| 规格书 |
 3D PDF 4-1773460-6_RESISTIVE_SOLUTIONS_RAIL 1309350_PASSIVE_COMPONENT Flame Proof Power Metal Oxide Film Resistors - Type ROX Series - Tyco Electronics Passives 8-1773459-4_POWER_FILTERING_AND_RESISTIVE_SOLUTIONS_FOR_ELEVATORS_AND_ESCALATORS |
| RoHS | RoHS Compliant |
| 电阻 | 2.7 Ohms |
| 容差 | 5 % |
| 额定功率 | 1 W |
| 额定电压 | 350 V |
| 温度系数 | 350 PPM / C |
| 端接类型 | Axial |
| 工作温度范围 | - 55 C to + 235 C |
| 外形尺寸 | 3.5 mm Dia. x 10 mm L |
| 产品 | Power Resistors Metal Oxide |
| 零件号别名 | 5-1625885-6 |
| 机箱样式 | Conformal |
| 直径 | 3mm |
| 长度 | 9mm |
| 最高工作温度 | +235°C |
| 最大温度系数 | +300ppm/°C |
| 最低工作温度 | -55°C |
| 最低温度系数 | -300ppm/°C |
| 技术 | Metal Oxide |
| RoHS指令 | Compliant |
| 表壳直径 | 3.5 mm |
| 表壳长度 | 10 mm |
| 产品范围 | :TE CONNECTIVITY - ROX Series |
| 电阻公差 | :± 5% |
| Resistor Case Style | :Axial Leaded |
| Resistor Element Material | :Metal Oxide |
| Resistor Mounting | :Through Hole |
| Weight (kg) | 0.0006 |
| Tariff No. | 85331000 |
| Brand/Series | ROXSeries |
| Material,Element | MetalOxide |
| Power,Rating | 1W |
| 端子 | Axial |
| TycoPartNumber | 5-1625885-6 |
