Microchip Technology Inc.- 电压调节器
02
MODELS电压调节器 - 型号列表共 236 个型号
| 制造商零件编号 | 价格/库存 | Package | Polarity | Number of Outputs | Minimum Input Voltage | Maximum Input Voltage | Maximum Output Current | Output Voltage | Typical Dropout Voltage @ Current | Accuracy | Line Regulation | Load Regulation | Operating Temperature | Mounting | Output Type | Standard Package | Product Category | RoHS | Input Voltage MAX | Output Current | Maximum Operating Temperature | Mounting Style | Package / Case | Input Voltage MIN | Minimum Operating Temperature | Packaging | Factory Pack Quantity | Voltage Regulation Accuracy | Regulator Topology | Mounting Type | Number of Regulators | Supplier Device Package | Voltage - Output | Voltage - Dropout (Typical) | Current - Output | Voltage - Input | rohs | Dropout Voltage - Max | Input Voltage Min | Input Voltage Max | Dropout Voltage Vdo | Voltage Regulator Case Style | No. of Pins | Operating Temperature Min | Operating Temperature Max | MSL | SVHC | Operating Temperature Range | Weight (kg) | Tariff No. | Input Bias Current - Max | Output Voltage Nom. | Base Number | Primary Input Voltage | Unit Pack | MOQ | Output current | Input Voltage | Type | Maximum Quiescent Current | Other Names | Voltage Regulator Type | Pin Count | Package Type | Accuracy % | No. of Outputs | Supply Voltage Min | Termination Type | Operating Temp Range | Regulator Output Type | Polarity Type | Output Voltage Accuracy | Operating Temperature Classification | Input Voltage (Min) | Topology | Rad Hardened | Current,Output | PackageType | Temperature,Operating,Range | Voltage,Dropout | Voltage,Input | Dropout Voltage@Current (Typ) | Dropout Voltage@Current (Max) | Operating Voltage Tolerance + | Output Current Max | Voltage,Output | Case | Max input voltage | Multiplicity | Integrated circuit type | Kind of voltage regulator | Gross weight | Voltage drop | Output voltage | spg | Collective package [pcs] | Matchcode | Standard Leadtime | ShortCirc.prot. | Op.Temp R.min | Op.Temp R.max | Mode | Automotive | Dropout Voltage | Tolerance | Leadfree Defin. | Quiescent curre | Quiescent Current (Max) | Overtemp.prot. | Regulation,Line | Regulation,Load | RegulatorType | Voltage,Noise | Voltage,Supply,RejectionRatio | Supply Voltage Max | PowerDissipation | Output voltage tolerance | Current,Supply | Maximum Power Dissipation | Operating current | Typical Dropout Voltage @ Current | Screening Level | Minimum Input Voltage | EU RoHS | Minimum Operating Temperature | Supplier Package | Standard Package Name | Maximum Operating Temperature | Special Features | Maximum Dropout Voltage @ Current | Output Voltage | Maximum Output Current | Accuracy | Maximum Input Voltage | Lead Shape | Operation Mode | Maximum Quiescent Current | PSRR / Ripple Rejection - Typ | Dimensions | Height | Length | Width | Resistance,Thermal,JunctiontoCase | Quiescent Current | Time,Rise | Dropout Voltage (Max) | Input Bias Current (Max) | Output Voltage Tolerance | PSRR / Ripple Rejection (Typ) | Shutdown | Product | Function | Output | PrimaryType | Technology | Series | Device Marking | IC Generic Number | Reference Voltage | Package Width | PCB | Package Length | Package Height | Tab | Output Voltage Min | Output Voltage Max | Output Voltage Adjustable Range | Power Supply IC Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 询价 | 3SOT-23 | Positive | 1 | 2.3 V | 6 V | 0.2(Min) A | 1.2 V | 0.15@200mA V | ±2 % | 0.75(Typ) %/V | 1(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Tape & Reel | Low Dropout Regulators - LDO | RoHS Compliant | 6 V | 250 mA | + 125 C | SMD/SMT | SOT-23-3 | 2.3 V | - 40 C | Reel | 3000 | 0.4 % | Positive Fixed | Surface Mount | 1 | SOT-23-3 | 1.2V | 0.15V @ 200mA | 200mA (Min) | 2.3 V ~ 6 V | Lead free / RoHS Compliant | 350 mV | :2.3V | :6V | :178mV | :SOT-23 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (16-Dec-2013) | :-40°C to +125°C | 0.0002 | 85423990 | 0.0016 mA | :1.2V | :1700 | :2.2V | - | - | 250mA | - | - | 0.004 mA | MCP1700T-1202E/TTCT | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | SOT23-3 | 6V | 1 | voltage stabiliser | LDO, fixed | 0.04 g | 178mV | 1.2V | 250 | 250 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ±0.4% | - | 0.3696 W | 1.6µA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 44 dB | - | - | - | - | - | - | - | 350 mV | 0.0016 mA | 2 % | 44 dB | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 3SOT-23A | Positive | 1 | 2.7 V | 13.2 V | 0.25(Min) A | 3 V | 0.625@250mA V | ±2 % | 0.1(Typ) %/V | 1(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Tape & Reel | LDO Voltage Regulators | RoHS Compliant | 13.2 V | 250 mA | +125 °C | SMD/SMT | TO-236-3, SC-59, SOT-23-3 | + 2.7 V | -40 °C | REEL | 3000 | 0.4 % | Positive Fixed | Surface Mount | 1 | SOT-23A-3 | 3V | 0.625V @ 250mA | 250mA (Min) | Up to 13.2V | Lead free / RoHS Compliant | 0.975 V at 250 mA | :2.7V | :13.2V | :330mV | :SOT-23 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.000033 | 85423990 | 0.002 mA | :3V | :1702 | :3.975V | 3000 | 3000 | 0.25A | 13.2V | VoltageRegulator | 0.005 mA | MCP1702T-3002E/CBCT | LDO | 3 | SOT-23A | :0.4% | :1 | :2.7V | :SMD | -40C to 125C | Fixed | Positive | �2 % | Automotive | 2.7 V | LDO | No | 250mA | SOT-23A | -40to+125°C | 625mV | 13.2V | 0.625@250mA | 0.975@250mA | :2% | :0.25A | 3V | - | - | - | - | - | - | - | - | - | - | MCP1702T-3002E/CB | 19 weeks | YES | -40°C | 125°C | POS | NO | 630mV | 2% | RoHS-conform | 0.002mA | 0.005 mA | YES | ±0.1%/V | ±1% | LowDropout,PositiveVoltageOut | 8μV/sqrtHz | 44dB | :13.2V | 253mW | - | 2μA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Linear | - | - | 3.1 x 1.8 x 1.3mm | 1.3mm | 3.1mm | 1.8mm | 110°C/W | 0.002mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 5SOT-23 | Positive | 1 | 2.7 V | 6 V | 0.05(Min) A | 3 V | 0.002@100uA|0.065@20mA|0.085@50mA V | ±0.5 % | 0.05(Typ) % | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Tape & Reel | LDO Voltage Regulators | RoHS Compliant | 6 V | 50 mA | +125 °C | SMD/SMT | SC-74A, SOT-753 | + 2.7 V | -40 °C | Tape and Reel | 3000 | 2.5 % | Positive Fixed | Surface Mount | 1 | SOT-23-5 | 3V | 0.085V @ 50mA | 50mA (Min) | Up to 6V | Lead free / RoHS Compliant | 250 / 400 mV | :2.7V | :6V | :85mV | :SOT-23 | :5 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.000033 | 85423990 | - | :3V | :1014 | :4V | 3000 | 3000 | 0.05A | 6.5V | Linear | - | TC1014-3.0VCT713CT | :LDO | 5 | SOT-23 | :0.5% | :1 | :2.7V | :SMD | - | - | - | - | - | - | - | - | 50mA | SOT-23-5 | -40to+125°C | 85mV | 6V | - | - | :0.5% | :0.05A | 3V | SOT23-5 | 6V | 1 | voltage stabiliser | fixed | 0.14 g | 85mV | 3V | 200 | 200 | TC1014-3.0VCT713 | 14 weeks | YES | -40°C | 125°C | POS | NO | 250mV | 0.2% | RoHS-conform | 0.05mA | - | YES | 0.05% | 0.5% | LowDropout | 600nV/sqrtHz | 64dB | :6V | 318mW | ±0.5% | 50μA | - | - | 0.002@100uA|0.065@20mA|0.085@50mA | Extended | 2.7 | Compliant | -40 | SOT-23 | SOT-23 | 125 | Current Limit|Shutdown|Thermal Pr... | 0.12@50mA | 3 | 0.05(Min) | ±0.5 | 6 | Gull-wing | - | - | - | 3.1 x 1.8 x 1.3mm | 1.3mm | 3.1mm | 1.8mm | - | - | - | - | - | - | - | YES | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 6DDPAK | Positive | 1 | 2.3 V | 6 V | 1.5 A | 3.3 V | 0.33@1.5A V | ±2 % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 1.5 A | + 125 C | SMD/SMT | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA | 2.3 V | - 40 C | Tube | 50 | 2 % | Positive Fixed | Surface Mount | 1 | 5-DDPAK | 3.3V | 0.33V @ 1.5A | 1.5A (Min) | Up to 6V | Lead free / RoHS Compliant | 600 mV | :2.3V | :6V | :330mV | :TO-263 | :5 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.0002 | 85423990 | 120 uA | :3.3V | :1827 | :3.9V | 50 | 350 | - | 6 V | Low Quiescent Current Low Voltage | - | MCP18273302EET | Linear | 5 +Tab | DDPAK | - | - | - | - | -40C to 125C | Fixed | Positive | �2 % | Automotive | 2.3 V | LDO | No | - | - | - | - | - | 0.33@1.5A | 0.6@1.5A | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 2.083 W | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 60 dB | - | - | - | - | - | - | - | - | - | - | - | - | LDO Voltage Regulator | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 4SOT-223 | Positive | 1 | 2.7 V | 6 V | 0.5 A | 2.5 V | 0.02@100uA|0.06@100mA|0.2@300mA|0.35@500mA V | ±0.5 % | 0.003(Typ) %/V | 0.002(Typ) %/mA | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 500 mA | + 125 C | SMD/SMT | TO-261-4, TO-261AA | + 2.7 V | - 40 C | Tube | 78 | 0.5 % | Positive Fixed | Surface Mount | 1 | SOT-223-3 | 2.5V | 0.35V @ 500mA | 500mA (Min) | Up to 6V | Contains lead / RoHS non-compliant | 0.03 V at 100 uA | :2.7V | :6V | :350mV | :SOT-223 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.0002 | 85423990 | 0.08 mA | :2.5V | :1262 | :3.5V | 78 | 4000 | - | 6 V | Linear | - | - | LDO | 3 +Tab | SOT-223 | - | - | - | - | -40C to 125C | Fixed | Positive | �0.5 % | Automotive | 2.7 V | LDO | No | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Linear | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 8SOIC N | Positive | 1 | 2.3 V | 6 V | 0.5(Min) A | 3.3 V | 0.21@500mA V | ±2 % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 500 mA | + 125 C | SMD/SMT | 8-SOIC (0.154", 3.90mm Width) | + 2.3 V | - 40 C | Tube | 100 | 2 % | Positive Fixed | Surface Mount | 1 | 8-SOIC N | 3.3V | 0.21V @ 500mA | 500mA (Min) | Up to 6V | Lead free / RoHS Compliant | 0.35 V at 500 mA | :2.3V | :6V | :210mV | :SOIC | :8 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.0001 | 85411000 | 0.12 mA | :3.3V | :1725 | :3.65V | 100 | 900 | 500mA | 6 V | VoltageRegulator | 0.22 mA | MCP17253302ESN | Linear | 8 | SOIC N | :0.5% | :1 | :2.3V | :SMD | -40C to 125C | Fixed | Positive | �2 % | Automotive | 2.3 V | LDO | No | 500mA | SOIC-8 | -40to+125°C | 210mV | 6V | 0.21@500mA | 0.35@500mA | :2% | :0.5A | 3.3V | SO8 | 6V | 1 | voltage stabiliser | fixed | 0.68 g | 210mV | 3.3V | 25 | 25 | - | - | - | - | - | - | - | - | - | - | - | 0.22 mA | - | - | - | - | - | - | :6V | - | ±0.5% | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Thermocouple | Voltage | Temperature | Resistive | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 4DDPAK | Positive | 1 | 2.3 V | 6 V | 1.5 A | 3.3 V | 0.33@1.5A V | ±2 % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 1.5 A | + 125 C | SMD/SMT | TO-263-4, D²Pak (3 Leads + Tab), TO-263AA | + 2.3 V | - 40 C | TUBE | 50 | 2 % | Positive Fixed | Surface Mount | 1 | 3-DDPAK | 3.3V | 0.33V @ 1.5A | 1.5A (Min) | Up to 6V | Lead free / RoHS Compliant | 0.6 V at 1.5 A | :2.3V | :6V | :330mV | :TO-263 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.0002 | 85423990 | 0.12 mA | :3.3V | :1827 | :3.9V | 50 | 350 | 1.5A | 6V | - | - | MCP1827S3302EEB | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | MCP1827S-3302E/EB | 14 weeks | YES | -40°C | 125°C | POS | NO | 330mV | 2% | RoHS-conform | 0.12mA | - | YES | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 4SOT-89 | Positive | 1 | 2.3 V | 6 V | 0.25(Min) A | 3.3 V | 0.178@250mA V | ±2 % | 0.75(Typ) %/V | 1(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Tape & Reel | LDO Voltage Regulators | RoHS Compliant | 6 V | 250 mA | + 125 C | SMD/SMT | TO-243AA | + 2.3 V | - 40 C | Tape and Reel | 1000 | 3 % | Positive Fixed | Surface Mount | 1 | SOT-89-3 | 3.3V | 0.178V @ 250mA | 250mA (Min) | Up to 6V | Lead free / RoHS Compliant | 350 mV | :2.3V | :6V | :178mV | :SOT-89 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.000033 | 85411000 | 0.0016 mA | :3.3V | :1700 | :6V | 1000 | 1 | 0.25A | 6.5V | Linear | 0.004 mA | MCP1700T3302EMBCT | Linear | 4 | SOT-89 | :0.4% | :1 | :2.3V | :SMD | -40C to 125C | Fixed | Positive | �2 % | Automotive | 2.3 V | LDO | No | 250mA | SOT-89 | -40to+125°C | 178mV | 6V | 0.178@250mA | 0.35@250mA | :2% | :0.25A | 3.3V | SOT89-3 | 6V | 1 | voltage stabiliser | LDO, fixed | 0.75 g | 178mV | 3.3V | 1000 | 1000 | MCP1700T-3302E/MB | 14 weeks | YES | -40°C | 125°C | POS | NO | 178mV | 2% | RoHS-conform | 0.0016mA | 0.004 mA | YES | ±0.75%/V | ±1% | LowDropout | 3μV/sqrtHz | 44dB | - | 1.635W | ±0.4% | - | 1.635 W | 1.6µA | 0.178@250mA | Extended | 2.3 | Compliant | -40 | SOT-89 | SOT-89 | 125 | Current Limit|Short Circuit Prote... | 0.35@250mA | 3.3 | 0.25(Min) | ±2 | 6 | Flat | - | 0.004 | - | - | - | - | - | - | - | 500μs | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 8SOIC N | Positive | 1 | 2.3 V | 6 V | 1(Min) A | 0.8 V | 0.22@1A V | ±2.5 % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 1 A | + 125 C | SMD/SMT | 8-SOIC (0.154", 3.90mm Width) | + 2.3 V | - 40 C | Tube | 100 | 2.5 % | Positive Fixed | Surface Mount | 1 | 8-SOIC N | 0.8V | 0.22V @ 1A | 1A (Min) | 2.3 V ~ 6 V | Lead free / RoHS Compliant | 220 mV | :2.3V | :6V | :220mV | :SOIC | :8 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.0002 | 85423990 | 0.14 mA | :800mV | :1726 | :2.3V | 100 | 600 | - | - | - | 0.22 mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
