cooper bussmann
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 电压 | 600V |
| 额定电流 | 30A |
| 安装类型 | DIN Rail |
| 保险丝座型 | Holder |
| 保险丝规格 | 0.394" Dia x 1.496" L (10mm x 38mm) |
| 端接类型 | Screw Terminal |
| 保险丝类型 | Cartridge |
| 配用/相关产品 | MIDGET |
| 标准包装 | 6 |
| 电路数 | 1 |
| 其他名称 | 283-3493 |
| RoHS指令 | Compliant |
| 安装风格 | DIN Rail |
| 产品 | Fuse Holders |
| 产品种类 | Fuse Holders |
| 额定电压 | 600 V |
| 系列 | CHM |
| 单位重量 | 0.035274 oz |
| 封装 | Bulk |
| 极数 | 1 |
| RoHS | RoHS Compliant |
| 标准包装 | 12 |
| Voltage Rating VDC | :600V |
| Voltage Rating VAC | :600V |
| Fuse Current | :30A |
| 保险丝座型 | :Modular Fuse Holder |
| Holder Terminals | :Pressure Plate |
| No. of Fuses | :1 |
| Fuse Size Held | :Midget |
| Weight (kg) | 0 |
| Tariff No. | 85369010 |
| Brand/Series | CHSeries |
| CurrentRating | 30A(UL)/32A(IEC) |
| Dimensions,Fuse | 10x38mm |
| MountingStyle | DINRail |
| NumberofPoles | 1 |
| 标准 | CCC/CSA(Class6225-30/CHCC)/IEC60269-2/UL/UR |
| TerminalType | CombBusBar/SpadeLug/Wire |
| VoltageRating | 600(UL)/690(IEC)V |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
