间 | 其他名称 | 子类别 | 供电电压 (Vcc/Vdd) | 深度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CIR BRKR SOLID STATE 8A 24VDC Phoenix Contact ECP 系列 8 A MCB 微型断路器 Circuit Breakers ECP 8 Phoenix Contact | 29 | 1: ¥780.98 | 1 | 1 | Lead free / RoHS Compliant | 24V | 1 | 8A | 12.5mm | 60mm | Solid State | Push-Push | Holder | ECP | Phoenix Contact | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 12 Days | ECP 8 | Not Specified | 32V | 70mm |
 CIR BRKR THRMMAG 5A 277VAC 50VDC Thermomagnetic 5A Breaker 1 Pole SFB Circuit Breakers CB TM1 5A SFB P CBTM15ASFBP Phoenix Contact | 11 | 1: ¥376.1758 | 1 | 1 | Compliant | 277V | 1 | 5A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
CIR BRKR 16A 277VAC 50VDC Thermomagnetic 16A Breaker 1 Pole Medium Circuit Breakers CB TM1 16A M1 P CBTM116AM1P Phoenix Contact | 10 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 16A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | - | - | - | - | - | - | - |
CIR BRKR 12A 277VAC 50VDC Thermomagnetic 12A Breaker 1 Pole SFB Circuit Breakers CB TM1 12A SFB P CBTM112ASFBP Phoenix Contact | 10 | 600: ¥20.196 | 1 | 1 | Compliant | 277V | 1 | 12A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
CIR BRKR 12A 277VAC 50VDC Thermomagnetic 12A Breaker 1 Pole Fast Circuit Breakers CB TM1 12A F1 P CBTM112AF1P Phoenix Contact | 10 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 12A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
CIR BRKR 500MA 277VAC 50VDC Thermomagnetic 0.5A Breaker 1Pole Medium Circuit Breakers CB TM1 0.5A M1 P CBTM10.5AM1P Phoenix Contact | 10 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 500mA | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
CIR BRKR THRMMAG 1A 277VAC 50VDC Thermomagnetic 1A Breaker 1 Pole Fast Circuit Breakers CB TM1 1A F1 P CBTM11AF1P Phoenix Contact | 10 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 1A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
CIR BRKR THRMMAG 6A 277VAC 50VDC Thermomagnetic 6A Breaker 1 Pole SFB Circuit Breakers CB TM1 6A SFB P CBTM16ASFBP Phoenix Contact CB TM1 系列 6A 热磁断路器 Phoenix Contact | 10 | 1: ¥323.2138 | 1 | 1 | Compliant | 277V | 1 | 6A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | 3D CAD 模型 | - | - | - | - | - |
CIR BRKR 16A 277VAC 50VDC Thermomagnetic 16A Breaker 1 Pole SFB Circuit Breakers CB TM1 16A SFB P CBTM116ASFBP Phoenix Contact | 10 | 1: ¥539.5663 | 1 | 1 | Compliant | 277V | 1 | 16A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
CIR BRKR THRMMAG 2A 277VAC 50VDC Thermomagnetic 2A Breaker 1 Pole Medium Circuit Breakers CB TM1 2A M1 P CBTM12AM1P Phoenix Contact CB TM1 系列 2A 热磁断路器 Phoenix Contact | 10 | 1: ¥323.2138 | 1 | 1 | Compliant | 277V | 1 | 2A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | 3D CAD 模型 | - | - | - | - | - |
CIR BRKR THRMMAG 3A 277VAC 50VDC Thermomagnetic 3A Breaker 1 Pole Medium Circuit Breakers CB TM1 3A M1 P CBTM13AM1P Phoenix Contact | 10 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 3A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | - | - | - | - | - | - | - |
CIR BRKR THRMMAG 6A 277VAC 50VDC Thermomagnetic 6A Breaker 1 Pole Medium Circuit Breakers CB TM1 6A M1 P CBTM16AM1P Phoenix Contact CB TM1 系列 6A 热磁断路器 Phoenix Contact | 10 | 1: ¥539.5663 | 1 | 1 | Compliant | 277V | 1 | 6A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | - | 3D CAD 模型 | - | - | - | - | - |
CIR BRKR THRMMAG 8A 277VAC 50VDC Thermomagnetic 8A Breaker 1 Pole Medium Circuit Breakers CB TM1 8A M1 P CBTM18AM1P Phoenix Contact | 10 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 8A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
CIR BRKR THRMMAG 4A 277VAC 50VDC Thermomagnetic 4A Breaker 1 Pole Medium Circuit Breakers CB TM1 4A M1 P CBTM14AM1P Phoenix Contact CB TM1 系列 4A 热磁断路器 Phoenix Contact | 10 | 1: ¥323.2138 | 1 | 1 | Compliant | 277V | 1 | 4A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | 3D CAD 模型 | - | - | - | - | - |
CIR BRKR THRMMAG 5A 277VAC 50VDC Thermomagnetic 5A Breaker 1 Pole Medium Circuit Breakers CB TM1 5A M1 P CBTM15AM1P Phoenix Contact | 13 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 5A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
CIR BRKR THRMMAG 2A 277VAC 50VDC Thermomagnetic 2A Breaker 1 Pole Fast Circuit Breakers CB TM1 2A F1 P CBTM12AF1P Phoenix Contact CB TM1 系列 2A 热磁断路器 Phoenix Contact | 10 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 2A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | 3D CAD 模型 | - | - | - | - | - |
CIR BRKR THRMMAG 3A 277VAC 50VDC Thermomagnetic 3A Breaker 1 Pole Fast Circuit Breakers CB TM1 3A F1 P CBTM13AF1P Phoenix Contact | 10 | 1: ¥316.88 | 1 | 1 | Compliant | 277V | 1 | 3A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | - | - | - | - | - | - | - |
CIR BRKR THRMMAG 8A 277VAC 50VDC Thermomagnetic 8A Breaker 1 Pole Fast Circuit Breakers CB TM1 8A F1 P CBTM18AF1P Phoenix Contact | 10 | 1: ¥316.88 | 1 | 1 | Compliant | 277V | 1 | 8A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | - | - | - | - | - | - | - |
CIR BRKR 10A 277VAC 50VDC Thermomagnetic 10A Breaker 1 Pole Fast Circuit Breakers CB TM1 10A F1 P CBTM110AF1P Phoenix Contact | 10 | 1: ¥303.076 | 1 | 1 | Compliant | 277V | 1 | 10A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | - | - | - | - | - | - | - |
CIR BRKR THRMMAG 8A 277VAC 50VDC Thermomagnetic 8A Breaker 1 Pole SFB Circuit Breakers CB TM1 8A SFB P CBTM18ASFBP Phoenix Contact | 10 | 1: ¥291.72 | 1 | 1 | Compliant | 277V | 1 | 8A | 12.3 mm | 52 mm | Thermal-Magnetic | Slide Switch | Panel Mount | CB TM1 | Phoenix Contact | Device Circuit Breakers | 1 | UL 94 V-0 | 277 V ac, 50 V dc | Gray | 45 mm | Pluggable | Quick Connect | Thermal Magnetic Trip | Trip Free | Not Illuminated | Thermomagnetic | TRABTECH Systems | - 30 C to + 60 C | Bulk | - | - | - | - | - | - |