,TO-226_straightlead.jpg){kind=small} | 询价 | 3TO-92 | Positive | 1 | 2.3 V | 6 V | 0.25(Min) A | 3.3 V | 0.178@250mA V | ±2 % | 0.75(Typ) %/V | 1(Typ) % | -40 to 125 °C | Through Hole | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 250 mA | + 125 C | Through Hole | TO-226-3, TO-92-3 (TO-226AA) | + 2.3 V | - 40 C | Bag | 1000 | 3 % | Positive Fixed | Through Hole | 1 | TO-92-3 | 3.3V | 0.178V @ 250mA | 250mA (Min) | Up to 6V | Lead free / RoHS Compliant | 350 mV | :2.3V | :6V | :178mV | :TO-92 | :3 | :-40°C | :125°C | :- | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.002963 | 85423990 | 0.0016 mA | :3.3V | :1700 | :6V | 1000 | 1000 | 0.25A | 6.5V | LDO | 0.004 mA | MCP17003302ETO | :Fixed | 3 | - | :0.4% | :1 | :2.3V | :Through Hole | - | - | - | - | - | - | - | - | 250mA | TO-92-3 | -40to+125°C | 300mV | 6V | - | - | :0.4% | :0.25A | 3.3V | - | - | - | - | - | - | - | - | - | - | MCP1700-3302E/TO | 14 weeks | YES | -40°C | 125°C | POS | NO | 178mV | 2% | RoHS-conform | 0.0016mA | - | YES | ±0.75%/V | ±1% | LowDropout | 3μV/sqrtHz | 44dB | - | 644mW | - | - | 0.644 W | - | 0.178@250mA | Extended | 2.3 | Compliant | -40 | TO-92 | TO-92 | 125 | Current Limit|Short Circuit Prote... | 0.35@250mA | 3.3 | 0.25(Min) | ±2 | 6 | Through Hole | - | 0.004 | 44 dB | - | - | - | - | - | - | 500μs | - | - | - | - | - | - | - | - | - | - | MCP1700 | :MCP1700-33 | :1700 | - | - | - | - | - | - | - | - | - | - |
| 询价 | 8SOIC N | Positive | 1 | 2.3 V | 6 V | 1(Min) A | 3.3 V | 0.22@1A V | ±2.5 % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 1 A | + 125 C | SMD/SMT | 8-SOIC (0.154", 3.90mm Width) | + 2.3 V | - 40 C | Tube | 100 | 2.5 % | Positive Fixed | Surface Mount | 1 | 8-SOIC N | 3.3V | 0.22V @ 1A | 1A (Min) | Up to 6V | Lead free / RoHS Compliant | 220 mV | :2.3V | :6V | :220mV | :SOIC | :8 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.000175 | 85423990 | 0.14 mA | :3.3V | :1726 | :3.8V | 100 | 600 | 1A | 6 V | VoltageRegulator | 0.22 mA | MCP17263302ESN | Linear | 8 | SOIC N | :0.4% | :1 | :2.3V | :SMD | -40C to 125C | Fixed | Positive | �2.5 % | Automotive | 2.3 V | LDO | No | 1000mA | SOIC-8 | -40to+125°C | 500mV | 6V | 0.22@1A | 0.5@1A | :2% | - | 3.3V | SO8 | 6V | 1 | voltage stabiliser | fixed | 0.72 g | 500mV | 3.3V | 100 | 100 | - | - | - | - | - | - | - | - | - | - | - | 0.22 mA | - | 0.05%/V | ±0.5% | Linear,LowDropout | 2μV/sqrtHz | 54dB | :6V | 0.366W | ±0.5% | 140μA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 6DDPAK | Positive | 1 | 2.3 V | 6 V | 1.5 A | 1.8 V | 0.33@1.5A V | ±2 % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 1.5 A | + 125 C | SMD/SMT | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA | + 2.3 V | - 40 C | Tube | 50 | 2 % | Positive Fixed | Surface Mount | 1 | 5-DDPAK | 1.8V | 0.33V @ 1.5A | 1.5A (Min) | 2.3 V ~ 6 V | Lead free / RoHS Compliant | 0.6 V at 1.5 A | :2.3V | :6V | :330mV | :TO-263 | :5 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.000175 | 85423990 | 0.12 mA | :1.8V | - | :2.4V | 50 | 350 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3TO-92 | Positive | 1 | 2.7 V | 13.2 V | 0.25(Min) A | 3.3 V | 0.525@250mA V | ±2 % | 0.1(Typ) %/V | 1(Typ) % | -40 to 125 °C | Through Hole | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 13.2 V | 250 mA | + 125 C | Through Hole | TO-226-3, TO-92-3 (TO-226AA) | + 2.7 V | - 40 C | TRAY | 1000 | 0.4 % | Positive Fixed | Through Hole | 1 | TO-92-3 | 3.3V | 0.525V @ 250mA | 250mA (Min) | Up to 13.2V | Lead free / RoHS Compliant | 0.725 V at 250 mA | :2.7V | :13.2V | :525mV | :TO-92 | :3 | :-40°C | :125°C | :- | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.0002 | 85423990 | 0.002 mA | :3.3V | :1702 | :4.03V | 1000 | 1000 | 0.25A | 13.2V | Linear | 0.005 mA | MCP17023302ETO | Linear | 3 | TO-92 | :0.4% | :1 | :2.7V | :Through Hole | -40C to 125C | Fixed | Positive | �2 % | Automotive | 2.7 V | LDO | No | 250mA | TO-92-3 | -40to+125°C | 330mV | 13.2V | 0.525@250mA | 0.725@250mA | :2% | :0.25A | 3.3V | - | - | - | - | - | - | - | - | - | - | MCP1702-3302E/TO | 14 weeks | YES | -40°C | 125°C | POS | NO | 630mV | 2% | RoHS-conform | 0.002mA | 0.005 mA | YES | - | - | - | - | - | :13.2V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23 | Positive | 1 | 2.3 V | 6 V | 0.25(Min) A | 5 V | 0.178@250mA V | ±2 % | 0.75(Typ) %/V | 1(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Cut Tape | LDO Voltage Regulators | RoHS Compliant | 6 V | 250 mA | + 125 C | SMD/SMT | TO-236-3, SC-59, SOT-23-3 | + 2.3 V | - 40 C | Tape and Reel | 3000 | 3 % | Positive Fixed | Surface Mount | 1 | SOT-23-3 | 5V | 0.178V @ 250mA | 250mA (Min) | Up to 6V | Lead free / RoHS Compliant | 350 mV | :2.3V | :6V | :178mV | :SOT-23 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.002 | 85423990 | 0.0016 mA | :5V | :1700 | :6V | 3000 | 3000 | 0.25A | 6.5V | LDO | 0.004 mA | MCP1700T5002ETTDKR | Linear | 3 | SOT-23 | :0.4% | :1 | :2.3V | :SMD | -40C to 125C | Fixed | Positive | �2 % | Automotive | 2.3 V | LDO | No | - | - | - | - | - | 0.178@250mA | 0.35@250mA | :0.4% | :0.25A | - | - | - | - | - | - | - | - | - | - | - | MCP1700T-5002E/TT | 14 weeks | YES | -40°C | 125°C | POS | NO | 178mV | 2% | RoHS-conform | 0.0016mA | 0.004 mA | YES | - | - | - | - | - | - | - | - | - | 0.3696 W | - | 0.178@250mA | Extended | 2.3 | Compliant | -40 | SOT-23 | SOT-23 | 125 | Current Limit|Short Circuit Prote... | 0.35@250mA | 5 | 0.25(Min) | ±2 | 6 | Gull-wing | - | 0.004 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23A | Positive | 1 | 2.7 V | 13.2 V | 0.25(Min) A | 5 V | 0.33@250mA V | ±2 % | 0.1(Typ) %/V | 1(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Tape & Reel | LDO Voltage Regulators | RoHS Compliant | 13.2 V | 250 mA | +125 °C | SMD/SMT | TO-236-3, SC-59, SOT-23-3 | + 2.7 V | -40 °C | REEL | 3000 | 0.4 % | Positive Fixed | Surface Mount | 1 | SOT-23A-3 | 5V | 0.33V @ 250mA | 250mA (Min) | Up to 13.2V | Lead free / RoHS Compliant | 0.65 V at 250 mA | :2.7V | :13.2V | :330mV | :SOT-23 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.000033 | 85423990 | 0.002 mA | :5V | :1702 | :5.65V | 3000 | 3000 | 0.25A | 13.2V | VoltageRegulator | 0.005 mA | MCP1702T-5002E/CBCT | Linear | 3 | SOT-23A | :0.4% | :1 | :2.7V | :SMD | -40C to 125C | Fixed | Positive | �2 % | Automotive | 2.7 V | LDO | No | 250mA | SOT-23A | -40to+125°C | 330mV | 13.2V | 0.33@250mA | 0.65@250mA | :2% | :0.25A | 5V | - | - | - | - | - | - | - | - | - | - | MCP1702T-5002E/CB | 19 weeks | YES | -40°C | 125°C | POS | NO | 630mV | 2% | RoHS-conform | 0.002mA | 0.005 mA | - | ±0.1%/V | ±1% | LowDropout,PositiveVoltageOut | 8μV/sqrtHz | 44dB | :13.2V | 253mW | - | 2μA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Linear | - | - | 3.1 x 1.8 x 1.3mm | 1.3mm | 3.1mm | 1.8mm | 110°C/W | 0.002mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 8SOIC N | Positive | 1 | 2.3 V | 6 V | 1.5(Min) A | 3.3 V | 0.33@1.5A V | ±2 % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 1.5 A | + 125 C | SMD/SMT | 8-SOIC (0.154", 3.90mm Width) | + 2.3 V | - 40 C | Tube | 100 | 2 % | Positive Fixed | Surface Mount | 1 | 8-SOIC N | 3.3V | 0.33V @ 1.5A | 1.5A (Min) | Up to 6V | Lead free / RoHS Compliant | 0.55 V at 1.5 A | :2.3V | :6V | :330mV | :SOIC | :8 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.000175 | 85423990 | 0.12 mA | :3.3V | :1727 | :3.85V | 100 | 480 | 1.5A | 6 V | Linear | 0.22 mA | MCP17273302ESN | Linear | 8 | SOIC N | :0.5% | :1 | :2.3V | :SMD | -40C to 125C | Fixed | Positive | �2 % | Automotive | 2.3 V | LDO | No | 1500mA | SOIC-8 | -40to+125°C | 330mV | 6V | 0.33@1.5A | 0.55@1.5A | :2% | - | 3.3V | SO8 | 6V | 1 | voltage stabiliser | LDO, fixed | 0.49 g | 330mV | 3.3V | 50 | 50 | - | - | - | - | - | - | - | - | - | - | - | 0.22 mA | - | 0.05%/V | ±0.5% | Linear,LowDropout | 2μV/sqrtHz | 60dB | :6V | 0.433W | - | 120μA | - | 120µA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 8SOIC N | Positive | 1 | 2.3 V | 6 V | 1.5(Min) A | 5 V | 0.33@1.5A V | ±2 % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 6 V | 1.5 A | + 125 C | SMD/SMT | 8-SOIC (0.154", 3.90mm Width) | + 2.3 V | - 40 C | Tube | 100 | 2 % | Positive Fixed | Surface Mount | 1 | 8-SOIC N | 5V | 0.33V @ 1.5A | 1.5A (Min) | Up to 6V | Lead free / RoHS Compliant | 0.55 V at 1.5 A | :2.3V | :6V | :330mV | :SOIC | :8 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.000175 | 85423990 | 0.12 mA | :5V | :1727 | - | 100 | 480 | 1.5A | - | VoltageRegulator | 0.22 mA | - | :LDO | - | - | :0.5% | :1 | :2.3V | :SMD | - | - | - | - | - | - | - | - | 1500mA | SOIC-8 | -40to+125°C | 330mV | 6V | - | - | :2% | :1.5A | 5V | SO8 | 6V | 1 | voltage stabiliser | LDO, fixed | 0.16 g | 330mV | 5V | 100 | 100 | - | - | - | - | - | - | - | - | - | - | - | - | - | 0.05%/V | ±0.5% | Linear,LowDropout | 2μV/sqrtHz | 60dB | :6V | 0.433W | - | 120μA | - | 120µA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 4SOT-89 | Positive | 1 | 2.7 V | 16 V | 0.25(Min) A | 3.3 V | 0.525@250mA V | ±2 % | 0.1(Typ) %/V | 1(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Tape & Reel | LDO Voltage Regulators | RoHS Compliant | 16 V | 250 mA | + 125 C | SMD/SMT | TO-243AA | + 2.7 V | - 40 C | REEL | 1000 | 2 % | Positive Fixed | Surface Mount | 1 | SOT-89-3 | 3.3V | 0.525V @ 250mA | 250mA (Min) | Up to 16V | Lead free / RoHS Compliant | 0.65 V at 250 mA | :2.7V | :16V | :525mV | :SOT-89 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (16-Dec-2013) | :-40°C to +125°C | 0.0002 | 