FPC/FFC矩形连接器 - 型号列表
共 61 个型号| 制造商零件编号 | 库存 | 价格 | RoHS | 标题 | 连接器性别 | 连接类型 | Insert | Contacts | Contact plating | Locking element | Rated voltage | Contact resistance | Dielectric strength | Insulation resistance | Rated current per contact | Lifetime | Insertion force | Withdrawal force | Flammability | Temperature range | Boot | Shell | Strain relief | Capacitance between contacts | Wiring | Wiresize | Cable O.D. | Locking device | Approvals | 可焊性 | Protection class | Standard compliance | 海关税号 | 重量 | 产品 | 颜色 | 宽度 | 长度 | 系列 | 附件类型 | 适用产品/相关产品 | SVHC | 材料表面处理 | 连接器颜色 | USOC 编码 | Shell plating | Locking element plating | 连接器类型 | 标准包装规格 | Panel thickness | Mounting direction | Shell coating | 电缆长度 | 线缆护套颜色 | 产品类别 | 方向 | 安装类型 | 接触镀层 | 触头材料 | 产品子类型 | 机械寿命 | 深度 | 高度 | 喷嘴开口 | 配置 | 端口数 | 尺寸/外形 | 类型 | 产品特性 | Switching contacts |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Patch Panels PATCH CABLE PREASSEM W/USB AB 2.0 COMP 1M Cable Assembly Patch Cord 1m 4 POS USB Type A to 4 POS USB Type B PL-PL CABLE ASSEMBLY, USB 2.0, 3.28FT PATCHCABLE-PREASSEMBLEDWITHUSB Cable assembly USB A - USB B 1 m, NKUSB-1, Neutrik Neutrik | 62 | 2: ¥323.0211 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 85444290 | 4.860752 oz | - | - | - | - | - | - | - | - | - | - | - | - | - | :USB B Receptacle | - | - | - | - | :3.28ft | :- | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Patch Panels 3C .173 W/2-SWITCH Straight DC Power Socket, Palladium Plate Neutrik 直向 直流电源插座, 镀钯触点 REAN / Neutrik | 145 | 1: ¥23.50 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Patch Panels | 直 | Straight | Palladium | Nickel Silver Alloy | Bantam (TT) | Obsolete | - | - | - | - | - | - | - | - | - |
 XLR Connectors RUBBER GASKET BLUE D-SIZE CHASSIS D-Size Gasket Blue Modular Connectors / Ethernet Connectors RUBBER GASKET BLUE D-SIZE CHASSIS Connector Accessories Sealing Gasket Blue SEALING GASKET D-SHAPE CHASSIS BLUE Gasket-rubberforusewithDsizechassisconnec Neutrik opticalCON 系列 D-Shape 底盘连接器 Neutrik | 32 | 1: ¥18.12 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 85366990 | 0.049384 oz | Accessories | Blue | 39.2mm | 34.2mm | OpticalCON | Sealing Gasket | OpticalCON D-Shape Chassis Connectors | :No SVHC (20-Jun-2013) | :- | :Blue | RJ45 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 XLR Connectors GASKET D-SZ CHASSIS CONNECTOR - WHITE D-Size Gasket White Modular Connectors / Ethernet Connectors GASKET D-SZ CHASSIS CONNECTOR - WHITE Connector Accessories Sealing Gasket White SEALING GASKET D-SHAPE CHASSIS WHITE Gasket-rubberforusewithDsizechassisconnec Neutrik opticalCON 系列 D-Shape 底盘连接器 Neutrik | 51 | 1: ¥18.12 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 85366990 | 0.049384 oz | Accessories | White | 39.2mm | 34.2mm | OpticalCON | Sealing Gasket | OpticalCON D-Shape Chassis Connectors | :No SVHC (20-Jun-2013) | :- | :White | RJ45 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 