介质隔离压力传感器
Panasonic Corporation- 介质隔离压力传感器
介质隔离压力传感器 - 型号列表
共 13 个型号| 制造商零件编号 | 库存 | 价格 | 供电电压 | 压力范围 | 最大压力 | 媒体交付类型 | 压力类型 | 工作温度 | 端子类型 | 精度 | 输出类型 | 响应时间 | 输出电压 | 壳体材料 | 密封等级 | 连接类型 | 测量制式 | 连接方式 | 防护等级 | 最大压力（PSI） | 最小液体比重 | 输出端 | 电阻 | 分辨率 | 传感器类型 | 负载电流 | 感应范围 | 输出数量 | 最小供电电压 | 输出数量与类型 | 保护电压（VP）（2416） | 压力（PSI） | 总宽度 | 描述 | 电气寿命 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Gauge Pressure Sensor For Non-Corrosive Gas, 100kPa Max Pressure, 12 to 24V dc, IP40 Pressure sensor -1...1 bar, DP101EP, Panasonic Panasonic 计量 压力传感器 , 100kPa最大压力读数, 12 → 24 V 直流, IP40 G1/8 Panasonic Corporation | 28 | 1: ¥762.60 | 12 → 24 V dc | -100kPa | 100kPa | Non-Corrosive Gas | Gauge | +50°C | Wire Lead | ±1 % | Relay | 2.5 ms | 100 mA | PBT | IP40 | G1/8 | 非腐蚀性气体 | 导线 | IP40 | 100kPa | -100kPa | PNP | 5 | 0.05 % | Pressure sensor | max.100 mA | Pressure | 2 | 12...24 VDC | 0 | IP 40 | G1/8" Outside Thread and M5 Inside Thread | 30 x 30 x 42.5 mm | Standard | Cable, 2 m |
Gauge Pressure Sensor For Non-Corrosive Gas, 100kPa Max Pressure, 12 to 24V dc, IP40 Pressure sensor -1...1 bar, DP101AEP, Panasonic Panasonic 计量 压力传感器 , 100kPa最大压力读数, 12 → 24 V 直流, IP40 G1/8 Panasonic Corporation | 33 | 1: ¥848.90 | 12 → 24 V dc | -100kPa | 100kPa | Non-Corrosive Gas | Gauge | +50°C | Wire Lead | ±1 % | Relay | 2.5 ms | 1 → 5 V dc, 100 mA | PBT | IP40 | G1/8 | 非腐蚀性气体 | 导线 | IP40 | 100kPa | -100kPa | 1...5 V | 5 | 0.05 % | Pressure sensor | max.100 mA | Pressure | 1 | 12...24 VDC | 1 | IP 40 | G1/8" Outside Thread and M5 Inside Thread | 30 x 30 x 42.5 mm | Multifunction | Cable, 2 m |
 Gauge Pressure Sensor For Non-Corrosive Gas, 1Mpa Max Pressure, 12 to 24V dc, IP40 Panasonic Corporation | 55 | 1: ¥1,058.964 | 12 → 24 V dc | 0MPa | 1MPa | Non-Corrosive Gas | Gauge | +50°C | Wire Lead | ±1 % | Analogue | 1 ms, 128 ms, 16 ms, 512 ms | 1 → 5 V | PBT | IP40 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Gauge Pressure Sensor For Non-Corrosive Gas, 1Mpa Max Pressure, 12 to 24V dc, IP40 Pressure sensor -1...10 bar, DP102AEP, Panasonic Panasonic 计量 压力传感器 , 1Mpa最大压力读数, 12 → 24 V 直流, IP40 G1/8 Panasonic Corporation | 13 | 1: ¥848.90 | 12 → 24 V dc | -0.1MPa | 1MPa | Non-Corrosive Gas | Gauge | +50°C | Wire Lead | ±1 % | Relay | 2.5 ms | 100 mA, 5 V | PBT | IP40 | G1/8 | 非腐蚀性气体 | 导线 | IP40 | 1Mpa | -0.1Mpa | 0.6...5 V | 15 | 0.05 % | Pressure sensor | max.100 mA | Pressure | 1 | 12...24 VDC | 1 | IP 40 | G1/8" Outside Thread and M5 Inside Thread | 30 x 30 x 42.5 mm | Multifunction | Cable, 2 m |
 | 251 | 1: ¥233.2876 | - | 0kPa | 100kPa | - | - | - | PCB | - | - | - | - | - | - | - | - | - | - | 100kPa | 0kPa | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Gauge Pressure Sensor For Non-Corrosive Gas, 100kPa Max Pressure, 12 to 24V dc, IP40 Panasonic Corporation | 55 | 1: ¥1,058.964 | 12 → 24 V dc | -100kPa | 100kPa | Non-Corrosive Gas | Gauge | +50°C | Wire Lead | ±1 % | Analogue | 1 ms, 128 ms, 16 ms, 512 ms | 1 → 5 V | PBT | IP40 