85423990 | 0.002 mA | :3.3V | :1703 | :16V | 1000 | 1000 | 0.25A | 16V | Linear | 0.005 mA | MCP1703T-3302E/MBCT | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | SOT89-3 | 16V | 1 | voltage stabiliser | LDO, fixed | 0.36 g | 625mV | 3.3V | 100 | 100 | MCP1703T-3302E/MB | 14 weeks | YES | -40°C | 125°C | POS | NO | 630mV | 2% | RoHS-conform | 0.002mA | - | YES | - | - | - | - | - | - | - | ±0.4% | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Linear | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 4SOT-223 | Positive | 1 | 6 V | 30 V | 0.07(Min) A | 3.3 V | 0.7@70mA V | ±2.5 % | ±0.0002(Typ) %/V | ±0.2(Typ) % | -40 to 125 °C | Surface Mount | Fixed | Rail / Tube | LDO Voltage Regulators | RoHS Compliant | 30 V | 70 mA | + 125 C | SMD/SMT | TO-261-4, TO-261AA | + 6 V | - 40 C | TUBE | 78 | 2.5 % | Positive Fixed | Surface Mount | 1 | SOT-223-3 | 3.3V | 0.7V @ 70mA | 70mA (Min) | 6 V ~ 30 V | Lead free / RoHS Compliant | 1.3 V at 70 mA | :6V | :30V | :700mV | :SOT-223 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.0001 | 85423190 | 0.07 mA | :3.3V | :1790 | :30V | 78 | 1 | 0.70A | 6V | Linear | 0.13 mA | - | Linear | 3 +Tab | SOT-223 | :2.5% | :1 | :6V | :SMD | -40C to 125C | Fixed | Positive | �2.5 % | Automotive | 6 V | LDO | No | 70mA | SOT-223-3 | -40to+125°C | 700mV | 48V | 0.7@70mA | 1.3@70mA | - | :0.07A | 3.3V | SOT223 | 30V | 1 | voltage stabiliser | LDO, fixed | 0.35 g | 700mV | 3.3V | 156 | 156 | MCP1790-3302E/DB | 14 weeks | YES | -40°C | 125°C | POS | NO | 700mV | 2.5% | RoHS-conform | 0.0070mA | 0.13 mA | YES | ±0.0002%/V | ±0.2% | LowDropout | 1.2μV/sqrtHz | 90dB | - | - | - | 70μA | - | 70µA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 15°C/W | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 6SOT-223 | Positive | 1 | 2.1 V | 6 V | 0.5(Min) A | 0.8 to 5 V | 0.21@500mA V | ±0.5(Typ) % | 0.05(Typ) %/V | 0.5(Typ) % | -40 to 125 °C | Surface Mount | Adjustable | Tape & Reel | LDO Voltage Regulators | RoHS Compliant | 6 V | 500 mA | + 125 C | SMD/SMT | SOT-223-6 | + 2.1 V | - 40 C | Tape and Reel | 4000 | 0.5 % | Positive Adjustable | Surface Mount | 1 | SOT-223-5 | 0.8 V ~ 5 V | 0.21V @ 500mA | 500mA (Min) | 2.1 V ~ 6 V | Lead free / RoHS Compliant | 0.35 V at 500 mA | :2.1V | :6V | :210mV | :SOT-223 | :5 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | 0.0001 | 85423190 | 0.12 mA | - | :1825 | :6V | 4000 | 4000 | 500mA | 6 V | Linear | 0.22 mA | MCP1825T-ADJE/DCCT | Linear | 6 | SOT-223 | :0.5% | :1 | :2.1V | :SMD | -40C to 125C | Adjustable | Positive | �0.5 % | Automotive | 2.1 V | LDO | No | 500mA | SOT-223-5 | -40to+125°C | 210mV | 6V | 0.21@500mA | 0.35@500mA | - | :0.5A | - | SOT223-5 | 6V | 1 | voltage stabiliser | adjustable | 0.4 g | 210mV | 0.8...5V | 100 | 100 | - | - | - | - | - | - | - | - | - | - | - | 0.22 mA | - | - | - | - | - | - | - | - | ±0.5% | - | - | - | 0.21@500mA | Extended | 2.1 | Compliant | -40 | SOT-223 | SOT-223 | 125 | Current Limit|Short Circuit Prote... | 0.35@500mA | 0.8 to 5 | 0.5(Min) | ±0.5(Typ) | 6 | Gull-wing | - | 0.22 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 0.41(Typ) V | 3.5 | 5 | 6.5 | 1.6 | Tab | :800mV | :5V | :800mV to 5V | :LDO |
第 1 / 12 页