XLR Connectors RUBBER GASKET BLACK CONNECTOR - BLACK D-Size Gasket Black Modular Connectors / Ethernet Connectors RUBBER GASKET BLACK CONNECTOR - BLACK Connector Accessories Sealing Gasket Black SEALING GASKET D-SHAPE CHASSIS BLACK D-SIZEGASKETBLACK Neutrik opticalCON 系列 D-Shape 底盘连接器 Neutrik | 358 | 1: ¥18.12 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 85366990 | 0.049384 oz | Accessories | Black | 39.2mm | 34.2mm | OpticalCON | Sealing Gasket | OpticalCON D-Shape Chassis Connectors | :No SVHC (20-Jun-2013) | :- | :Black | RJ45 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 XLR Connectors RUBBER GASKET GREEN CONNECTOR - GREEN D-Size Gasket Green Modular Connectors / Ethernet Connectors RUBBER GASKET GREEN CONNECTOR - GREEN SEALING GASKET D-SHAPE CHASSIS GREEN Gasket-rubberforusewithDsizechassisconnec Neutrik opticalCON 系列 D-Shape 底盘连接器 Neutrik | 21 | 1: ¥18.12 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 85366990 | 0.049384 oz | Accessories | Green | 39.2mm | 34.2mm | OpticalCON | Sealing Gasket | OpticalCON D-Shape Chassis Connectors | :No SVHC (20-Jun-2013) | :- | :Green | RJ45 | - | - | - | 20 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 XLR Connectors RUBBER GASKET YELLOW CONNECTOR - YELLOW D-Size Gasket Yellow Modular Connectors / Ethernet Connectors RUBBER GASKET YELLOW CONNECTOR - YELLOW SEALING GASKET D-SHAPE CHASSIS YELLO D-SIZEGASKETBLACK Neutrik opticalCON 系列 D-Shape 底盘连接器 Neutrik | 108 | 1: ¥18.12 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 85366990 | 0.049384 oz | Accessories | Yellow | 39.2mm | 34.2mm | OpticalCON | Sealing Gasket | OpticalCON D-Shape Chassis Connectors | :No SVHC (20-Jun-2013) | :- | :Yellow | RJ45 | - | - | - | 20 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 XLR Connectors RUBBER GASKET RED CONNECTOR - RED D-Size Gasket Red Modular Connectors / Ethernet Connectors RUBBER GASKET RED CONNECTOR - RED Connector Accessories Sealing Gasket Red SEALING GASKET D-SHAPE CHASSIS RED Gasket-rubberforusewithDsizechassisconnec Neutrik opticalCON 系列 D-Shape 底盘连接器 Neutrik | 142 | 1: ¥18.12 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 85366990 | 0.049384 oz | Accessories | Red | 39.2mm | 34.2mm | OpticalCON | Sealing Gasket | OpticalCON D-Shape Chassis Connectors | :No SVHC (20-Jun-2013) | :- | :Red | RJ45 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Jack Socket 48-Port Patch Panel, 1U Rack Height Patch Panels 24x1/4'' Dual Jacks Half Normalld Bottom 1/4""PATCHPANEL 插孔插座 48路 配线板, 1U机架高度 Neutrik | 22 | 1: ¥590.81 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Jack Socket | - | - | - | - | - | - | - | - | - | - | - | - | - | 19in | 1U | Half Normal | 半标准 | 48 | - | - | - | - |
