Omron Industrial
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 产品种类 | Relay Sockets & Hardware |
| RoHS | RoHS Compliant |
| 附件类型 | Solder Terminal Socket |
| 相关继电器系列 | LY, SP, DP |
| 端接类型 | Solder Terminal |
| 应用 | All models meet UL and CSA approved, Arc barrier equipped |
| 封装 | Bulk |
| 系列 | PT08 |
| 工厂包装数量 | 10 |
| 零件号别名 | 1181267 |
| 欧盟RoHS指令 | Compliant |
| 安装 | Through Hole |
| 身体上的取向 | Straight |
| 性别 | SKT |
| 端接方式 | Solder |
| 触点数 | 8 |
| 类型 | Relay Socket |
| 工业别名 | PT08-0 |
| 子类别 | Connector Socket |
| 交货期 | 20 Days |
| 安装类型 | Through Hole |
| 配用/相关产品 | LY Series, SPDT/DPDT |
| 标准包装 | 10 |
| 位置数 | 8 |
| RoHS指令 | Lead free / RoHS Compliant |
| 适用于 | LY1-0, LY2-0, LY2Z-0 |
| Socket Mounting | :PC Board |
| 额定电流 | :15A |
| Socket Terminals | :Through Hole |
| 额定电压 | :110VAC |
| No. of Pins | :8 |
| Leaded Process Compatible | :Yes |
| No. of Contacts | :8 |
| Weight (kg) | 0.032 |
| Tariff No. | 85369010 |
| SVHC | :No SVHC (20-Jun-2013) |
| 终端类型 | :Through Hole |
| ForUseWith | LY1and2polerelay |
| MountingType | PCB |
| NumberofPoles | 1 |
| RelayType | GeneralPurpose |
| 标准 | ULRecognized,CSACertified,VDEApproved |
| 端子 | PCB |
| Leads | for PCB |
| 外形尺寸 | see |
| 额定电流 | 10A |
| Multiplicity | 1 |
| 身高 | 12mm |
| Gross weight | 9.32 g |
| 宽度 | 22mm |
| Operating temperature | -25...55°C |
| 针数 | 8 |
| 额定电压 | 250V AC |
| Relay series | LY2 |
| Type of relays accessories | socket |
| Collective package [pcs] | 5 |
| spg | 5 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
