Neutrik
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 身体上的取向 | Straight |
| 触点材料 | Brass |
| 触点电镀 | Silver over Nickel |
| 额定电流 | 16A |
| 性别 | Male |
| 外壳材料 | Zinc |
| 最高工作温度 | +80°C |
| 最低工作温度 | -30°C |
| 安装类型 | Cable Mount |
| 触点数 | 3 |
| 端接方式 | Solder |
| 额定电压 | 50 V |
| 工厂包装数量 | 40 |
| 产品种类 | XLR Connectors |
| 定位 | Vertical |
| 端接类型 | Solder |
| 单位重量 | 0.888904 oz |
| 标准 | Standard XLR |
| 封装 | Bulk |
| 位置/触点数 | 3 |
| RoHS | RoHS Compliant |
| 安装风格 | Chassis (Panel) |
| 产品类型 | Connectors |
| 外壳电镀 | Nickel |
| 系列 | :DLX |
| No. of Contacts | :3 |
| 接触端子 | :Solder |
| Connector Mounting | :Panel |
| Connector Body Material | :Metal |
| SVHC | :No SVHC (20-Jun-2013) |
| 主体镀层 | :Nickel |
| 颜色 | :Nickel |
| Connector Colour | :Natural |
| 可燃性等级 | :UL94HB |
| 绝缘电阻 | :1Gohm |
| 材质 | :Zinc Die-cast |
| No. of Mating Cycles | :1000 |
| Operating Temperature Max | :+80°C |
| Operating Temperature Min | :-30°C |
| Wire Area Size Max | :2.5mm² |
| Wire Size AWG Max | :14AWG |
| Weight (kg) | 0.026 |
| Tariff No. | 85366990 |
| Angle | Straight |
| Brand/Series | DLXSeries |
| ContactPlating | SilveroverNickel |
| Current,Rating | 16A |
| FlammabilityRating | UL94HB |
| InsulationType | Uninsulated |
| Material,Body | ZincDie-Cast |
| Material,Contact | Brass |
| MountingType | Panel |
| NumberofContacts | 3 |
| PrimaryType | XLR |
| 端子 | Solder |
| 类型 | Plug |
| Voltage,Rating | 50V |
| RoHS指令 | RoHS Compliant Part |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