 Z-Panel Frame Plate 2D Racks & Rack Cabinet Accessories Z-PANEL FRAME PLATE 2D SIZE, BLACK The NZPFD-2 Plate Can Be Loaded With Two Optical Con Duo Or Quad Chassis Connectors Z-Panelframeplate2D-Sizeknockouts,connectors Neutrik | 227 | 1: ¥257.4412 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Rack Panels | Black | 44mm | 132.5mm | OpticalCON | Panel Frame Plate | OpticalCON 19 in Z-Panel Frame | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 5.24 in L x 1.73 in W | Frame Plate | 2 D-size knockouts | - |
 Neutrik | 909 | 1: ¥23.664 | - | NCJ6FI-S | female | Combo | PA66 | Bronze (CuSn6) | 0.2 µm Au hard alloy over 2 µm Ni | Steel Ck67 | < 50 V | < 20 mΩ (jack) | 1,5 kVdc | > 10 GΩ (initial) | 7,5 A (Jack) | > 1000 mating cycles | ≤ 25 N | ≤ 25 N | UL 94 V-0 | -30 °C to +80 °C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Nickel | - | - | max. 7 mm 0.27" | Rear mounting | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Neutrik | 300 | 1: ¥21.828 | - | NCJ9FI-H | female | Combo | PA66 | Bronze (CuSn6) | 0.2 µm Au hard alloy over 2 µm Ni | Steel Ck67 | < 50 V | < 20 mΩ (jack & switching contacts) | 1,5 kVdc | > 10 GΩ (initial) | 7,5 A (Jack) | > 1000 mating cycles | ≤ 25 N | ≤ 25 N | UL 94 V-0 | -30 °C to +80 °C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Nickel | - | - | max. 7 mm 0.27" | Rear mounting | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 3 |
 Neutrik | 117 | 1: ¥51.816 | - | NC6FX | female | XLR | Polyamide (PA 6.6 30 % GR) | Brass (CuZn39Pb3) | 2 µm Ag over 2 µm Ni | St3K32 (latch) / Ck 67 (spring) | < 50 V | ≤ 3 mΩ | 1,5 kVdc | > 10 GΩ (initial) | 7,5 A | > 1000 mating cycles | ≤ 20 N | ≤ 20 N | UL 94 HB | -30 °C to +80 °C | Polyurethan | Zinc diecast (ZnAl4Cu1) | Polyacetal (POM) | ≤ 7 pF | Solder contacts | max. 18 AWG | 3.5 - 8.0 mm | Latch lock | UL | Complies with IEC 68-2-20 | IP 40 | IEC 61076-2-103 | - | - | - | - | - | - | - | - | - | - | - | - | - | Nickel | Nickel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Neutrik | 50 | 25: ¥55.4329 | - | NC6MX | male | XLR | Polyamide (PA 6.6 30 % GR) | Brass (CuZn39Pb3) | 2 µm Ag over 2 µm Ni | Zinc diecast (ZnAl4Cu1) | < 50 V | ≤ 3 mΩ | 1,5 kVdc | > 10 GΩ (initial) | 7,5 A | > 1000 mating cycles | ≤ 20 N | ≤ 20 N | UL 94 HB | -30 °C to +80 °C | Polyurethan | Zinc diecast (ZnAl4Cu1) | Polyacetal (POM) | ≤ 7 pF | Solder contacts | max. 18 AWG | 3.5 - 8.0 mm | Latch lock | UL | Complies with IEC 68-2-20 | IP 40 | IEC 61076-2-103 | - | - | - | - | - | - | - | - | - | - | - | - | - | Nickel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Neutrik | 103 | 1: ¥43.248 | - | NC7MX | male | XLR | Polyamide (PA 6.6 30 % GR) | Brass (CuZn39Pb3) | 2 µm Ag over 2 µm Ni | Zinc diecast (ZnAl4Cu1) | < 50 V | ≤ 3 mΩ | 1,5 kVdc | > 10 GΩ (initial) | 5 A | > 1000 mating cycles | ≤ 20 N | ≤ 20 N | UL 94 HB | -30 °C to +80 °C | Polyurethan | Zinc diecast (ZnAl4Cu1) | Polyacetal (POM) | ≤ 9 pF | Solder contacts | max. 18 AWG | 3.5 - 8.0 mm | Latch lock | UL | Complies with IEC 68-2-20 | IP 40 | IEC 61076-2-103 | - | - | - | - | - | - | - | - | - | - | - | - | - | Nickel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Neutrik | 614 | 1: ¥28.696 | - | NC3FX-BAG | female | XLR | Polyamide (PA66) | Bronze (CuSn8) | 2 µm Ag over 2 µm Ni | St3K32 (latch) / Ck 67 (spring) | < 50 V | ≤ 3 mΩ | 1,5 kVdc | > 10 GΩ (initial) | 16 A | > 1000 mating cycles | ≤ 20 N | ≤ 20 N | UL 94 V-0 | -30 °C to +80 °C | Polyurethan | Zinc diecast (ZnAl4Cu1) | Polyacetal (POM) | ≤ 4 pF | Solder contacts | max. 14 AWG | 3.5 - 8.0 mm | Latch lock | UL | Complies with IEC 68-2-20 | IP 40 | IEC 61076-2-103 | - | - | - | - | - | - | - | - | - | - | - | - | - | Black chromium | Nickel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Neutrik | 16 | 4: ¥71.808 | - | NC3MX-B | male | XLR | Polyamide (PA66) | Brass (CuZn39Pb3) | 0.2 µm Au hard alloy over 2 µm Ni | Zinc diecast (ZnAl4Cu1) | < 50 V | ≤ 3 mΩ | 1,5 kVdc | > 10 GΩ (initial) | 16 A | > 1000 mating cycles | ≤ 20 N | ≤ 20 N | UL 94 V-0 | -30 °C to +80 °C | Polyurethan | Zinc diecast (ZnAl4Cu1) | Polyacetal (POM) | ≤ 4 pF | Solder contacts | max. 14 AWG | 3.5 - 8.0 mm | Latch lock | UL | Complies with IEC 68-2-20 | IP 40 | IEC 61076-2-103 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Black KTL | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Neutrik | 307 | 1: ¥53.72 | - | NC5FX | female | XLR | Polyamide (PA66) | Brass (CuZn39Pb3) | 2 µm Ag | St3K32 (latch) / Ck 67 (spring) | < 50 V | ≤ 3 mΩ | 1,5 kVdc | > 10 GΩ (initial) | 7,5 A | > 1000 mating cycles | ≤ 20 N | ≤ 20 N | UL 94 V-0 | -30 °C to +80 °C | Polyurethan | Zinc diecast (ZnAl4Cu1) | Polyacetal (POM) | ≤ 7 pF | Solder contacts | max. 18 AWG | 3.5 - 8.0 mm | Latch lock | UL | Complies with IEC 68-2-20 | IP 40 | IEC 61076-2-103 | - | - | - | - | - | - | - | - | - | - | - | - | - | Nickel | Nickel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Neutrik | 592 | 1: ¥35.292 | - | NC5MX | male | XLR | Polyamide (PA 66) | Brass (CuZn39Pb3) | 2 µm Ag | Zinc diecast (ZnAl4Cu1) | < 50 V | ≤ 3 mΩ | 1,5 kVdc | > 10 GΩ (initial) | 7,5 A | > 1000 mating cycles | ≤ 20 N | ≤ 20 N | UL 94 V-0 | -30 °C to +80 °C | Polyurethan | Zinc diecast (ZnAl4Cu1) | Polyacetal (POM) | ≤ 7 pF | Solder contacts | max. 18 AWG | 3.5 - 8.0 mm | Latch lock | UL | Complies with IEC 68-2-20 | IP 40 | IEC 61076-2-103 | - | - | - | - | - | - | - | - | - | - | - | - | - | Nickel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Neutrik | 118 | 1: ¥51.952 | - | NC5MX-BAG | male | XLR | Polyamide (PA 66) | Brass (CuZn39Pb3) | 2 µm Ag | Zinc diecast (ZnAl4Cu1) | < 50 V | ≤ 3 mΩ | 1,5 kVdc | > 10 GΩ (initial) | 7,5 A | > 1000 mating cycles | ≤ 20 N | ≤ 20 N | UL 94 V-0 | -30 °C to +80 °C | Polyurethan | Zinc diecast (ZnAl4Cu1) | Polyacetal (POM) | ≤ 7 pF | Solder contacts | max. 18 AWG | 3.5 - 8.0 mm | Latch lock | UL | Complies with IEC 68-2-20 | IP 40 | IEC 61076-2-103 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Black KTL | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
