bourns
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| Operating Temperature | -40 to 125 °C |
| Standard Package | Bulk |
| Mounting | Through Hole |
| Shaft Style | Slot |
| Programmable | No |
| Type | Square Encoder |
| Maximum Operating Speed | 120r/min |
| EU RoHS | Compliant |
| Shaft Diameter | 3.18 |
| Shaft Material | Plastic |
| Number of Channels | 3 |
| Minimum Operating Temperature | -40 |
| Mechanical Life | 100000 |
| Terminal Type | PC Pins |
| Product Length | 9.53 |
| Encoder Code | Quadrature |
| Maximum Operating Temperature | 125 |
| IP Rating | IP67 |
| Body Orientation | Right Angle |
| Motion | Rotary |
| Shock Rating | 100G |
| Encoder Signal | Digital Square Wave |
| Maximum Operating Torque | 5oz.in |
| Pulses per Revolution | 6 |
| Product Depth | 17.88 |
| Encoder Reading | Incremental |
| Modular Kit Encoder | No |
| Product Height | 9.53 |
| Detents | No |
| Index output | Not Indexed |
| Rotational Life (Cycles Min) | 100K |
| Mounting Type | Panel, PCB Through Hole |
| Termination Style | PC Pin |
| Encoder Type | Mechanical |
| Output Type | Quadrature (Incremental) |
| Detent | No |
| Actuator Type | 1/8" Dia Slotted End |
| Built in Switch | No |
| Other Names | 3315C001006L |
| Orientation | Right Angle |
| rohs | Lead free / RoHS Compliant |
| Encoder Technology | Incremental |
| Maximum Operating Temperature | +125°C |
| Maximum Revolutions | 120rpm |
| Minimum Operating Temperature | -40°C |
| Output Signal Type | Quadrature |
| Overall Depth | 17.88mm |
| Overall Height | 9.53mm |
| Overall Width | 9.53mm |
| Pulses Per Revolution | 6ppr |
| Resolution | 2 bit |
| Shaft Type | Slotted |
| Factory Pack Quantity | 50 |
| With Switch | No Switch |
| Mounting Style | Panel |
| Product | Mechanical Encoders |
| Product Category | Encoders |
| Shaft Length | 12.7 mm |
| Shaft Diameter | 1/8 in |
| Operating Temperature Range | - 40 C to + 125 C |
| Size / Dimension | 9 mm |
| Output | Quadrature |
| RoHS | RoHS Compliant |
| Number of Detents | 0 |
| Series | 3315 |
| Bushing Size | 6.35 mm x 6.35 mm |
| Packaging | Bulk |
| Bushing Thread | 1/4-32 UNEF-2A |
| Bushing Material | Plastic |
| Technology | Rotary |
| No. of Channels | :3 |
| Rotational Speed Max | :120rpm |
| SVHC | :No SVHC (16-Dec-2013) |
| Weight (kg) | 0.0011 |
| Tariff No. | 85334010 |
