omron electronics
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 位置数 | 2 |
| 安装 | Surface Mount |
| 极掷配置 | SPST |
| 交换机配置 | ON OFF |
| 执行器风格 | Recessed Slide |
| 终端类型 | Gull Wing |
| 最大额定电流 | 0.025@24VDC A |
| 最大直流额定电压 | 24 V |
| 工作温度 | -20 to 70 °C |
| 标准包装 | Rail / Tube |
| 水洗 | No |
| 执行器类型 | Standard |
| 安装类型 | Surface Mount |
| 电路 | SPST |
| 触点额定电压 | 0.025A @ 24VDC |
| 定位 | Top Actuated |
| 其他名称 | A6H2101 |
| 触动器电平 | Flush |
| RoHS指令 | Lead free / RoHS Compliant |
| 工厂包装数量 | 125 |
| 安装方式 | Straight |
| 产品种类 | DIP Switches / SIP Switches |
| 端子节距 | 1.27 mm |
| 工作温度范围 | - 20 C to + 70 C |
| 系列 | A6H |
| 封装/外壳 | DIP-2 |
| 端接类型 | SMD/SMT |
| 直流电额定电压 | 24 V |
| 执行器 | Flat |
| 额定电流 | 25 mA |
| 零件号别名 | 658654 |
| 开关类型 | DIP |
| RoHS | RoHS Compliant |
| Overall length | 3.77mm |
| Poles number | 2 |
| DC contacts rating (at resistance load) | 0.025 A / 24 VDC |
| Min insulation resistance | 100MΩ |
| Mechanical durability | 1000cycles |
| Electrical life | 1000cycles |
| Terminal pitch | 1.27mm |
| Row pitch | 6.15mm |
| Gross weight | 0.16 g |
| Switching method | ON-OFF |
| Operating temperature | -20...70°C |
| Multiplicity | 1 |
| Switches features | flat actuator |
| Switch type | DIP-SWITCH |
| Contact material | beryllium copper |
| SubCategory | DIP Switch |
| MainCategory | Switches |
| 系列 | A6H |
| 位置数 | 2 |
| 致动器水平 | Flush |
| 电路 | SPST |
| 不同电压时的触头额定电流 | 0.025A @ 24VDC |
| 致动器类型 | Standard |
| Dimensions L x W x H | 3.77 x 4.5 x 1.55 mm |
| 接触电阻 | <200 mOhm |
| Switching capacity | 25 mA@ 24 VDC |
| Actuation | above, flat |
| 测试电压 | 300 |
| 连接方式 | SMD |
| Insulation resistance | >100 MOhm |
| 间距 | 1.27 |
| Temperature range | -20...+70 °C |
| Poles | 2 |