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Gauge Pressure Sensor For Non-Corrosive Gas, 1Mpa Max Pressure, 12 to 24V dc, IP40 Pressure sensor -1...10 bar, DP112AEPJ, Panasonic Panasonic 计量 压力传感器 , 1Mpa最大压力读数, 12 → 24 V 直流, IP40 G1/8 Panasonic Corporation | 10 | 1: ¥956.80 | 12 → 24 V dc | -0.1MPa | 1MPa | Non-Corrosive Gas | Gauge | +50°C | Wire Lead | ±1 % | Relay | 2.5 ms | 100 mA, 5 V | PBT | IP40 | G1/8 | 非腐蚀性气体 | 导线 | IP40 | 1Mpa | -0.1Mpa | 0.6...5 V | 15 | 0.05 % | Pressure sensor | max.100 mA | Pressure | 1 | 12...24 VDC | 1 | IP 40 | G1/8" Outside Thread and M5 Inside Thread | 30 x 30 x 42.5 mm | Multifunction | Plug M8 |
 Differential, Gauge Pressure Sensor For Non-Corrosive Gas, 12 to 24V dc Panasonic 分差，计量 压力传感器 , 12 → 24 V 直流, IP67 NPT 1/8 Panasonic Corporation | 40 | 1: ¥1,432.658 | 12 → 24 V dc | - | - | Non-Corrosive Gas | Differential, Gauge | +50°C | - | - | - | - | - | - | - | NPT 1/8 | 非腐蚀性气体 | 导线 | IP67 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Gauge Pressure Sensor For Non-Corrosive Gas, 100kPa Max Pressure, 12 to 24V dc, IP40 Pressure sensor -1...1 bar, DP111EPJ, Panasonic Panasonic 计量 压力传感器 , 100kPa最大压力读数, 12 → 24 V 直流, IP40 G1/8 Panasonic Corporation | 10 | 1: ¥877.70 | 12 → 24 V dc | -100kPa | 100kPa | Non-Corrosive Gas | Gauge | +50°C | Wire Lead | ±1 % | Relay | 2.5 ms | 100 mA | PBT | IP40 | G1/8 | 非腐蚀性气体 | 导线 | IP40 | 100kPa | -100kPa | PNP | 5 | 0.05 % | Pressure sensor | max.100 mA | Pressure | 2 | 12...24 VDC | 0 | IP 40 | G1/8" Outside Thread and M5 Inside Thread | 30 x 30 x 42.5 mm | Standard | Plug M8 |
 | 480 | 1: ¥122.162 | - | 0kPa | 40kPa | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Gauge, Vacuum Pressure Sensor For Non-Corrosive Gas, 0kPa Max Pressure, 12 to 24V dc, IP40 Panasonic Corporation | 55 | 1: ¥1,058.964 | 12 → 24 V dc | -101.3kPa | 0kPa | Non-Corrosive Gas | Gauge, Vacuum | +50°C | Wire Lead | ±1 % | Analogue | 1 ms, 128 ms, 16 ms, 512 ms | 1 → 5 V | PBT | IP40 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Gauge Pressure Sensor For Non-Corrosive Gas, 100kPa Max Pressure, 12 to 24V dc, IP40 Pressure sensor -1...1 bar, DP111AEPJ, Panasonic Panasonic 计量 压力传感器 , 100kPa最大压力读数, 12 → 24 V 直流, IP40 G1/8 Panasonic Corporation | 15 | 1: ¥956.80 | 12 → 24 V dc | -100kPa | 100kPa | Non-Corrosive Gas | Gauge | +50°C | Wire Lead | ±1 % | Relay | 2.5 ms | 1 → 5 V dc, 100 mA | PBT | IP40 | G1/8 | 非腐蚀性气体 | 导线 | IP40 | 100kPa | -100kPa | 1...5 V | 5 | 0.05 % | Pressure sensor | max.100 mA | Pressure | 1 | 12...24 VDC | 1 | IP 40 | G1/8" Outside Thread and M5 Inside Thread | 30 x 30 x 42.5 mm | Multifunction | Plug M8 |
Differential, Gauge Pressure Sensor For Non-Corrosive Gas, 12 to 24V dc Panasonic 分差，计量 压力传感器 , 12 → 24 V 直流, IP67 NPT 1/8 Panasonic Corporation | 40 | 1: ¥1,432.658 | 12 → 24 V dc | - | - | Non-Corrosive Gas | Differential, Gauge | +50°C | - | - | - | - | - | - | - | NPT 1/8 | 非腐蚀性气体 | 导线 | IP67 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
